Sida 1/26

NVIDIA

Graphics Accelerator

User's Manual

Rev. 101

mitted in any form without the expressed, written permission of .GBT

Trademarks

Third-party brands and names are the properties of their respective owners.

Notice

Please do not remove any labels on this graphics card. Doing so may void the warranty of this card.

Due to rapid change in technology, some of the specications might be out of date before publication of this this

manual.The author assumes no responsibility for any errors or omissions that may appear in this document nor does

the author make a commitment to update the information contained herein.

Rovi Product Notice:

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual

property rights.Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended

for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering

or disassembly is prohibited.

- 2 -

Table of Contents

1. Introduction ..................................................................................................................3

1.1. Minimum System Requirements .................................................................................... 3

2. Hardware Installation ...................................................................................................5

2.1. SLI Technology .............................................................................................................. 5

3. Software Installation ....................................................................................................7

3.1. Driver and Utility Installation .......................................................................................... 7

3.1.1. Driver Installation ..............................................................................................................7

3.1.2. GIGABYTE Easy Boost on Driver Disk ...........................................................................9

3.2. Display Properties Pages ........................................................................................ 12

3.3. Accessing NVIDIA Control Panel ............................................................................. 13

4. Troubleshooting Tips .................................................................................................21

5. Appendix ....................................................................................................................22

5.1. Regulatory Statements ................................................................................................ 22

- 3 - Introduction

1. Introduction

1.1. Minimum System Requirements

Hardware•

- Intel

Pentium

4 or AMD Athlon

XP class

- 2GB system memory (4GB recommended)

- Optical drive for software installation (CD-ROM or DVD-ROM drive)

Operating System•

- Windows

Vista

- Windows

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	Grafikkort
Modell:	GeForce GTX 770
Bredd:	129 mm
Djup:	292 mm
Höjd:	43 mm
Processorfrekvens:	1046 MHz
Maximal upplösning:	4096 x 2160 pixlar
Antal HDMI-portar:	1
Full HD:	Ja
Minneskapacitet:	256 bit
NVIDIA 3D Vision:	Ja
Grafikprocessorfamilj:	NVIDIA
Grafikprocessor:	GeForce GTX 770
PhysX:	Ja
FireStream:	Nej
bruksanvisning:	Ja
Antal displayportar:	1
Maximal digital upplösning:	4096 x 2160 pixlar
Formfaktor:	Full-Height/Full-Length (FH/FL)
DirectX-version:	11.1
OpenGL-version:	4.3
Temperatur vid drift:	0 - 95 ° C
Gränssnittstyp:	PCI Express 3.0
Mac-kompatibel:	Nej
Antal DVI-D anslutningar:	1
Inbyggd TV mottagare:	Nej
Minne klockhastighet:	7010 MHz
Minneskapacitet, diskret grafikkort:	4 GB
Grafikkortets minnestyp:	GDDR5
Lägsta systemströmförsörjning:	600 W
Kylning typ:	Aktiv
Dual Link-DVI:	Ja
Antal DVI-I anslutningar:	1
CUDA:	Nej
Klockhastighet vid processor-boost:	1085 MHz
Max antal skärmar per grafikkort:	4
Fästets höjd:	Full-Height (FH)
Kompletterande strömkontakter:	1x 6-pin, 2x 8-pin
Antal DVI-anslutningar:	2
