Sida 1/72
Safety Information . . . . . . . . . .2–4
For Australia and New Zealand . . .21
Operating Instructions
Automatic Icemaker . . . . . . . . . . .10
Controls . . . . . . . . . . . . . . . . . . . . .5
Ice and Water Dispenser . . . . . . .11
Shelves, Bins and Racks . . . . . . .6–8
Storage Drawers . . . . . . . . . . . . . . 9
Care and Cleaning . . . . . . .12, 13
Replacing the Light Bulbs . . . . . .13
Installation Instructions . . . .14–16
For Australia and
New Zealand . . . . . . . . . . . . . .22–24
Troubleshooting Tips
Before You Call For Service . . .18–20
Normal Operating Sounds . . . . . .17
EXPORT 197D3352P003 49-60222 09-02 JR
Write your model and serial numbers here:
Model # _____________________
Serial # _____________________
Find these numbers on a label inside
the refrigerator compartment at the top
on the right side behind the controls.
Réfrigérateurs
Côte à côte
Manuel d’utilisation
et d’installation
La section française commence à la page 26
Frigoríficos
Lado a lado
Models 20, 22 and 25
Owner’s Manual and
Installation Instructions
Manual del propietario
e instalación
La sección en español empieza en la página 50
Refrigerators
Side by Side
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
■
■This refrigerator must be properly installed
and located in accordance with the Installation
Instructions before it is used. Also see the How to
Connect Electricity section.
■
■Do not attempt to stand on top of the refrigerator.
Doing so may result in bodily injury or damage to
the refrigerator.
■
■Do not allow children to play with the refrigerator
or tamper with the controls.
■
■Do not allow children to climb, stand or hang on
the shelves in the refrigerator. They could damage
the refrigerator and seriously injure themselves.
■
■Do not touch the cold surfaces in the freezer
compartment when hands are damp or wet.
Skin may stick to these extremely cold surfaces.
■
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■
■In refrigerators with automatic icemakers, avoid
contact with the moving parts of the ejector
mechanism, or with the heating element located
on the bottom of the icemaker. Do not place
fingers or hands on the automatic icemaking
mechanism while the refrigerator is plugged in.
■
■Installation of the icemaker must be done by
a qualified service technician.
■
■Keep fingers out of the “pinch point” areas;
clearances between the doors and between the
doors and cabinet are necessarily small. Be careful
closing doors when children are in the area.
■
■Unplug the refrigerator before cleaning and
making repairs.
NOTE: We strongly recommend that any servicing be
performed by a qualified individual.
■
■Before replacing a burned-out light bulb, the
refrigerator should be unplugged in order to avoid
contact with a live wire filament. (A burned-out
light bulb may break when being replaced.)
NOTE: Turning the freezer control to the position does not0
remove power to the light circuit.
■
■Do not refreeze frozen foods which have thawed
completely.
4
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
HOW TO CONNECT ELECTRICITY
The power cord of this appliance is equipped with
an earthing plug which mates with a standard
earthed wall outlet to minimize the possibility of
electric shock hazard from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly earthed.
Where an unearthed wall outlet is encountered,
it is your personal responsibility and obligation to
have it replaced with a properly earthed wall outlet.
The refrigerator should
always be plugged into
its own individual
electrical outlet.
This provides the
best performance
and also prevents
overloading house
wiring circuits which could cause a fire hazard from
overheated wires. Please refer to the rating plate on
the refrigerator for the correct voltage, wattage and
frequency. If the product plug does not fit your
outlet, the product should be fitted with a new plug.
IMPORTANT: The refitting of electric plugs and cables should
be done by a qualified technician or service agent. In some
countries the refitting of electric plugs and cables is only
permitted when the work is completed by a qualified technician.
If the power supply cord becomes damaged, it must
be replaced by a qualified service agent in order to
avoid a safety hazard.
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull straight
out from the outlet.
Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end.
When moving the refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
Mains lead replacement
If the mains lead on your refrigerator needs
replacing at any time, it must be replaced by a
special lead which is obtainable from your local
dealer. A charge will be made for the replacement
of the mains lead if you have damaged the lead.
The refrigerator must be positioned so that the plug
is accessible.
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Insure proper earthing
exists before using.
Earthing plug
5
Initially, set the refrigerator compartment control at and the freezer control 5
at 5and allow 12 hours for the temperature to stabilize.
Several adjustments may be required. Adjust the controls one increment at
a time, and allow 12 hours after each adjustment for the refrigerator to reach
the temperature you have set.
Setting the freezer control to stops cooling in both the refrigerator and0
freezer compartments but does not shut off electrical power to the refrigerator.
Control settings will vary based on personal preferences, usage and
operating conditions, and may require more than one adjustment.
9 IS COLDEST0 IS OFF
FREEZER FRESH FOOD
5
8
9
4
3
2
1
0
6
7
5
8
9
4
3
2
1
6
7
About the controls on the refrigerator.
Ambient Room Temperature Limits
This refrigerator is designed to operate in ambient temperatures specified by
its Temperature Class, which is marked on the rating plate.
