Sida 1/14

BIOS Setup Manual

BIOS Setup

BIOS (Basic Input and Output System) is a UEFI interface that allows you to setup and configure your system for optimum use.

Using your mouse and keyboard, users can change BIOS settings, monitor CPU temperature, select the boot device priority and

view system information such as the CPU name, DRAM capacity, and the BIOS version.

To access the BIOS setup program, press the <Delete> key during the POST (Power-On Self-Test) when the power is turned on.

BIOS Setup Program Function Keys

< >< > ↑ ↓

Move the selection bar to select an item

< >< > ← →

Move the selection bar to select the screen

<Enter> or <Double Click> Execute command or enter the submenu

<Esc> or <Right Click> Main Menu: Exit the BIOS Setup program

Submenus: Exit current submenu

<+> Increase the numeric value or make changes

<-> Decrease the numeric value or make changes

<F1> General Help

<F2> Restore the previous BIOS settings for the current submenus

<F3> Load the Optimized BIOS default settings for the current submenu

<F4> Save all the changes and exit the BIOS Setup program

Main

This setup page includes all the items in standard compatible BIOS

Advanced

This setup page includes all the items of BRIX enhanced features.

Chipset

Platform Controller Hub additional features configuration.

Security

Change, set or disable supervisor and user password. Configuration supervisor password allows you to restrict access to the

system and BIOS Setup.

A supervisor password allows you to make changes in BIOS Setup.

A user password only allows you to view the BIOS settings but not to make changes.

Boot

This setup page provides items for configuration of boot sequence.

Save & Exit

Save all the changes made in the BIOS Setup program to and exit. (Pressing can also carry out this task.)<F10>

Abandon all changes and the previous settings remain in effect. Pressing to the confirmation message will exit BIOS Setup. <Y>

(Pressing can also carry out this task.) <Esc>

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	Skrivbord
Modell:	GB-BXA8-5545
Produkttyp:	Mini-PC, barebone
Strömförsörjning:	100 - 240V AC
Processorfamilj:	AMD A
Wi-Fi:	Ja
Bluetooth-version:	4.0
Ljudsystem:	Realtek ALC269
Antal HDMI-portar:	1
Hörlursutgångar:	1
Processor:	A8
Maximalt internminne:	16 GB
S/PDIF-utgång:	Ja
Mini PCI Express-kortplatser:	1
Kompatibla processorer:	AMD A
Antal processorer som stöds:	1
Minnestyper som stöds:	DDR3-SDRAM
Antal minnesplatser:	2
Produktens färg:	Svart
Nätverksegenskaper:	802.11b/g/n
Antal LAN (RJ-45) anslutningar:	1
Produktstorlek (BxDxH):	107.6 x 114.4 x 29.9 mm
processorsockel:	Socket FP2 (µBGA-827)
Nätverksansluten (Ethernet):	Ja
På / av-knapp:	Ja
Minnesplatser, typ:	SO-DIMM
Minnets hastigheter:	1333 MHz
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	4
LAN-styrenhet:	Realtek RTL8111G
Processorkärnor:	4
Bluetooth:	Ja
Externa anslutningar:	mSATA
Gränsssnitt för panelmontering:	75 x 75, 100 x 100 mm
Processorlitografi:	32 nm
Grafikadapterfamilj:	AMD
Ombord grafikkort modell:	AMD Radeon HD 8510G
Ombord grafikkort:	Ja
Chassityp:	Miniatyrdator (nettop)
Antal strömförsörjningsaggregat:	1
Antal processorer installerade:	1
Antal Mini Displayportar:	1
Processorfrekvens (max):	2.7 GHz
