NVIDIA

Graphics Accelerator

User's Manual

Rev. 105

mitted in any form without the expressed, written permission of GBT.

Trademarks

Third-party brands and names are the properties of their respective owners.

Notice

Please do not remove any labels on this graphics card. Doing so may void the warranty of this card.

Due to rapid change in technology, some of the speciﬁ cations might be out of date before publication of this this

manual.The author assumes no responsibility for any errors or omissions that may appear in this document nor does

the author make a commitment to update the information contained herein.

Rovi Product Notice:

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual

property rights.Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended

for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering

or disassembly is prohibited.

- 2 -

Table of Contents

1. Introduction ..................................................................................................................3

1.1. Minimum System Requirements .................................................................................... 3

2. Hardware Installation ...................................................................................................5

2.1. SLI Technology .............................................................................................................. 5

3. Software Installation ....................................................................................................7

3.1. Driver and Utility Installation .......................................................................................... 7

3.1.1. Driver Installation ..............................................................................................................7

3.1.2. GIGABYTE OC Guru II .....................................................................................................9

3.2. Display Properties Pages ........................................................................................ 19

3.3. Accessing NVIDIA Control Panel ............................................................................. 20

4. Troubleshooting Tips .................................................................................................28

5. Appendix ....................................................................................................................29

5.1. Regulatory Statements ................................................................................................ 29

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	Grafikkort
Modell:	GV-N690D5-4GD-B
Bredd:	111 mm
Djup:	279 mm
Höjd:	38 mm
Antal ugnar:	5.0
Processorfrekvens:	915 MHz
Maximal upplösning:	- pixlar
HDCP:	Ja
HDMI:	Ja
Minneskapacitet:	512 bit
NVIDIA 3D Vision:	Ja
Grafikprocessorfamilj:	NVIDIA
Grafikprocessor:	GeForce GTX 690
Minnesbandbredd (max):	384 GB/s
CUDA-kärnor:	3072
PhysX:	Ja
Antal slots:	2
Maximal digital upplösning:	2560 x 1600 pixlar
Formfaktor:	Full-Height/Full-Length (FH/FL)
Windows-operativsystem som stöds:	Ja
Mac-operativsystem som stöds:	Nej
DirectX-version:	11
OpenGL-version:	4.2
Strömförbrukning (vanlig):	300 W
Maximal arbetstemperatur:	98 ° C
Manual:	Ja
Linux operativsystem som stöds:	Ja
Mac-kompatibel:	Nej
Antal DVI-D anslutningar:	1
Inbyggd TV mottagare:	Nej
Minne klockhastighet:	6008 MHz
Grafikadapterfamilj:	NVIDIA
Minneskapacitet, diskret grafikkort:	4 GB
Maximal analog upplösning:	2048 x 1536 pixlar
Grafikkortets minnestyp:	GDDR5
Lägsta systemströmförsörjning:	650 W
Kylning typ:	Aktiv
Dual Link-DVI:	Ja
Antal DVI-I anslutningar:	2
Antal processorer installerade:	2
Stöd för parallellprocessteknik:	Quad-GPU SLI
Antal Mini Displayportar:	1
CUDA:	Ja
Klockhastighet vid processor-boost:	1019 MHz
Max antal skärmar per grafikkort:	4
Fästets höjd:	Full-Height (FH)
Kompletterande strömkontakter:	2x 8-pin
Grafikkort RAMDAC:	400 MHz
Stream-processorer:	3072
Texture Fill Rate (TFR):	234 GT/s
