Professional On-Line & Line-Interactive UPS Solutions
True Double Conversion 1.0kVA - 20kVA & 30kVA - 800kVA
Output Power Factor 0.9 - Rack/Tower 2 in 1 Design - LCD Display - Perfect Battery Pack
Knight Series Online Rack UPS System
3.0/6.0kVA LCD Display– 1-P In / 1-P Out
with battery bank solution
Knight 3.0 kVARack specially designed to with stand high fluctuation power. Built-in input OVCD, it becomes a rugged UPS to protect your equipment against extreme
high voltage.
Knight 6.0 kVA Rack is a high flexibility UPS with 2-in-1 design which integrates standard backup UPS and long-run UPS into one unit by simply adjusting charging current
via LCD front panel. This high flexibility UPS offers easy-adjustable battery numbers design for diverse applications
Features & Advantages
●
●
●
●
●
●
●
●
●
●
●
True double-conversion
Microprocessor control optimizes reliability
Input power factor correction
Output power factor 0.8
Adjustable charge current suitable for long backup tme
Wide input voltage (110 V – 300 V)
Converter mode available
ECO mode for energy saving
Generator compatible
Smart SNMP works well with either USB or RS-232 together
display allows easy monitoring and access of UPS status
UPS Warranty: 3 years – Battery Bank Warranty: 2 years
Knight 3kVAKnight 3kVA rear viewKnight 6kVAKnight 6kVA rear view
Battery Bank for Knight Rack Series 3.0 kVA UPS
Battery bankBattery TypeBatteriesBank CapacityDimension
BB-72/9RT12V/9Ah6 pcs72V / 9Ah600 x 438 x 88 mm
BB-72/18RT12V/9Ah12 pcs72V / 18Ah600 x 438 x 88 mm
Backup Time: Please see the following Backup Time Table
Battery Bank for Knight Rack Series 6.0 kVA UPS
Battery bankBattery TypeBatteriesBank CapacityDimension
BB-240/9RT12V/9Ah20 pcs240V / 9Ah580 x 438 x 133 mm
Backup Time: Please see the following Backup Time Table
Backup Time Table for Knight Series 3.0/6.0 kVA UPS
Backup Time (min)
UPS Battery Bank100%75%50%
Knight
KN-1103RL
Rack
3.0 kVA
without Internal Battery000
+ 1 BB-72/9RT - 72V / 9 Ah58,312,5
+ 1 BB-72/18RT - 72V / 18 Ah101827
+ 2 BB-72/18RT - 72V / 36 Ah233856
+ 3 BB-72/18RT - 72V / 54 Ah355785
+ 4 BB-72/18RT - 72V / 72 Ah4676113
Knight
KN-1106RL
Rack
6.0 kVA
without Internal Battery00-
+ 1 BB-240/9RT - 240V / 9 Ah819-
+ 2 BB-240/9RT - 240V / 18 Ah3746-
+ 3 BB-240/9RT - 240V / 27 Ah4956-
+ 4 BB-240/9RT - 240V / 36 Ah7984-
PModelkVAFormDatasheetBrochureManualSNMP CardSoftwarePrice
1KN-1103RL3.0 kVA
Rack
PDFPDF
PDFGo to SNMPGo to SoftwarePricelist
2KN-1106RL6.0 kVA
Rack
Specification
ModelKN-1103RLKN-1106RL
Input
Capacity
3.0 kVA / 2,4 kW6.0 kVA / 4,8 kW
Nominal Voltage
200/208/220/230/240 VAC
Voltage Range
110-300 VAC ± 1%
110-300 VAC ± 1% @50% Load
176-300VAC ± 1% @100% Load
Produktspecifikationer
| Varumärke: | FSP/Fortron |
| Kategori: | UPS |
| Modell: | Knight KN-1103RL |
| Vikt: | 10000 g |
| Bredd: | 438 mm |
| Djup: | 480 mm |
| Höjd: | 88 mm |
| LED-indikatorer: | Ja |
| Batterikapacitet: | 9 Ah |
| Certifiering: | IEC 62040-1\r\nIEC-62040-2\r\nCE |
| Uteffekt: | 2400 W |
| Effektfaktor: | 0.99 |
| Effektivitet: | 90 % |
| Rackkapacitet: | 2U |
| Antal ingångsfaser: | 1 |
| Utspänning THD: | 3 % |
| Antal utgångsfaser: | 1 |
| Vågform: | Sinus |
| Antal batterier: | 6 |
| Produktens färg: | Svart |
| Skärmtyp: | LCD |
| Formfaktor: | Rackmonterad |
| Ingångsfrekvens: | 40/70 hz |
| Effekt skyddsfunktioner: | Överbelastning |
| Temperatur vid drift: | 0 - 40 ° C |
| Intervall för relativ operativ luftfuktighet: | 20 - 90 % |
| Batterispänning: | 12 V |
| Ljudnivå Lc IEC: | 50 dB |
| Antal uttag AC: | 4 AC-utgångar |
| Hörbart larm: | Ja |
| Kylning typ: | Aktiv |
| Uteffekt kapacitet (VA): | 3 kVA |
| Inmatning spänning (min): | 110 V |
| Inmatning spänning (max): | 300 V |
| Utgång, driftspänning (min): | 200 V |
| Utgång, driftspänning (max): | 240 V |
| Utgångseffektfaktor: | 0.8 |
| Crestfaktor: | 3:1 |
| AC försäljningsställen: | C13 coupler |
| Utgångsspänningsreglering: | 6 % |
| Uttag: | C20 coupler |
