Sida 1/32

TABLE OF CONTENTS

www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352

All about the

Use & Care

of your Wall Oven

Welcome & Congratulations ...................................2

Important Safety Instructions .................................3

Features at a Glance ..............................................5

Before Setting Oven Controls .................................8

Setting Oven Controls ..........................................11

318205312 (April 2011) Rev. B

Self-Cleaning .......................................................24

Care & Cleaning ..................................................26

Before You Call ..................................................29

Major Appliance Warranty ....................................32

WELCOME & CONGRATULATIONS



NOTE

Please attach sales receipt here for future reference.

Please record your model and serial numbers

below for future reference.

Model Number:

Serial Number:

Purchase Date:

Congratulations on your purchase of a new appliance! At

Electrolux Home Products, we are very proud of our

product and are completely committed to providing you

with the best service possible. Your satisfaction is our

number one priority.

We know you’ll enjoy your new appliance and Thank You

for choosing our product. We hope you consider us for

future purchases.

PLEASE CAREFULLY READ AND SAVE THESE

INSTRUCTIONS

This Use & Care Manual contains general operating

instructions for your appliance and feature information

for several models. Your product may not have

all the described features. The graphics shown are

representative. The graphics on your appliance may not

look exactly like those shown. These instructions are not

meant to cover every possible condition and situation

that may occur. Common sense and caution must be

practiced when installing, operating and maintaining any

appliance.

Product Registration

Serial Plate Location

The PRODUCT

REGISTRATION CARD

should be ﬁ lled in completely,

signed and returned to

Electrolux Home Products.

Printed in Canada

Dual fan model shown only.

IMPORTANT SAFETY INSTRUCTIONS

WARNING

This symbol will help alert you to situations that

may cause serious bodily harm, death or property

damage.

IMPORTANT

IMPORTANT indicates installation, operation or

maintenance information which is important but not

hazard-related.

CAUTION

This symbol will help alert you to situations that

may cause bodily injury or property damage.

DEFINITIONS

This is the safety alert symbol. It is used to alert

you to potential personal injury hazards. Obey all safety

messages that follow this symbol to avoid possible injury

or death.

WARNING

• All appliance can tip.

• Injury to persons could result.

• Install anti-tip bracket packed with

your appliance.

• See Installation Instructions.

To reduce the risk of tipping, the

appliance must be secured by properly

installed anti-tip bracket provided

with the unit. Refer to the Installation

Instructions for proper anti-tip bracket

installation.

• User Servicing. Do not repair or replace any part

of the appliance unless speciﬁ cally recommended

in the manuals. All other servicing should be done only

by a qualiﬁ ed technician to reduce the risk of personal

injury and damage to the appliance.

• Never modify or alter the construction of an

appliance such as removal of panels, wire covers

or any other permanent part of the appliance.

• Storage on Appliance. Flammable materials

should not be stored near surface units. This

includes paper, plastic and cloth items, such as

cookbooks, plasticware and towels, as well as ﬂ ammable

liquids. Do not store explosives, such as aerosol cans, on

or near the appliance. Flammable materials may explode

and result in ﬁ re or property damage.

• Remove the oven door from any unused appliance

if it is to be stored or discarded.

WARNING

Stepping, leaning, sitting or pulling down on the

door of this appliance can result in serious injuries

and may also cause damage to the appliance. Do not

allow children to climb or play around the appliance.

• Storage in or on Appliance—Flammable materials

should not be stored in an oven. This includes

paper, plastic and cloth items, such as cookbooks,

plasticware and towels, as well as ﬂ ammable liquids. Do

not store explosives, such as aerosol cans, in or near the

appliance.

WARNING

Do not use the oven for storage.

• Remove all tape and packaging wrap before using

the appliance. Destroy the carton and plastic

bags after unpacking the appliance. Never allow

children to play with packaging material. Do not remove

the wiring label and other literature attached to the

appliance. Do not remove model/serial number plate.

• Proper Installation. Be sure your appliance is

properly installed and grounded by a qualiﬁ ed

technician in accordance with the National

Electrical Code No. 70 - latest edition in the

United States, or CSA C22.1, Part 1 in Canada, and

local code requirements. Install only per installation

instructions provided in the literature package for this

appliance.

Ask your dealer to recommend a qualiﬁ ed technician and

an authorized repair service. Know how to disconnect the

electrical power to the appliance at the circuit breaker or

fuse box in case of an emergency.

CAUTION

Electronic controllers can be damaged by cold

temperatures. When you use your appliance for

the ﬁ rst time, or if it has not been used for a

long period of time, make sure that it has been

exposed to a temperature above 0°C/32°F for at

least 3 hours before connecting it to the power

supply.

Read all instructions before using this appliance.

Save these instructions for future reference.
