“Triplex Diaphragm”

3426 / 3526 / 3626 Series

Automatic Water System Pump

FEATURES

• Self–Priming

• Dry Running

• Soft Noise Absorbing Mounts

• Snap–in Port Fittings

• Built-in Bypass : Less Pulsation

• Reduces need for accumulator tank

• Corrosion Resistant Materials

• Meets ISO 8846 (Ignition protection)

SPECIFICATIONS

Motor:Permanent Magnet, Ball Bearing

Totally Enclosed. CE Models are

fully suppressed.

Pump: Three chamber diaphragm design

Self-priming up to 9 feet suction lift;

Pump able to run dry without damage

Dimensions English (SI)

*CE fully suppressed models are identified by a prefix “R” and a CEmark on the label.(i.e. R3626144).

Self Declaration Of Conformance (SDOC) is available upon request.

OPERA

TION

With pump switch off and battery fully charged, fill water tank, open all faucets, then turn pump switch on. Water will

begin to flow. When the water is free of air, turn faucets off. Remember, you are filling the water heater and the toilet

and shower lines. When all valves are shut-off, pump will stop. Should pump fail to stop, turn switch off and see the

trouble shooting guide.

CAUTION - Pump surface will get hot to the touch if operated for extended periods of time

under pressurized conditions.

2.25"

3.12"

4.24"

4.75"

3.18"

9.04"

(80 mm)

(65 mm)

(229 mm)

(80 mm)

(108 mm)

(121 mm)

DIMENSIONAL DRAWING

Model 3426 / 3526 / 3626 Series

PumpHeight Length Width Weight

Series

inches (mm) inches (mm) inches (mm) Lb (Kg)

3X26XXX 4.75 (121) 9.00 (229) 6.00 (152) 3.50 (1.59)

MODEL*VOLTSAMP DRAW

@10 psi (0.7 bar)

FLOW

GPM (LPM)

PRESSURE SWITCH

Max psi (bar)

BYPASS

0352614412V dc4.42.9 (11)50 (3.4)Yes

R362634424V dc2.22.9 (11) 40 (2.8)Yes

R342614412V dc4.4 2.9 (11) 25 (1.7)Yes

R342634424V dc2.22.9 (11)25 (1.7)Yes

R342614812V dc3.52.0 (8)25 (1.7)Yes

R342634824V dc1.72.0 (8)25 (1.7)Yes
