DUAL MIC-PRE

Green Dual Mic Pre (introduction) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Section (i): Setting Up

Power Connections

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Power Supply

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Signal Connections

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Section (ii): Functions

Controls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Setting the Gain

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Setting the Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using Mic Preamplification

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Recording Direct to Hard Disk or DAT

. . . . . . . . . . . . . . . . . . . . . . . . . . .9

Recording to Tape (Analogue or Digital)

. . . . . . . . . . . . . . . . . . . . . . . .10

Stereo Recording

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Spaced Omni-directional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Coincident Pair

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Section (iii): Trouble Shooting

Non-Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Changing A Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Worldwide Distributors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

c o n t e n t s

Green Dual Mic Pre

The Green Mic Pre provides two high performance microphone preamplifiers, as two

independent channels.

A microphone preamplifier converts low-level microphone signals to line level sig-

nals, which is the level used in recording and PA gear. A lot of equipment contains

mic preamps (for example, mixing desks, and some tape machines), but they do not

provide the quality of a dedicated mic preamp, so you can improve the quality of

your sound by using the Green Mic Pre instead of the built-in preamps.

Power Connections

There is an IEC mains lead supplied in the package which should have the correct

moulded plug for your country. The wiring colour code used in all Focusrite products is:

For units shipped to the USA, Canada, Taiwan and Japan

Live Neutral Earth - Black - White - Green

For units shipped to any other country

Live Neutral Earth - Brown - Blue - Green and Yellow

The chassis is connected directly to the mains safety earth. We do not provide an

earth lifting switch, since such a switch can allow for a dangerous wiring arrange

ment.

Warning: For safety reasons, it is absolutely IMPERATIVE that the mains safety earth

is connected.

d u a l m i c - p r e

Power Supply

All modules will work correctly from either 50 Hz or 60 Hz power supplies, and draw

approximately 35VA from the mains supply at highest load.

Most modules will operate on a range of voltages, and have a two-position switch on

the rear panel that should be set to the correct voltage:

115V

Set to this position if the module is to be used with

voltages in the range 85V to 120V

230V

Set to this position if the module is to be used with

voltages in the range 200V to 250V

To comply with the safety codes in some countries, modules may be supplied with

out a voltage selector. In this case, the module is preset to the local supply voltage,

which is clearly marked on the rear of the module. Check that the voltage is set cor

rectly.

Signal Connections

All the signal connections are via connectors mounted on the rear panel. Standard

XLR connectors are used for all mic and line level signals, and are wired to the AES

standard, which are:

Pin 1 Screen chassis

Pin 2 Live audio 0°

Pin 3 Return audio 180°

For all inputs and outputs, the screen (pin 1 of the XLR) is connected to the chassis

earth point.

In the Green range, jack inputs are used only for external switching applications or

as unbalanced guitar inputs on some units.

When the screen and earth wiring of the module is completed correctly, all modules

which are marked with the European Community CE marking comply fully with the

CE EMC regulations.

s e t t i n g u p
