English User’s Manual

English

Thank you for purchasing GIGABY TE thermal product. GIGABY TE

is dedicated to the integration of casing liquid/air-cooling solution

technology, to provide users with the most optimal solution for heat

dissipation. For further information and specifications of the “Triton”

series, please visit GIGABYTE website. (http://www.gigabyte.com.tw)

The Following are not covered by the warranty:

1. Using the product incorrectly or in a manner other than the designed purpose.

2. Nonobservance of the proper operations provided.

3. Malfunction due to interference from other devices.

4. Unapproved modification of the product.

5. Consequential damage to other objects due to the product’s fault.

6. Malfunction arising from natural hazards E.g. earthquake, lighting, fire and floods.

7. The product’s warranty label has been removed or damaged.

8. The devices inside, including power supply, hard disk, CD-ROM drive, motherboard,

ventilator, etc, are not detached from the casing prior to transportation of the computer

system, resulting in damage to the casing or other computer-related devices.

9. Any loss/damage caused by failure to follow the installation process with in the user

manual.

Triton 180

Triton

Failure to wear gloves during installation of computer products

may cause bodily harm or damage to your devices. Incorrect

connector installation may possibly burn out the motherboard

and other components. Be sure to observe the instructions in

the user manual.

English

Table of Contents

1. Components Introduction

1-1 Casing’s Internal Structure

1-2 Front and Rear Panel Structure

1-3 Removal of Side and Front Panels

2. Features

3. Specifications

4. Installation Instructions

4-1 Installation of Power Supply

4-2 Installation of Motherboard

4-3 Installation of Add-on Card

4-4 Installation of Front Multi-Media I/O Port

4-5 Installation of Fan Power Cable

4-6 Installation of 5.25” Front Device Bay

4-7 Installation of 3.5” Front Device Bay

4-8 Installation of 3.5” Internal Device Bay

4-9 Foot Supports

4-10 Liquid Cooling System Support

4-11 Recommended Cooling Products

Produktspecifikationer

Varumärke:	Gigabyte
Kategori:	dator box
Modell:	Triton
Vikt:	8400 g
Bredd:	200 mm
Djup:	440 mm
Höjd:	480 mm
Ljudutgång:	Ja
Material:	Gjuten aluminium
Modell:	PC
Expansionsplatser:	7
Produktens färg:	Svart
Formfaktor:	Midi Tower
Antal USB 2.0 anslutningar:	2
Ljudanslutning:	Ja
Som stöds moderkorts formfaktorer:	ATX
Anta IEEE 1394/Firewire anslutningar:	1
Externa expansionsfack:	5x5.25"
Ventilationsfläkt:	2x 120mm
