Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352

Introduction. . . . . . . . . . . . . . . . . .2

Important Safety Instructions. . . . . . . .3

Cooking Recommendations. . . . . . . . 12

Before Setting Surface Controls . . . . . 15

Setting Surface Controls. . . . . . . . . . 16

Before Setting Oven Controls. . . . . . . 17

Oven Controls . . . . . . . . . . . . . . . 18

Care and Cleaning . . . . . . . . . . . . . 20

Before You Call . . . . . . . . . . . . . . . 22

Warranty . . . . . . . . . . . . . . . . . . 24

use

care

WALL OVEN

A23376002 (October 2021)

INTRODUCTION

Welcome to our

family

Thank you for bringing Frigidaire into your home!

We see your purchase as the beginning of a long

relationship together.

This manual is your resource for the use and care

of your product. Please read it before using your

appliance. Keep it handy for quick reference. If

something doesn’t seem right, the troubleshooting

section will help you with common issues.

FAQs, helpful tips and videos, cleaning products, and

kitchen and home accessories are available at www.

frigidaire.com.

We are here for you! Visit our website, chat with an

agent, or call us if you need help. We may be able

to help you avoid a service visit. If you do need

service, we can get that started for you.

Let’s make it ocial! Be sure to register your prod-

uct.

Keep your product info here so it’s easy to ﬁnd.

Model Number:

Serial Number:

Purchase Date:

Serial Number Location

 Read all the safety instructions in the front of

your Use & Care Manual.

 Remove all packaging materials from your ap-

pliance before cooking.

 Conﬁrm that the electrical power to the appli-

ance is turned on.

 Wipe out the inside of the oven cavity with a

damp cloth.

 Apply a thin layer of cooking oil to the sides of

the oven racks to keep them gliding smoothly.

 Set the clock. See (page 13) for instructions.

 Before cooking, set the oven to bake at 350°F

(177ºC) for 30 minutes (page 19). Some noise

and odors are normal on the ﬁrst cooking cycle.

 Remember to complete your product registra-

tion!

Installation Checklist



Serial Number Location

Important Safety InStructIonS

defInItIonS

This is the safety alert symbol. It is

used to alert of potential personal injury

hazards. Obey all safety messages that

follow this symbol to avoid possible injury

or death.

WarnInG

Indicates a potentially hazardous

situation which, if not avoided, may

result in death or serious injury.

cautIon

Indicates a potentially hazardous

situation which, if not avoided, may

result in minor or moderate injury.

Important

Indicates installation, operation or

maintenance information which is

important but not hazard-related.

Read all instructions before using this

appliance.

This manual contains important safety

symbols and instructions. Please pay

attention to these symbols and follow all

instructions given.

Do not attempt to install or operate your

appliance until you have read the safety

precautions in this manual. Safety items

throughout this manual are labeled with a

WARNING or CAUTION statement based

on the risk type.

Warnings and important instructions

appearing in this guide are not meant to

cover all possible conditions and situations

that may occur. Common sense, caution,

and care must be exercised with installing,

maintaining, or operating your appliance.

note

Indicates a short, informal reference –

something written down to assist the

memory or for future reference.

WARNING

Tip Over Hazard

• A child or adult can tip the

oven and be killed.

• Install the anti-tip device

to oven and/or structure

per installation instructions.

• Ensure the anti-tip device is

re-engaged when the oven is moved.

• Do not operate the oven without the

anti-tip device in place and engaged.

• Failure to follow these instructions can

result in death or serious burns to

children and adults.

Refer to the installation

instructions supplied with

your appliance for proper

installation.

Anti-tip mounting holes

Check for proper installation with a visual

check that the anti-tip screws are present. Test

the installation with light downward pressure

on the open oven door. The oven should not

tip forward.
