ELECTRIC COOKTOP INSTALLATION INSTRUCTIONS
A
F
B
C
D
E
All dimensions are in inches (cm).
Only some models are available in Canada.
*
Allow 2" (5 cm) space below cooktop to clear the electric cable and allow for installation of the
junction box on the wall at the back of the cooktop.
P/N 318205403 (0904) Rev. C
English – pages 1-8
Español – pages 9-16
Français – pages 17-24
Cooktop Dimensions
IMPORTANT INSTALLATION‑INFORMATION
•Allelectriccooktopsrunoffasinglephase,three-wire
orfour-wirecable,240/208volt,60hertz,AConly
electrical supply with ground.
•Pleasenoteminimumdistancesbetweencooktopand
adjacent and overhead cabinetry is 30" (76.2cm).
* 30" (76.2 cm) min. for unprotected cabinet
24" (61 cm) min. for protected surface
Cooktop Cutout Dimensions
Figure 1
30" Min. *
(76.2 cm)
Printed in China
MODELA. LENGTHB. WIDTHC. DEPTH
CUTOUT DIMENSIONS
F. DEPTH
BELOW
COOKTOP*
D. LENGTHE. WIDTH
MIN.MAX.MIN.MAX.
26" Coil Elements25¾ (65.4)21
9
/
16
(54.8)3½ (8.9)25 (63.5)25 (63.5)20½ (52.1)20½ (52.1)5½ (14)
30" Ceramic Glass30
3
/
8
(77.8)21
3
/
8
(54.4)2
5
/
8
(6.7)29
5
/
8
(75.2)29
7
/
8
(75.9)20¼ (51.4)20½ (52.1)5 (12.7)
30" Coil Elements30 (76.2)21½ (54.6)3 (7.6)26¾ (67.9)28¼ (71.8)19
1
/
8
(48.6)20 (50.8)5 (12.7)
32" Ceramic Glass32¼ (81.9)20¼ (51.4)3¾ (9.5)31 (78.7)31¼ (79.4)19 (48.3)19¼ (48.9)5¾ (14.6)
24 (61.0)23 (58.5)23¼ (59.0)
36" Ceramic Glass36¾ (93.5)21
3
/
8
(54.4)2
5
/
8
(6.7)35
5
/
8
(90.5)36
1
/
8
(91.8)20¼ (51.4)20½ (52.1)5 (12.7)
36" Coil Elements
(36" X 18")
36 (91.4)18 (45.7)3
7
/
8
(9.8)34¼ (87)34
3
/
8
(87.3)16
5
/
8
(42.2)16¾ (42.5)5
7
/
8
(14.9)
36" Coil Elements
(36" x 21½")
36 (91.4)21½ (54.6)3 (7.6)32¾ (83.2)34¼ (87)19 (48.3)20 (50.8)5 (12.7)
INSTALLATION AND SERVICE MUST BE PERFORMED
BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR’S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING
FOR YOUR SAFETY: Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of this or any other appliance.
CanadaUnited States
32" Coil Elements32¼ (81.9)20¼ (51.4)3¾ (9.5)31 (78.7)31¼ (79.4)19 (48.3)19¼ (48.9)5¾ (14.6)
24" Ceramic Glass
21
3
/
8
(54.4)
2
5
/
8
(6.7)20¼ (51.4)20½ (52.1)5 (12.7)
