GIGABYTE Q2532 Series Notebooks User’s Manual

Date Issued: 2011/05

This manual takes you, step by step, through setting up and using your new Notebook PC. Information in this manual has been carefully

checked for accuracy and is subject to change without prior notice.

No part or parts of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic,

mechanical, by photocopy, recording, or otherwise, without prior written consent.

Trademarks

Product names used herein are for identication purposes only and may be the trademarks of their respective companies.

Microsoft

and Windows

are trademarks of the Microsoft Corporation.

Intel

is the registered trademarks of Intel Corporation.

NVIDIA

and GeForce

are trademarks of NVIDIA Corporation.

All other brands or product names mentioned in this manual are trademarks or registered trademarks of their respective companies.

English

General Safety Precautions

In order to ensure your safety and the safety of your notebook, we ask

that your carefully follow these safety precautions.

CAUTION: Using your notebook for long periods of time, with

the base resting directly on exposed skin, can cause injury,

burns or discomfort from the heat buildup that is generated from

the base of your portable computer.

● After removing the notebook from thebox,pleaseensurethatall

packaging materials are kept out of the reach of small children as

they can cause a potential choking hazard. The packaging materials

should be safely stored away in the event that it may be used again

for safe transportation of the notebook.

● EnsurethattheACAdapterandpowercable areplacedinasafe

area where it cannot be tripped over or stepped on. The AC Adapter

should be situated in a well ventilated area and should have nothing

resting on or covering it.

● Before turningonthe notebook, ensurethat it is placedonalevel

surface with at least 10 cm of clearance around the air vents, which

will aid in proper cooling.

● Donotobstructthe airvents ofthenotebookanddonot insertany

foreign objects into this space. Doing this may cause a short circuit

or may cause the CPU fan to malfunction, resulting in the risk of a

reorelectricshock.Thismayeventuallyrenderpermanentdamage

to the notebook.

● Donotepressortouchthedisplaypanel.

● Only use theACAdapter that is provided with the notebook or

that which is recommended by the manufacturer. Using non-

recommended or non-approved parts may cause damage or increase

theriskofareorexplosion.IntheeventthatanotherACAdapteris

required, advice should be sought from a GIGABYTE service agent,

in order to make sure that the correct part is recommended.

● Pleasefollowthebatteryinstallationguidelines.Incorrectinstallation

ofbatteriesmayincreasetheriskofareorexplosion.

● Onlyreplaceoldbatterieswiththesameoranalternativecompatible

battery that is recommended by GIGABYTE or an authorized

GIGABYTE Service Centre.

● Beforeconnectingthenotebooktothepoweroutlet,makesurethat

the voltage rating of the AC Adapter is compatible with the power

specicationinthecountrywhere youare located.Adetailedlistof

thepowerspecicationfordifferentcountriescanbefoundonPage

23~26.

● Whenusinganextensioncord,pleasemakesurethatthetotalsum

of ampere ratings for all connected devices does not exceed the total

ampere capacity for the circuit.

● Before removing the batteryfromthe notebook, make sure firstly

that the notebook is switched off and secondly that the AC Adapter

is disconnected from the electrical wall socket. Once this is done, it

would be safe to remove the battery.

Do not carry the notebook battery, loose in your handbag,

backpack or pocket where loose metal objects (money, keys,

chains, pens, etc) may be present. The metal objects can short

circuit the terminals of the battery resulting in overheating that

could cause a fire hazard. In the event that you need to

transport the battery separately from the notebook, please

place it inside an anti-static bag.

