Sida 1/20

GC-TITAN RIDGE 2.0

Installation Guide/安裝指南/安装指南

12WE6-TITAR2-00AR

For more product details, please visit GIGABYTE's website.

To reduce the impacts on global warming, the packaging materials of this product

are recyclable and reusable. GIGABYTE works with you to protect the environment.

- 2 -

Chip  Intel

DSL7540 Thunderbolt

™

3 Controller

Back Panel

Connectors

 1 x DisplayPort, supporting a maximum resolution of 8K

(7680x3840)@60 Hz

(Note 1) (Note 2)

* Support for DisplayPort 1.4 version, HDCP 2.2, and HDR.

 2 x Thunderbolt

™

3 out ports (Thunderbolt

™

3 Port 1/Thunderbolt

™

3 Port 2), supporting up to 40 Gbps bandwidth and a maximum

display resolution of 8K (7680x3840)@60 Hz

(Note 1) (Note 2)

 2 x Mini-DisplayPort In ports (DP_IN1/DP_IN2)

Internal

Connectors

 2 x 6-pin PCIe power connectors

 1 x USB 2.0/1.1 header

 1 x 5-pin Thunderbolt

™

header

 1 x 3-pin Thunderbolt

™

header

Interface  PCIe 3.0 interface (PCIe x4)

Data Transfer

Rate

 40 Gbps Bi-directional per port

Supported

Operating Systems

 Support for Windows 10 (64-bit) with RS3 or later

Compatible

Motherboards



Go to GIGABYTE’s website for the latest motherboard support list.

Product Specication

(Note 1) Actual resolutions supported are dependent on the graphics card being used.

(Note 2) Due to hardware limitations, the DisplayPort connector, Thunderbolt

™

3 connector 1, and

Thunderbolt

™

3 connector 2 require signal input from external devices and support up to

two display outputs at a time.

- 3 -

晶片  Intel

DSL7540 Thunderbolt

™

3 控制器

後方面板裝置

連接插座

 1個DisplayPort輸出插座，可支援至最高8K(7680 x 3840)@60 Hz

的解析度

(註一)(註二)

* 支援DisplayPort 1.4版本、HDCP 2.2及HDR。

 2個Thunderbolt

™

3輸出插座(Thunderbolt

™

3插座1/Thunder-

bolt

™

3插座2)，最高可支援40 Gbps傳輸速度，螢幕可支援

至最高8K(7680 x 3840)@60 Hz的解析度

(註一)(註二)

 2個Mini-DisplayPort輸入插座(DP_IN1/DP_IN2)

內接插座  2個6-pin PCIe電源插座

 1個USB 2.0/1.1插座

 1個5-pin Thunderbolt

™

插座

 1個3-pin Thunderbolt

™

插座

介面  PCIe 3.0 介面(PCIe x4)

資料傳輸速度  每埠可支援至最高40 Gbps雙向傳輸速度

支援作業系統  支援Windows 10 (64-bit) RS3(含)以上版本

可相容主機板  請至技嘉網站查詢有關支援的主機板列表

產品規格

(註一) 實際所支援的解析度會依您所使用的顯示卡而有不同。

(註二) 由於硬體限制，DisplayPort插座、Thunderbolt

™

3插座1和Thunderbolt

™

3插座2 需要

外部輸入訊號，並且同時只支援兩個顯示輸出。

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	moderkort
Modell:	GC-TITAN RIDGE
Värdgränssnitt:	PCIe
Bandbredd:	40 Gbit/s
Harmonized System (HS)-kod:	84733020
Intern:	Ja
Kretsar:	Intel DSL7540
Antal:	1
Utgränssnittet:	Mini DisplayPort, DisplayPort, Thunderbolt 3
Expansionskortets standard:	PCIe 3.0
