Sida 1/16
Model No. BQ1050
Model No. BQ1051
Ideal heavy duty BBQ for sporting and social clubs
or anywhere large groups are entertained
Solid 5mm thick steel hotplate
Castors for easy moving
Stainless steel burners
Removable lid that doubles as a windshield
Foldable side shelves
Propane Gas
Gas Certified to Australian and New Zealand Standards
Important: Retain these instructions for future use.
03339 09/17
Gasmate® is a registered trademark of:
Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber, N.Z. www.gasmate.co.nz
CATERER
4 & 6 BURNER BBQ
2
CONTENTS
Section Page
General Information 2-4
Parts List & Hardware List 5-6
Assembly Instructions 7-11
Care & Maintenance 12
Lighting Procedure 13
Burner Operation & Operating Procedure 14
Safe Appliance Locations 15
GENERAL INFORMATION
Gas Installation Codes
• Barbecues must be used in accordance with the
installation requirements of your gas supply authority,
or the appropriate installation code issued by
Standards Australia AS 5601.
• Barbecues for use with bottled gas are labelled
‘Propane Gas’.
• Barbecues for use with natural gas are labelled
‘natural gas’ and must be installed by an authorised
person. Check the gas type sticker attached to the
barbecue.
Clearances
Minimum Clearances from combustible materials
must be:
Rear - 300mm Sides - 300mm Above - 800mm
Hose & Regulator Safety
The regulator and hose assembly supplied with the
barbecue are suitable for Propane Gas only. A gas
regulator adjusted to have an outlet pressure of 2.75kPA
is supplied for connection to the propane gas cylinder.
The pressure regulator and hose assembly supplied
with the barbecue must be used. Replacement pressure
regulators and hose assemblies must be those specified
by the barbecue manufacturer.
When connecting the hose and regulator assembly to the
gas cylinder, take care to avoid unnecessary twisting of
the flexible hose.
After the assembly has been secured, turn on the gas
and check for leaks by brushing a soap and water
solution over all connections.
If you are unable to correct the leak by tightening the
connections, turn off the gas and contact the supplier
immediately.
Always ensure the barbecue is kept away from flammable
materials and the gas cylinder clear of any heat source.
When changing over from an empty gas cylinder to a full
one make sure this procedure is carried out in a flame
free atmosphere.
Specifications
Barbecue specifications can be found on the data label
attached to the barbecue body.
Hose connection thread at gas inlet is 1/4” B.S.P.
3
Gas Cylinder Use & Safety
This is a low pressure barbecue and must only be used
with the hose and regulator supplied. Your barbecue
is designed for use with 4.5Kg or 9Kg gas cylinders
certified to AS 2469.
The gas cylinder should be filled by a reputable gas
supplier and visually inspected and re-qualified at each
filling.
Always check the cylinder collar for the test date status.
Always keep cylinder in an upright position. Always close
the cylinder valve when the barbecue is not in use.
Do not subject gas cylinder to excessive heat.
NEVER STORE YOUR GAS CYLINDER INDOORS.
If you store your barbecue indoors, ALWAYS disconnect
the gas cylinder first and store the cylinder safely outside.
Cylinders must be stored outdoors in a well ventilated
area out of reach of children, and must not be stored in a
building, garage or any other enclosed area.
Location of your Barbecue
DO NOT use your barbecue in garages, porches, sheds,
breezeways, or other enclosed areas. Your barbecue is to
be used OUTDOORS. The barbecue is not intended to be
installed in or on recreational vehicles and/or boats and
should not be placed under any surface that will burn. Do
not obstruct the flow of combustion and ventilation air
around the barbecue housing.
Tools You Will Need
Standard Phillips-head screw driver (or cordless drill and
bits) and Adjustable Spanner.
Check Barbecue for any Damage
Inspect barbecue parts as you proceed with assembly.
Contact your supplier for assistance regarding
replacement of any damaged or missing parts. Do not
assemble or operate a barbecue that appears damaged.
Barbecues for use with gas cylinders are labelled
‘Propane Gas’. Check labelling at the gas connection on
your barbecue.
Protect Children
Keep children away from barbecue during use and until
barbecue has cooled after you have finished.
Do not allow children to operate barbecue.
Always ensure that no sporting or physical activities are
carried out in close proximity to the barbecue during use
and while still hot.
FOR YOUR SAFETY
• Do not store empty or full spare gas cylinders under
or near this or any other appliance.
• Keep the gas hose away from hot surfaces and
protect from dripping grease. Avoid unnecessary
twisting of hose. Visually inspect the hose prior
to each use for cracks, excessive wear or other
damage. Replace the hose if necessary.
• Never test for gas leaks with a lit match or open
flame. Never light barbecue with hood closed or
before checking to ensure the burner tubes are fully
seated over gas valve orifices.
• Never lean over cooking surface when lighting.
• Never alter or modify the regulator or gas supply
assembly.
• This barbecue must not be used indoors.
• Ensure the barbecue is set up on a level and
stable surface.
• Do not move the barbecue while in use or when
hot. Remove the drip tray before moving.
• Do not operate this appliance before leak
checking hoses and gas cylinder connection.
• Do not spray aerosols in the vicinity of this
appliance while it is in operation.
• Do not use or store flammable materials in or near
this appliance.
• Do not place articles on or against this appliance.
