Poseidon 310

English User’s Manual

GZ-AA3CB-SJS / SJB

English

Thank you for purchasing

GI G ABY T E Tec h. t he r mal

product. GIGABYTE Tech. is

dedicated to the integration

of casing water/air- cooling

s o l u t i o n t e c h n o l o g y t o

provide users with the most

optimal solution for thermal

d i s s i p a t i o n . Fo r f u r t h e r

information and specifications

of the “Poseidon” series, please

visit GIGABYTE Tech. website.

(http://www.gigabyte.com.tw)

The following are not covered by the warranty:

1. Using the product incorrectly or in a manner other than the designed

purpose.

2. Nonobservance of the proper operation provided

3. Malfunction due to interference from other devices

4. Unapproved modification of the product

5. Consequential damage to other devices due to the product’s fault.

6. Malfunction arising from natural hazards, e.g. earthquake, lightning,

fire, and floods.

7. The product’s warranty label has been removed or damaged.

8. The devices inside, including power supply, hard disk, CD-ROM

drive, motherboard, ventilator, etc, are not detached from the

casing prior to transportation of the computer system, resulting in

damage to the casing or other computer-related devices.

9. Any loss/damage caused by failure to follow the installation process

with in the user manual.

Failure to wear gloves during installation of computer

products may cause bodily harm or damage to your

devices. Incorrect connector installation may possibly

burn out the motherboard and other components. Be

sure to observe the instructions in installation manual.

English

Table of Contents

1. Components Introduction 3

1-1 Casing’s Internal Structure 4

1-2 Front, Rear, and Left Side Panel Structure 5

1.3 Removal of Side and Front Panel 5

2. Features 6

3. Specifications 7

4. Installation Instruction 8

4-1 Installation of Power Supply 8

4-2 Installation of Motherboard 8

4-3 Installation of Add-on Card 9

4-4 Installation of Front Multi-Media I/O port 10

4-5 Connection of Fan Power Cables 11

4-6 Installation of 5.25” Front Device Bay 11

4-7 Installation of 3.5” Front Device Bay 12

4-8 Installation of 3.5” Internal Device Bay 12

4-9 Foot Supports 13

4-10 Liquid Cooling System Support 13

4-11 Recommended Cooling Products 14

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	dator box
Modell:	Poseidon 310
Vikt:	8800 g
Bredd:	200 mm
Djup:	505 mm
Höjd:	440 mm
Ljudutgång:	Ja
Material:	Gjuten aluminium
Modell:	PC
Expansionsplatser:	7
Produktens färg:	Silver
Formfaktor:	Midi Tower
Antal USB 2.0 anslutningar:	2
Ljudanslutning:	Ja
Som stöds moderkorts formfaktorer:	ATX
Anta IEEE 1394/Firewire anslutningar:	1
Externa expansionsfack:	5 x 5.25", 2 x 3.5"
Interna expansionsfack:	3 x 3.5"