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	Laptop
Modell:	Q2532N-CF1
Vikt:	2600 g
Bredd:	380 mm
Djup:	262 mm
Skärm diagonal:	15.6 "
Upplösning:	1366 x 768 pixlar
Processorfrekvens:	2.3 GHz
Processorfamilj:	Intel® Core™ i5
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth-version:	3.0+HS
LED-bakgrundsbelysning:	Ja
Antal HDMI-portar:	1
DVI-port:	Nej
Antal inbyggda högtalare:	2
Lösenordsskydd:	HDD
Hörlursutgångar:	1
Inbyggd mikrofon:	Ja
Internminne:	4 GB
Modell:	PC
Kabelteknik:	10/100/1000Base-T(X)
Processor:	i5-2410M
Intel® Wireless Display (Intel® WiDi):	Ja
Processorns driftlägen:	64-bit
Processorns cache:	3 MB
Busstyp:	DMI
Maximalt internminne:	8 GB
Total lagringskapacitet:	500 GB
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Hyper Threading Technology (Intel® HT Technology):	Ja
Intel® InTru™ 3D-teknik:	Ja
Intel® Insider™:	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Nej
Idle stater:	Ja
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Nej
Intel® Identity Protection Technology (Intel® IPT):	Ja
Intel® Trusted Execution Technology:	Nej
Minnesplatser:	2x SO-DIMM
Antalet installerade hårddiskar:	1
FSB-paritet:	Nej
Typ av laddningsport:	DC-in-uttag
Processorserie:	Intel Core i5-2400 Mobile Series
S/PDIF-utgång:	Nej
Intel® FDI-teknik:	Ja
Intel® Rapid Storage Technology:	Nej
Intel® Smart Cache:	Ja
WiFi-certifierad:	Ja
Batteriteknik:	Litium-Ion (Li-Ion)
Processorgenerering:	2:a generationens Intel® Core™ i5
Typ av minneskort:	Memory Stick (MS), MMC, MS PRO, MS Pro-HG, SD, SDHC, SDXC
Produktens färg:	Svart
Inbyggd kortläsare:	Ja
processortillverkare:	Intel
Tv-ut:	Nej
Nätverksegenskaper:	Gigabit Ethernet, WLAN
Installerat operativsystem:	Windows 7 Home Premium
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	BGA 1023
Processorns kodnamn:	Sandy Bridge
Högtalareffekt:	4 W
Numeriskt tangentbord:	Ja
Intel® Clear Video Technology för MID (Intel® CVT för MID):	Nej
Processorns cachetyp:	Smart Cache
Hårddiskkapacitet:	500 GB
Typ av internminne:	DDR3-SDRAM
Nätverksansluten (Ethernet):	Ja
Displaytyp:	LCD
Hårddiskens rotationshastighet:	5400 RPM
Intel Clear Video Technology:	Nej
Antal USB 2.0 anslutningar:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
Moderkortets chipset:	Intel® HM65 Express
Native bildförhållande:	16:9
Processorkärnor:	2
Processorboostfrekvens:	2.9 GHz
Upplösning (numerisk), främre kamera:	1.3 MP
Bluetooth:	Ja
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Efterlever industristandard:	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Infraröd port:	Nej
Drifttid för batteri:	- h
Kvalitet på VGA (D-Sub) porten:	1
Processor främre buss:	- MHz
Systembuss, hastighet:	5 GT/s
Processortrådar:	4
Processorlitografi:	32 nm
Stegning:	J1
Processor med ECC-stöd:	Nej
Värmeavledningseffekt (TDP):	35 W
Högsta antal PCI Express-platser:	16
PCI Express-kortplatser version:	2.0
PCI Express konfigurationer:	1x8, 1x16, 2x4, 2x8
T-junction:	100 ° C
CPU multiplikatorn (buss / core-förhållande):	23
Lagringsmedia:	HDD
Optisk enhetstyp:	DVD Super Multi
Grafikadapterfamilj:	Intel, NVIDIA
Ombord grafikkort modell:	Intel® HD Graphics 3000
Diskret grafikkortsmodell:	NVIDIA® GeForce® GT 540M
Basfrekvens för inbyggt grafikkort:	650 MHz
Högsta dynamiska frekvens för inbyggt grafikkort:	1200 MHz
Grafik enhets-ID:	0x116
Ombord grafikkort:	Ja
Diskret grafikkort:	Ja
Familj av inbyggda grafikkort:	Intel® HD Graphics
Uttag för mikrofon/linje in:	Ja
Slot för ExpressCard:	Nej
Typ av CardBus PCMCIA-kortplats:	Nej
Slot för SmartCard:	Nej
Pekredskap:	Styrplatta
Operativsystemets systemarkitektur:	64-bit
Antalet battericeller:	8
Intel® Stöldskydd Teknik (Intel® AT):	Ja
Intel® Turbo Boost Technology:	2.0
Förstärkt Intel Speedstep Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Quick Sync Video Technology:	Ja
Intel® Flex minnesåtkomst:	Ja
Intel® Förbättrad Halt State:	Ja
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Intel® Efterfrågan Baserad Växla:	Nej
Execute Disable Bit-säkerhet:	Ja
Termiska övervakningsteknik:	Ja
Processorns förpackningsstorlek:	37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Stödda instruktionsset:	AVX
Inbäddade alternativ:	Nej
Grafik & IMC litografi:	32 nm
Intel Identity Protection Technology-version:	1.00
Intel Virtualization Technology (VT-x):	Ja
Etisk processor (Conflict Free):	Nej
Intel® Dual Display Kan Teknik:	Ja
Integrerat 4G WiMAX:	Ja
Intel® Snabb Memory Access:	Ja
ARK-ID för processor:	52224
Hårddiskens gränssnitt:	SATA
Images Type Map:	<div><img src="https://ark.intel.com/inc/images/diagrams/diagram-18.gif" title="Block Diagram" /></div>
Hårddiskens storlek:	2.5 "
Windowstangent:	Ja
Diskret grafikminne typ:	GDDR3
Antal diskreta grafikkort:	1
Höjd (framsida):	29.1 mm
Höjd (baksida):	34 mm
Inbyggt grafikkortsminne:	0.125 GB
