Notice to customer
Changing and calibrating lenses
Table of contents
1 Thank you! ...............................................................................................1
2 Applicability..............................................................................................1
3 Changing lenses (FLIR Exx series) ....... ........................ ............ ............ ......... 2
4 Changing lenses (FLIR T5xx series)......... ............ ............ ............ ............... ... 5
5 Calibrating the lens–camera combination ......... ............ ............ ............ ........... 8
6 Customer support ...................................................................................... 9
7 Appendix ............................................................................................... 10
1 Thank you!
Thank you for choosing a product from FLIR Systems. We hope that the product will
meet your expectations and that you will consider us again for your future needs.
2 Applicability
Note Part numbers subject to change and/or amendment without further notice.
Please check http://support.flir.com for latest applicability data.
2.1 Lens applicability
Sales order P/N Item P/N Product denomination
T199588 T199106 Lens 14° + case
T199590 T199104 Lens 42° + case
T199589 T199105 Lens 24° + case
2.2 Camera applicability
P/N Product denomination
78502-0101 FLIR E75 24°
78504-0101 FLIR E75 24° + 14°
78506-0101 FLIR E75 24° + 14° & 42°
78505-0101 FLIR E75 24° + 42°
78503-0101 FLIR E75 42°
78507-0101 FLIR E75 42° + 14°
78502-0201 FLIR E85 24°
78504-0201 FLIR E85 24° + 14°
78506-0201 FLIR E85 24° + 14° & 42°
78505-0201 FLIR E85 24° + 42°
78503-0201 FLIR E85 42°
78507-0201 FLIR E85 42° + 14°
78502-0301 FLIR E95 24°
78504-0301 FLIR E95 24° + 14°
78506-0301 FLIR E95 24° + 14° & 42°
78505-0301 FLIR E95 24° + 42°
78503-0301 FLIR E95 42°
78507-0301 FLIR E95 42° + 14°
79302-0101 FLIR T530 24°
79304-0101 FLIR T530 24° + 14°
79306-0101 FLIR T530 24° + 14° & 42°
79305-0101 FLIR T530 24° + 42°
79303-0101 FLIR T530 42°
Copyright
© 2017, FLIR Systems, Inc.
All rights reserved worldwide. Names and marks
appearing herein are either registered trademarks
or trademarks of FLIR Systems and/or its
subsidiaries. All other trademarks, trade names or
company names referenced herein are used for
identification only and are the property of their
respective owners.
Document identity
Publ. No.: T810264
Release: AC
Commit: 45029
Head: 45029
Language: en-US
Modified: 2017-09-18
Formatted: 2017-09-18
Website
http://www.flir.com
Customer support
http://support.flir.com
Disclaimer
Specifications subject to change without further
notice. Models and accessories subject to
regional market considerations. License
procedures may apply. Products described herein
may be subject to US Export Regulations. Please
refer to exportquestions@flir.com with any
questions.
1 (10) www.flir.com
Notice to customer
Changing and calibrating lenses
© 2017, FLIR Systems, Inc.
#T810264; r. AC/45029/45029; en-US
P/N Product denomination
79307-0101 FLIR T530 42° + 14°
79302-0201 FLIR T540 24°
79304-0201 FLIR T540 24° + 14°
79306-0201 FLIR T540 24° + 14° & 42°
79305-0201 FLIR T540 24° + 42°
79303-0201 FLIR T540 42°
79307-0201 FLIR T540 42° + 14°
3 Changing lenses (FLIR Exx series)
Note If the new lens has not been used with the camera before, the lens–camera com-
bination must be calibrated after the lens has been mounted. See section 5 Calibrating
the lens–camera combination, page 8 for information on how to do this.
Note Do not touch the lens surface when you change lenses. If this happens, clean
the lens according to the instructions in 7.1 , page 10.Infrared lens
Follow this procedure:
1. Take a firm grip around the inner ring of the lens. Rotate the inner ring 30° counter-
clockwise until it stops.
2. Carefully pull out the lens.
2 (10) www.flir.com
Notice to customer
Changing and calibrating lenses
© 2017, FLIR Systems, Inc.
#T810264; r. AC/45029/45029; en-US
3. The infrared detector is now fully exposed. Do not touch this surface. If you see dust
on the detector, follow the instructions in 7.2 , page 10.Infrared detector
4. Make sure that the inner ring of the camera lens is fully in its open position.
• Correct: The tooth (1) is in its end position at the black stop pin (2).
• Wrong: You must rotate the inner ring until the tooth (1) reaches the black stop pin
(2).
3 (10) www.flir.com
