Eng
Español... Página 6
User Manual
Manual
del usuario
RUEDA DE LOS NIÑOS
CHILDREN’S WHEELBARROW
DISTRIBUTED BY DISTRIBUIDO POR:
ALDI INC., BATAVIA, IL 60510
WWW.ALDI.US
USA
2
YEAR WARRANTY
AÑOS DE GARANTÍA
MODEL:
52839 04/2017
AFTER SALES SUPPORT
cs@discoverhomeproducts.com
1855 965 5310
SERVICIO POSVENTA
Identify all the parts packaged in the carton against
the parts list. Remove all protective materials and place
parts on a non-abrasive surface to avoid scratching. If
any parts are missing or damaged, DO NOT attempt to
assemble. Please contact our customer service center
(Monday-Friday 9:00AM-4:00PM ET) at 1855 965 5310.
Contents
Getting Started.................................................... 2
Parts List................................................................. 3
Assembly Instructions....................................... 4
Warranty Information
................................... 11
USA
1855 965 5310
AFTER SALES SUPPORT
2
cs@discoverhomeproducts.com
Children’s Wheelbarrow
USA
Getting Started
!
Caution
Read all the instructions before assembly. Failure to do so
may result in faulty assembly and potential injury! Assemble
product on a soft, non-abrasive surface such as a carpet or
cardboard to avoid damaging the item.
Small parts like bolt caps and bolts, may pose a choking
hazard to young children. Keep out of reach of small children.
ALL bolts should be fully tightened.
Do not place unit near stairways, wall heaters, fireplace,
or any source of extreme heat.
(ADULT ASSEMBLY REQUIRED)
Parts List
Children’s Wheelbarrow
USA
Children’s Wheelbarrow
USA
Assembly Instructions
USA
1855 965 5310
AFTER SALES SUPPORT
cs@discoverhomeproducts.com
3
USA
1855 965 5310
AFTER SALES SUPPORT
4
cs@discoverhomeproducts.com
Part A - 1 Piece
Tray
Handle
Leg Leg Brace
Part B - 2 Pcs Part C - 2 Pcs Part D - 1 Piece
Part E - 2 Pcs
Tray Brace Axle Tube Axle Wheel
Part F - 2 Pcs Part G - 1 Piece Part H - 1 Piece
Note: Do not tighten all the bolts till you finish all the assembly.
HARDWARE BAG:
Part I - 4 Pcs
Bolt (15mm)
Bolt (45mm)
Bolt (60mm) Nut
Part J - 4 Pcs Part K - 2 Pcs Part L - 10 Pcs
Part M - 10 Pcs
Lock- Washer Washer Plastic Cap
Part N - 10 Pcs Part O - 10 Pcs
Tools Required (not included)
1.Slotted screwdriver
1.10mm Wrench
J
I
O
A
A
B
D
C
Step 2: Attach the Leg Brace (D) to the Leg (C) as shown using Bolts (I).
Add Washers (N), Lock-Washers (M) and Nuts (L) then hand tighten.
Step 1: Insert the Bolts (J) through the tray and tape the heads to the inside of
the tray. Turn the tray upside down and place a handle over the two bolts as
shown. Then place a Leg (C) with the hole towards the end of the handle, over
the bolts. Add a Washer (N), Lock-Washer (M) and Nut (L) then hand tighten.
Repeat this procedure with the other handle and leg.
Fig.1
Fig.2
PARTS LIST:
