Sida 1/4
USER MANUAL
SpectroLED
BATON-BAT
RECHARGEABLE BATTERY HANDLE
FOR BATON-20 AND BATON-34
SpectroLED Rechargeable Battery Handle for Baton - USER MANUAL
2
BATON-BAT
OVERVIEW
4-pin connector
Locking ring
Battery indicator lights
Bottom Cap
Battery indicator button
Power input
socket
1/4-20 socket
Power indicator
Red - charging
Green - fully charged
SpectroLED Rechargeable Battery Handle for Baton - USER MANUAL
3
ATTACHING THE BATTERY
HANDLE TO THE BATON
REPLACING THE
POWER CELL
PRODUCT
SPECIFICATIONS
1. Unscrew the bottom cap, and
remove the spent power cell.
2. Insert the new power cell with the
battery contact facing inward.
Battery Type: Rechargeable lithium-ion
Output: 2600 mAh, 22.2 V
Runtime: Baton-20: approximately 2 hr.
Baton-34: approximately 1 hr.
Charge Time: Approx. 5 hr.
Construction: Metal
Length: 9 in. (22.8 cm)
Weight: 1.4 lb. (648 g)
1. Align the XLR connector with the
pins on the bottom of the Baton.
2. Press the battery pack onto the
Baton, and turn the locking ring
clockwise to tighten until secure.
To check the remaining power in the battery
pack, press and hold the power indicator.
4 lights Fully charged
3 lights 75%
2 lights 50%
1 light 25% or less. Recharge the battery.
