ACTIVE TUBE

SPECIFICATIONS

 CS-AT1100

PeakPower(Watts) 360

RatedPower(Watts) 120

FrequencyResponse 36Hz-250Hz

LowPassFilter(Variable) 40Hz-250Hz

Tuning BassReex

WooferSize 10”

Fuse 20A

Dimensions(mm) 559(l)x306(w)x306(h)

 22-1/32x12-1/16x12-1/16”

CS-AT1100

www.fusionelectronics.com

CONTROL DESCRIPTIONS

LEVEL

Thisallowstheadjustmentoftheamplierlevelofthesubwoofer.

Turnclockwisetoincreasethelevel.Ifthesoundbecomesdistorted

reducethelevel.

LOW PASS FILTER (LPF)

This allows the adjustment of the highest frequency the Active

Tubewillproduce.Thisshouldbeadjustedtoblendwithyourmain

speakers.Typically,thiswillbesettoaround100Hz(approximately

thecentralpositionofthecontrolknob).

REMOTE LEVEL CONTROLLER

Whenconnected,thisallowsfurthercontroloverthelevelfroma

remotelocation,usingthesuppliedlead.

INSTALLATION

Makesure the ActiveTubeis rmlyxed inyour vehicle.Check

beforedrillingorcuttingholes.DONOTworkneargastanks,fuel

lines,hydrauliclinesorelectricalwiring.

DONOTmounttheActiveTubeinsuchawayastopinchordamage

thewires.

Make sure everything is rmly connected, before attaching the

+12Vwire.Ensurethe+12Vwireisfusedascloseaspossibletothe

battery.Alwaysuseafusewiththerecommendedrating.

DISCLAIMER

AlwaysensuretheActiveTubeissecurelyattached,toavoidmovement.FUSIONacceptsnoresponsibilityfordamageorinjuryinrelation

toinappropriatesecuringofthisproduct.

WIRING

• Connectthegroundwiretothevehiclerst(cleandirtandpaint

 tobaremetal).

• Connecttheremoteon(bluewire).

• ConnecttheRCAcablesifapplicable,OR

• Connectthespeakerlevelwirebysplicingintotheheadunits 

 speakerwires.See onreverse.Note1

• Connecttheremotelevelcontrollerwiththesuppliedlead.

• Connectthe12volt(redwire)tothepositivebatteryterminal.

• Checkallconnections.

PUBLISHEDBYFUSIONELECTRONICSLIMITED:©Copyright2010byFUSIONElectronicsLimited.Allrightsreserved.Specicationsanddesignaresubjecttochangewithoutnotice.

YOUCANHELPPROTECTTHEENVIRONMENT!Pleaseremembertorespectthelocalregulations:Handinthenon-workingelectricalequipmenttoanappropriatewastedisposalcenter.

RECORD YOUR PURCHASE DETAILS HERE:

SERIALNUMBER

DATEOFPURCHASE

AFFIXRECEIPTHERE

WARNING:AudioSystemscanproducesoundlevelsover135dB.Continuousexposuretosoundpressurelevelsover100dBmaycausepermanent

hearingloss!Pleasewatchforemergencyvehiclesaswarningsignalsmaynotbeheard.USECOMMONSENSE!

Forfurtherproductandinstallationinformation,pleasevisitwww.fusionelectronics.com

Pourplusd’informationssurlesproduitsetl’installation,rendez-voussurwww.fusionelectronics.com

Paraobtenermásinformaciónacercadelosproductosydesuinstalación,visiteelsitiowebwww.fusionelectronics.com

Bezoekwww.fusionelectronics.comvoormeerproduct-eninstallatie-informatie.

WeitereProdukt-undInstallationsinformationenndenSieunterwww.fusionelectronics.com

Perulterioriinformazionisuiprodottielaloroinstallazione,potetevisitarewww.fusionelectronics.com

Для получения дополнительной информации о продуктах и установке зайдите, пожалуйста, на: www.fusionelectronics.com

Note 1

Takecaretomakesurethewires

aresplicedinthecorrectphase.

Positivetopositive,negativeto

negative.Failuretodothiscorrectly

couldresultinlossofbass.

SeeNote1

Spliceintosource

unit’sspeakerwires

(R+)Grey/White

(R-)Grey

(L+)Green/White

(L-)Green

Connecttheremote

levelcontrollerleadto

theamplier

Connectredwire

topositive(+12V)

batteryterminal

Connectbluewiretosourceunit’s

accessoryleadorswitched12volt

source(REM)

Connectblackwire

tochassisground

ofvehicle(Ground)

SpeakerLevel

InputPlug

RemoteLevelController

VehicleBattery
