OO Quick Start Guide

Included Components

1. HS4 x1

3. Quick Start Guide x1

2. SA-1 Stand Adapter x1

1. 3.2.

Attach the SA-1 to the mic stand

Stand Mounting (Optional)

Lift the HS4 over the stand, align it up

with the hole.

Bring the HS4 down onto the stand

gently until secure.

Setup

Connect one end of a 1/4" cable to

either 1/4" input, and the other end to

your powered ampliﬁer.

To Daisy Chain:

Connect one end of a 1/4" cable to either 1/4" input, and the other end to either 1/4" input on the other HS4. Repeat for any other HS4's being Daisy Chained.

8 Ohms for 2 Hot Spots

5.33 Ohms for 3 Hot Spots

4 Ohms for 4 Hot Spots

(The Total Load)

For more details on

Ohm’s Law, Scan Here:

GAL A X Y AUDIO Quick Start Guide

Included Components

1. HS4 x1

3. Quick Start Guide x1

2. SA-1 Stand Adapter x1

1. 3.2.

Attach the SA-1 to the mic stand

Stand Mounting (Optio nal)

Lift the HS4 over the stand, align it up

with the hole.

Bring the HS4 down onto the stand

gently until secure.

Setup

Connect one end of a 1/4" cable to

either 1/4" input, and the other end to

your powered ampliﬁer.

To Daisy C hain:

Connect one end of a 1/4" cable to either 1/4" input, and the other end to either 1/4" input on the other HS4. Repeat for any other HS4's being Daisy C hained.

8 Ohms for 2 Hot Spots

5.33 Ohms for 3 Hot Spots

4 Ohms for 4 Hot Spots

(The Total L oad)

For more details on

Ohm’s Law, Scan Here:

Specifications subject to change without notice.

V20151123

601 E. Pawnee Wichita, KS 67211 316. 263.2852 FAX 316.263.0642 www.galaxyaudio.com

Distributed in Canada by Audio Distributors International ( ) 1275 Newton, unit 6 Boucherville, QC J4B 5H2 CanadaADI

450.449.8177 FAX 450.449.8180

Other Helpful Sources

HS4

Manual

(PDF Download)

HS4

Product Page

HS4

Cutsheet

(PDF Download)

HS4

How To Video

Quick Start Guide

FAQ

1. Q. How many HS4 can I connect together?

A. It depends on your ampliﬁers rating. If it is rated to run at 4ohms, the maximum number of HS4 is 4, if your amp is

rated to 2 ohms, you could use up to 8 HS4.

Printed in China
