An overview of the tripod:
Each leg of the tripod can be adjusted in three different angles to meet
different shooting requirements, as shown in the direction, press the angle
control button, at the same time, move the leg to the corresponding angle,
and release the control button.
Angle regulation:
Press
Unlock the cantral column in the direction a, stretch to the appropriate
position in direction b, and finally rotate the central column lock along
direction c.
CT28X USE MANUAL
Ball Head details:
Inverted installation of central column:
Extension of leg:
Back folding of tripod:
Monopod function:
Rotate the hook knob in the direction a shown, pull out the hook in direction
b, and unlock the central column according to direction c. Pull out the central
column along the direction d, insert the central column according to direction
e, lock the central column according to direction f, finally install the hook back
and finish the inversion.
In the direction of the diagram a, at the same time or separately, rotate
the leg locking mechanism, then pull the leg out to your desired length,
and then, in the direction of the diagram c, rotate the leg locking
mechanism and lock it.
A leg in the tripod can be removed and connected to the central column
for using as a monopod.
After all the legs are retracted and locked, as shown in the diagram a,
press the angle adjustment button. At the same time, move the leg to the
reverse side to realize the back folding according to the direction b of the
illustration. Make the tripod to the smallest size, easy to carry.
Central column adjustment:
Platform Locking Knob
MountingPlatform
36mmBallJoint
BodyOuter
360PanningScale°
HeadLockingKnob
HeadLockingKnob
SeparatePanningLock
14fastmounting/"
Platescrews
Switchingplatform
Centralshaft
lockingknob
Footjoint
Spongecasing
Tightenthewrench
ofthefoottube
Cloudhead
Angleadjusting
button
Foottube
Axis
Couple
