Sida 1/4
[Volkswagen®: Touran, Tiguan II, Touareg, Passat, Beetle…]
Check online your vehicle compatibility.
Focal® is a trademark of Focal-JMLab® - www.focal.com - SCCG - 07/11/2020 - v1
IS VW 180
Product Data Sheet
Type 2-way component kit
Woofer 180mm
Tweeter Aluminium inverted dome
Voice coil diameter 1" (25mm)
Voice coil height 1/2"
Magnet Ferrite
Cone Polyglass
Suspension Butyl
Impedance 2Ω
Max. power 150W
Nom. power 75W RMS
Sensitivity (2.83V/1m) 94dB
Frequency response 50Hz-20kHz
Crossover Woofer: integrated
Tweeter: on line
Polyglass cone
Neutral sound without coloration
Chassis-integrated spacer
Perfect integration
in the original locations
Butyl surround
Excellent durability
Vehicle dedicated connector
No welding and no cables to cut
Foam kit included
Tweeter mounting foams
and anti-vibration foams
included
Aluminium inverted dome tweeter
with adaptation ring
Smoothness and definition
of sound in every directions
Check your car compatibility
at www.focal-inside.com
Key Points
• Quick and easy install
• No modifications needed on the vehicle
• Invisible integration
• Increased sound quality
• No additional accessories required
• Large emissive surface delivering deep bass
The IS VW -way component kit is designed for all drivers who wish to replace their original audio system with
a quality sound solution The speaker drivers employ Polyglass technology which delivers well-defined midrange
and bass The Aluminium inverted dome tweeter a Focal technology provides perfect treble reproduction This
kit is designed for vehicles that have tweeter slots
Woofer SPECIFICATIONS
Focal® is a trademark of Focal-JMLab® - www.focal.com - SCCG - 09/11/2020 - v1
IS VW 180
Technical Sheet
FREQUENCY RESPONSE/IMPEDANCE
MECHANICAL DRAWING
PARAMETERS
Nominal power 75W
Maximum power 150W
Sensitivity 94dB
Nom. impedance 2 Ω
Cone Black Polyglass
Surround Butyl
DC resistance 2.07 Ω
VC diameter 25mm 1"
Former Kapton
Layers 2
Wire Copper
Net weight 1050g 2.31 lbs
Rdc 2.07 Ω
Fs 62.4Hz
Mms 24.7g
Cms 0.264mm/N
Vas 12.6 l
Qts 0.695
Qes 0.782
Qms 6.23
Bxl 5.06N/A
Sd 183.35cm²
SPL 88dB
Xmax 7mm
Dimensions in mm
0
5
10
15
20
25
30
35
40
50
55
60
65
70
75
80
85
90
95
100
105
110
10 100 1000 10000
Frequency response - 0° Frequency response - 30° Impedance
Impedance (Ohm)
SPL (dB) - 2.83V, 1m
Tweeter SPECIFICATIONS
Focal® is a trademark of Focal-JMLab® - www.focal.com - SCCG - 09/11/2020 - v1
TWEETER VW
Technical Sheet
FREQUENCY RESPONSE/IMPEDANCE
MECHANICAL DRAWING
PARAMETERS
Nominal power 15W
Maximum power 100W
Sensitivity 91dB
Nom. impedance 4 Ω
Cone Aluminium
Surround Fabric
DC resistance 3.5 Ω
Former Kapton
Layers 2
Wire Aluminium
Net weight 50g 0.11 lbs
Rdc 3.5 Ω
Fs 3875Hz
Mms 24.7g
SPL 88dB
Dimensions in mm
45.8
39.9
21.5
6.6 14.9
26
4,6
4,8
5
5,2
5,4
5,6
5,8
6
50
55
60
65
70
75
80
85
90
95
100
105
110
200 2000 20000
Frequency response - 0° Frequency response - 30° Impedance
Impedance (Ohm)
SPL (dB) - 2.83V, 1m
