Marine Radar

MODEL 1824C-BB/

1834C-BB/1934C-BB/

1944C-BB/1954C-BB

OPERATOR'S MANUAL

http://www.furuno.co.jp/

FIRST EDITION : JAN. 2005

( DAMI ) M1804C-BB, GD1920C-BB

Pub. No. OME-35490

(Elemental Chlorine Free)

The paper used in this manual

elemental chlorine free.

MODEL 1824C-BB/1834C-BB/1934C-BB/1944C-BB/1954C-BB, GD-1920C-BB OPERATOR'S MANUAL

Color Video Plotter

GD-1920C-BB

VX2

SAFETY INSTRUCTIONS

WARNING

ELECTRICAL SHOCK HAZARD

Do not open the equipment.

Only qualified personnel

should work inside the

equipment.

Turn off the radar power

switch before servicing the

antenna unit. Post a warn-

ing sign near the switch

indicating it should not be

turned on while the antenna

unit is being serviced.

Prevent the potential risk of

being struck by the rotating

antenna and exposure to

RF radiation hazard.

Wear a safety belt and hard

hat when working on the

antenna unit.

Serious injury or death can

result if someone falls from

the radar antenna mast.

Do not disassemble or modify the

equipment.

Fire, electrical shock or serious injury can

result.

Turn off the power immediately if water

leaks into the equipment or the equip-

ment is emitting smoke or fire.

Continued use of the equipment can cause

fire or electrical shock.

Use the proper fuse.

Fuse rating is shown on the power cable.

Use of a wrong fuse can result in damage

to the equipment.

Keep heater away from equipment.

Heat can alter equipment shape and melt

the power cord, which can cause fire or

electrical shock.

A warning label is attached to the

equipment. Do not remove the label.

If the label is missing or damaged,

contact a FURUNO agent or dealer.

WARNING

To avoid electrical shock, do not

remove cover. No user-serviceable

parts inside.

Name: Warning Label (1)

Type: 86-003-1011-0

Code No.: 100-236-230

WARNING

Radio Frequency

Radiation Hazard

The radar antenna emits electromagnetic

radio frequency (RF) energy which can be

harmful, particularly to your eyes. Never

look directly into the antenna aperture from

a close distance while the radar is in

operation or expose yourself to the trans-

mitting antenna at a close distance.

Distances at which RF radiation levels of

100 and 10 W/m

exist are given in the

table below.

Note: If the antenna unit is installed at a

close distance in front of the wheel house,

your administration may require halt of

transmission within a certain sector of

antenna revolution. This is possible - Ask

your FURUNO representative or dealer to

provide this feature.

MODEL

Distance to

100 W/m

point

Distance to

10 W/m

point

MODEL

1834C-BB

Nil

Worst case

1.80 m

MODEL

1934C-BB

MODEL

1944C-BB

Worst case

0.20 m

Worst case

3.00 m

Nil

Worst case

2.50 m

MODEL

1954C-

Nil

Worst case

2.50 m

Worst case

2.30 m

XN-12A

XN-13A

MODEL

1824C-BB

Nil

Worst case

0.50 m

WarningLabel

TABLE OF CONTENTS

FOREWORD ....................................vi

SYSTEM CONFIGURATIONS .......viii

1. OPERATIONAL OVERVIEW.. 1-1

1.1 Operating Controls..........................1-1

1.1.1 Control unit ..........................1-1

1.2 Inserting a Chart Card ....................1-3

1.3 Turning the Unit On/Off...................1-4

1.4 Adjusting Hue, Panel Illumination...1-5

1.5 Selecting a Display.........................1-6

1.5.1 Display modes .....................1-6

1.5.2 Selecting a display...............1-7

1.5.3 Switching control in

combination and overlay

screens ................................1-8

1.5.4 Selecting image source .......1-9

1.6 Trackball, Cursor...........................1-10

1.7 Entering the MOB Mark,

Setting MOB as Destination ..................1-11

1.8 Data Boxes ...................................1-12

1.8.1 Showing, hiding data boxes

with soft key .......................1-12

1.8.2 Rearranging data boxes ....1-12

1.8.3 Temporarily erasing a

data box .............................1-12

1.9 Function Keys...............................1-13

1.10 Simulation Display........................1-14

2. RADAR OPERATION ............. 2-1

2.1 Radar Display .................................2-1

2.2 Transmitting, Stand-by....................2-1

2.3 Tuning .............................................2-2

2.4 Adjusting the Gain ..........................2-2

2.5 Reducing Sea Clutter .....................2-3

2.5.1 How the A/C SEA works ......2-3

2.5.2 Adjusting the A/C SEA.........2-4

2.6 Reducing Precipitation Clutter........2-4

2.6.1 Adjusting the A/C RAIN .......2-4

2.7 Range Scale ...................................2-5

2.8 Pulselength .....................................2-5

2.9 Presentation Mode..........................2-6

2.9.1 Selecting a presentation

mode....................................2-6

2.9.2 Description of presentation

modes ..................................2-7

2.10 Measuring the Range .....................2-8

2.10.1 Measuring range by

range rings...........................2-8

2.10.2 Measuring range by cursor..2-8

2.10.3 Measuring range by VRM....2-9

2.10.4 Various VRM operations......2-9

2.11 Measuring the Bearing..................2-10

2.11.1 Measuring bearing by cursor....

........................................2-10

2.11.2 Measuring bearing by EBL .......

........................................2-10

2.11.3 Various EBL operations .....2-10

2.12 Erasing the Heading Line,

North Marker.................................2-11

2.13 Reducing Noise Interference........2-11

2.14 Rejecting Radar Interference........2-11

2.15 Zoom.............................................2-12

2.15.1 Zooming radar targets .......2-12

2.15.2 Zooming ARP, TTM targets.......

........................................2-13

2.16 Shifting the Picture........................2-14

2.16.1 Manual shift........................2-14

2.16.2 Automatic shift ...................2-14

2.17 Using the Offset EBL ....................2-15

2.17.1 Predicting collision course.2-15

2.17.2 Measuring range & bearing

between two targets...........2-16

2.18 Echo Trails ....................................2-17

2.18.1 Trail time ............................2-17

2.18.2 Starting echo trails .............2-18

2.18.3 Trail gradation....................2-18

2.18.4 Trail color ...........................2-18

2.18.5 Echo trail mode..................2-19

2.19 Echo Stretch..................................2-19

2.20 Echo Averaging.............................2-20

2.21 Outputting TLL Data......................2-21
