Sida 1/4
[Volkswagen®: Golf 6, Passat, Polo, Amarok, T6.1…]
Check online your vehicle compatibility.
Focal
®
is a trademark of Focal-JMLab
®
- www.focal.com - SCCG - 07/11/2020 - v1
IS VW 165
Product Data Sheet
Type 2-way component kit
Woofer
165mm
Tweeter
Aluminium inverted dome
Voice coil diameter
1" (25mm)
Voice coil height
1/2"
Magnet
Ferrite
Cone
Polyglass
Suspension
Butyl
Impedance
2Ω
Max. power
120W
Nom. power
60W RMS
Sensitivity (2.83V/1m)
93.7dB
Frequency response
60Hz-20kHz
Crossover
Woofer: integrated
Tweeter: on line
Polyglass cone
Neutral sound without coloration
Chassis-integrated spacer
Perfect integration
in the original locations
Butyl surround
Excellent durability
Vehicle dedicated connector
No welding and no cables to cut
Foam kit included
Tweeter mounting foams
and anti-vibration foams
included
Aluminium inverted dome tweeter
with adaptation ring
Smoothness and definition
of sound in every directions
Check your car compatibility
at www.focal-inside.com
Key Points
• Quick and easy install
• No modifications needed on the vehicle
• Invisible integration
• Increased sound quality
• No additional accessories required
The IS VW -way component kit is designed for all drivers who wish to replace their original audio system with
a quality sound solution The speaker drivers employ Polyglass technology which delivers well-defined midrange
and bass The Aluminium inverted dome tweeter a Focal technology provides perfect treble reproduction This
kit is designed for vehicles that have tweeter slots
Woofer
SPECIFICATIONS
Focal
®
is a trademark of Focal-JMLab
®
- www.focal.com - SCCG - 09/11/2020 - v1
IS VW 165
Technical Sheet
FREQUENCY RESPONSE/IMPEDANCE
MECHANICAL DRAWING
PARAMETERS
Nominal power 60W
Maximum power 120W
Sensitivity 93.7dB
Nom. impedance 2 Ω
Cone Black Polyglass
Surround Butyl
DC resistance 2.08 Ω
VC diameter 25mm 1"
Former Kapton
Layers 2
Wire Copper
Net weight 900g 1.98 lbs
Rdc 2.08 Ω
Fs 77.7Hz
Mms 16.7g
Cms 0.25mm/N
Vas 6.65 l
Qts 0.8
Qes 0.919
Qms 6.2
Bxl 4.3N/A
Sd 136.85cm²
SPL 87.7dB
Xmax 7mm
Dimensions in mm
85
80
35
3
38.6
73.6
151.3
169
158.5
4 x
5.1
170
0
5
10
15
20
25
30
35
40
50
55
60
65
70
75
80
85
90
95
100
105
110
10 100 1000 10000
Frequency response - 0° Frequency response - 30° Impedance
Impedance (Ohm)
SPL (dB) - 2.83V, 1m
Tweeter
SPECIFICATIONS
Focal
®
is a trademark of Focal-JMLab
®
- www.focal.com - SCCG - 09/11/2020 - v1
TWEETER VW
Technical Sheet
FREQUENCY RESPONSE/IMPEDANCE
MECHANICAL DRAWING
PARAMETERS
Nominal power 15W
Maximum power 100W
Sensitivity 91dB
Nom. impedance 4 Ω
Cone Aluminium
Surround Fabric
DC resistance 3.5 Ω
Former Kapton
Layers 2
Wire Aluminium
Net weight 50g 0.11 lbs
Rdc 3.5 Ω
Fs 3875Hz
Mms 24.7g
SPL 88dB
Dimensions in mm
45.8
39.9
21.5
6.6 14.9
26
4,6
4,8
5
5,2
5,4
5,6
5,8
6
50
55
60
65
70
75
80
85
90
95
100
105
110
200 2000 20000
Frequency response - 0° Frequency response - 30° Impedance
Impedance (Ohm)
SPL (dB) - 2.83V, 1m
