Sida 1/8
1
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
A s s e m b l y M a n u a l
Flowline Master with Edge V1 Stabilizaon Arm
(FLN MSTR EGV1) - -
2 x Washers
2 x Velcro
2.5mm Allen Key
2mm Allen Key
Edge V1
Stabilizaon
Arm
Height Riser
Flycam
Flowline
Master
Support Bar
Camera Hook
Side Support
Adjustment
Balance Adjustment
Knob
2
• Similarly, remove the second screw.
• Now, remove the Hook from the Flowline
Support Arm.
• As shown in the image, take the Cord
bundle out from the Cup and pull the Cord
unl a Cord lock comes out.
• Separate the Cord and the Cord lock.
• Keep the lock aside to re aach it later.-
Flowline Master with Edge Setup
• Loosen the screw of the Camera Hook
aached to the Flowline Support Arm using
the Allen key.
• Similarly, separate the Cord from the Cup to
mount it back later.
NOTE: It is recommended to aach the minimum required weight (4kg / 8lb) for pulling down the balancing
rope to ensure proper operaon of your Flycam Flowline system.
3
• To detach the Flowline Support Rod,
pull it upwards.
• To detach the extension from the Support
Rod of the Vest, remove its screw using a
screwdriver.
• Detach the extension from the Support Rod
and align the cord with the height riser, as
shown in the image.
• Aach the extension with the height riser
and push it inside.
Feature: Height riser that oers up to 4" of
vercal extension for taller operators and a
lockable hook to secure any camera, gimbal,
or cage eortlessly.
• Dissemble the Camera Hook and the
Support Rod from the Vest.
• Insert a screw in the Support rod and
ghten it using the screwdriver.