Temperature Symbol Ambient Temperature
Class Maximum Minimum
Extended-
Temperate SN 32°C 10°C
Temperate N 32°C 16°C
Subtropical ST 38°C 18°C
Tropical T 43°C 18°C
NOTE: Internal temperature may be affected by such factors as the location of the refrigerator,
ambient temperature and frequency of door openings. Adjust temperature controls as required
to compensate for these
factors.
9 IS COLDEST
0 IS OFF
The controls will look like one of the following:
Deep Door Shelves
Detachable shelf extenders deepen and
enclose fixed door shelves, providing more
storage room and greater storage flexibility.
To remove: Lift the shelf extender straight up
then pull out.
To replace: Engage the shelf extender in the
molded supports on the door and push in.
It will lock in place.
Quick Space Shelf (on some models)
This shelf splits in half and slides under itself
for storage of tall items on the shelf below.
Slide-Out Spillproof Shelf (on some models)
The slide-out spillproof shelf allows you to
reach items stored behind others. The special
edges are designed to help prevent spills from
dripping to lower shelves.
Make sure you push the shelves all the way back in
before you close the door.
Spillproof Shelves (on some models)
Spillproof shelves have special edges to help
prevent spills from dripping to lower shelves.
7
8
About the additional features.
Not all features are on all models.
ShelfSaver™Rack
Use this rack to store beverage cans for
easy access.
It can also hold a 22 cm x 33 cm baking
dish.
Loading the Freezer Compartment
Load so that at least 15 mm of space remains
clear between stacks of packages and 15 mm
to 25 mm of space between the top of any
stack and any shelf or basket above it.
Packages may hang over the front of shelves
but must remain 15 mm from doors.
■Food to be frozen must not be placed
in direct contact with food in storage.
If food is to be frozen every day, it may
be necessary to reduce the quantity to
be frozen.
■If a quantity of food needs to be frozen,
set the freezer control to its coldest setting.
After the food is frozen, reset the freezer
control to its initial position.
■Food is most quickly frozen on the middle
three shelves of the freezer compartment
and most slowly in the freezer door
shelves.
■Do not store commercially quick-frozen
food longer than the time recommended
by the food manufacturers.
■If the power to the appliance is shut off for
an extended time or if the refrigerating
system fails, do not open the doors unless
absolutely necessary. When it is necessary,
close them as quickly as possible so the
frozen food will stay frozen as long as
possible.
■The freezer door storage shelves marked
with a two-star label are only appropriate
for the storage of previously frozen food.
Effervescent drinks should not be stored in the
freezer compartment.
Freezer Performance
This Refrigerator/Freezer has an overall
“Four Star” rating.
Freezer performance is classified by star
ratings defined by ISO 8561 STANDARD
AND SUMMARY BELOW:
However, these limited areas have a two star
rating as permitted by the standard:
CODE
or
FREEZING–LOAD TEMP.
(FOOD TEMPERATURE)
Below -6°C.
Below -12°C.
Below -18°C.
Models Location of Freezer Shelves
20, 22 Without icemaker: All freezer door shelves.
20,22 With icemaker: All freezer door shelves and
the shelf above the ice bucket.
25 With icemaker: All freezer door shelves.
Load Limiting Line:
On models 20 and 22, frozen food packages should
not be loaded above the load limiting line located at
the back of the freezer compartment.
9
About the storage drawers.
Not all features are on all models.
Storage Drawers
Excess water that may accumulate in the
bottom of the drawers should be wiped dry.
Adjustable Humidity Drawers
Slide the control all the way to the High
or setting to provide high humidity
recommended for most vegetables.
Slide the control all the way to the Low or
setting to provide lower humidity levels
recommended for most fruits.
Adjustable Temperature Drawer
The adjustable temperature drawer has its
own cold air duct to allow a stream of cold
air from the freezer compartment to flow
around the drawer.
The variable temperature control regulates
the air flow from the freezer compartment.
Set control lever to convert the drawer up
to normal refrigerator temperature. Cold air
duct is turned off. Variable settings between
these extremes can be selected.
Set control lever down to the coldest setting
to store fresh meats. If lever is left in meat
position for a long period of time, some frost
may form on the inside of the drawer.
Normal
Coldest
Divider
Trivet
Trivet and Divider (on some models)
The trivet is designed to keep your fruits and vegetables off
the floor of the drawer and away from any moisture that
might form. The divider will keep the larger fruits and
vegetables from falling or rolling onto the more delicate
ones. By lifting straight up on the divider, you can detach it
from the trivet and adjust it from side to side, then push
down and into position.
About storage drawer removal.
Not all features are on all models.
Drawer Removal
Drawers can easily be removed by tilting up
slightly and pulling past stop location.
If the door prevents you from taking out
the drawers, the refrigerator will need to
be rolled forward until the door opens
enough to slide the drawers out. In some
cases, when you roll the refrigerator out,
you will need to move the refrigerator to
the left as you roll it out.
When replacing the drawers, make
sure you slide them through the
drawer guides.
Drawer
Guides
10
Automatic Icemaker (on some models)
The icemaker will produce seven cubes
per cycle—approximately 100–130 cubes
in a 24-hour period, depending on freezer
compartment temperature, room
temperature, number of door openings
and other use conditions.
If the refrigerator is operated before the
water connection is made to the icemaker,
set the power switch in the O position.
When the refrigerator has been connected
to the water supply, set the power switch to
the position.I
The icemaker will fill with water when it
cools to freezing. A newly-installed
refrigerator may take 12 to 24 hours to
begin making ice cubes.
You will hear a buzzing sound each time the
icemaker fills with water.
Throw away the first few batches of ice to
allow the water line to clear.
Be sure nothing interferes with the sweep
of the feeler arm.
When the bin fills to the level of the feeler
arm, the icemaker will stop producing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes will
become cloudy, taste stale and shrink. If the
ice cubes become stuck in the icemaker, turn
off the icemaker, remove the cubes and turn
the icemaker back on.
WARNING: Connect to potable water supply
only. Installation of the icemaker must be
done by a qualified service technician.
There is an upper freezer shelf
above the icemaker that can be
used for storage.
Ice Storage Drawer
Icemaker Accessory Kit
To access ice, pull the drawer out.
To remove the drawer, pull it straight out
and lift it past the stop location.
If your refrigerator did not come already
equipped with an automatic icemaker,
an icemaker accessory kit is available at
extra cost.
Check the back of the refrigerator for the
specific icemaker kit needed for your model.
WARNING: Connect to potable water supply
only. Installation of the icemaker must be
done by a qualified service technician.
Icemaker
Feeler Arm
Power
Switch
Green
Power Light
About the automatic icemaker.
A newly-installed refrigerator may take 12–24 hours to begin making ice.
11
About the ice and water dispenser.
On some models
Ice Storage Drawer
on Dispenser Models
To remove:
Set the icemaker power switch to the
Oposition. Pull the drawer straight out
and then lift past the stop position.
To replace:
When replacing the drawer, make sure to
push it firmly into place. If it does not go
all the way back, remove it and rotate the
drive mechanism 1/4 turn. Then push the
drawer back again.
Rotate
Drive
Mechanism
Important Facts About Your Dispenser
■Do not add ice from trays or bags to
the storage bin. It may not crush or
dispense well.
■Avoid overfilling glass with ice and use
of narrow glasses. Backed-up ice can jam
the chute or cause the door in the chute
to freeze shut. If ice is blocking the chute,
poke it through with a wooden spoon.
■Beverages and foods should not be quick-
chilled in the ice storage bin. Cans, bottles
or food packages in the storage bin may
cause the icemaker or auger to jam.
■Some crushed ice may be dispensed even
though you selected CUBED ICE. This
happens occasionally when a few cubes
have been left in the crusher.
■After crushed ice is dispensed, some water
may drip from the chute.
■Sometimes a small mound of snow will
form on the door in the ice chute. This
condition is normal and usually occurs
when you have dispensed crushed ice
repeatedly. The snow will eventually
evaporate.
CAUTION: Some products such as water ices should
not be consumed too cold.
To Use the Dispenser
Select CUBED ICE , CRUSHED ICE or
WATER .
Press the glass gently against the top of the
dispenser cradle.
The spill shelf is not self-draining. To reduce
water spotting, the shelf and its grille should
be cleaned regularly.
If no water is dispensed when the refrigerator is first
installed, there may be air in the water line system.
Press the dispenser arm for at least two minutes to
remove trapped air from the water line and to fill the
water system. To flush out impurities in the water
line, throw away the first six glassfuls of water.
CAUTION: Never put fingers or any other
objects into the ice crusher discharge opening.
Locking the Dispenser (on some models)
Press the LOCK CONTROL
pad for 3 seconds to lock
the dispenser and control
panel. To unlock, press
and hold the pad again
for 3 seconds.
Dispenser Light
This pad turns the night
light in the dispenser on
and off. The light also
comes on when the
dispenser cradle is pressed.
If this light burns out, it
should be replaced with
a 6 watt maximum, 12 volt
DC bulb.
Spill Shelf
Produktspecifikationer
| Varumärke: | GE |
| Kategori: | kylskåp |
| Modell: | RSG25KEMFWW |
Behöver du hjälp?
Om du behöver hjälp med GE RSG25KEMFWW ställ en fråga nedan och andra användare kommer att svara dig
kylskåp GE Manualer
10 September 2025
10 September 2025
10 September 2025
10 September 2025
20 Augusti 2025
19 Augusti 2025
19 Augusti 2025
14 Augusti 2025
13 Augusti 2025
13 Augusti 2025
kylskåp Manualer
- Curtiss
- Continental Edison
- Edgestar
- Orbegozo
- Rex
- Novy
- Thermo-Kool
- Schmick
- Inoksan
- Airflo
- Landmark
- NewAir
- Lemair
- Gasmate
- WhiteLine
Nyaste kylskåp Manualer
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
23 Oktober 2025
21 Oktober 2025
21 Oktober 2025
20 Oktober 2025
20 Oktober 2025
