Sida 1/32

Lombok A130/AL130A/A230/AL230A / Großbritannien / A31008-M2412-L101-1-7619 / Lombok.fm / 12.02.2013

Version 4, 16.09.2005

Gigaset A130/AL130A/A230/AL230A

The handset at a glance

1 Charge status of the batteries:

= e V U

(flat to full) 

= flashes: batteries almost flat

e V U flashes: charging

2 answer machine icon

3Display keys

4 End call key and On/Off key

5 Talk key/Handsfree key

6 Control key (

7 Directory key (press down on the 

control key)

8 Key 1 

Open the answer machine /

network mailbox

9 Star key 

Ringers on/off (press and hold); with 

an open connection: switch from pulse 

dialling to tone dialling (press briefly)

10 Key 0/recall key

Consultation call (flash): press and hold

11 Hash key

Keypad lock on/off (press and hold); 

toggles between upper/lower case 

and digits; inserts a dialling pause 

(press and hold)

12 Microphone

(handsfree mode A230/AL230A

only)

A130/AL130A A230/AL230A

1 ±V

11.12. 11:56

INT MENU

Display keys:

Pressing a key launches the function that ap

pears above that key in the display.

Gigaset service contact numbers:

For personal advice on our range of products and for repairs or guarantee/warranty claims

call:

Service Centre UK: 0845 0318190 (local call cost charge)

Service Centre IE: 0818 200 033

Please have your proof of purchase ready when calling.

Please note

New messages in the calls list/answer machine list/network mailbox list (

¢ page 8) are

indicated in the display by the message New messages.

Display Function when pressed

INT Call other registered handsets

¢ page 11.

MENU Open main/submenu (see menu overview

¢ page 16).

“

Go back one menu level.

Scroll up/down or adjust volume with u.

Move cursor to left/right with u.

Backspace deletes one character at a time.

OK Confirm menu function or save entry.

Lombok A130/AL130A/A230/AL230A / Großbritannien / A31008-M2412-L101-1-7619 / Lombok.fm / 12.02.2013

Version 4, 16.09.2005

ECO DECT

During a call, the level of the handset's radio signal adjusts automatically according to

the distance between the handset and base station: the shorter the distance, the lower

the signal strength (radiation).

The handset’s radio signal is switch

ed off when it is in standby mode. The base station,

however, maintains contact with the handset with fewer radio signals.

In addition, the base station radio signa

ls are switched off when the No Radiation

setting is enabled.

¤ u Settings ¤ OK ¤ u Base ¤ OK ¤ u ECO DECT ¤ OK ¤ No Radiation

¤ OK (‰= radiation switched off, icon ½ in the left-hand corner of the display)

Please note

◆ All registered handsets must support this feature.

◆ For quick connection of incoming calls the handset repeatedly switches to recep-

tion mode for short periods. This incre

ases energy consumption and therefore

reduces the standby and talk times.

The base station at a glance

Base A130/A230

Base AL130A/AL230A

1 Registration/paging key: 

Search for handsets (press briefly, "Pag-

ing"

¢ page 10).

¢ page 10).

2 Volume keys: (– = quieter; + = louder)

During message playback: adjust the

speaking volume.

While phone is ringing: adjust ringer

melody volume.

3 Play/Stop key:

Switch answer machine on and off (press

and hold);

play back new messages from answer

machine (press briefly); 

during message playback: cancel play-

back (press briefly).

Lights up: Answer machine is activated. 

Flashes: You have at least one new mes-

sage or a message is played back or be-

ing recorded.

Flashes very quickly: Full memory.

During message playback:

4 Skip to the start of the current message

(press once) or go to the previous

message (press twice).

5 Go to the next message.

6 Delete current message.

Lombok A130/AL130A/A230/AL230A / Großbritannien / A31008-M2412-L101-1-7619 / Lombok.fm / 12.02.2013

Version 4, 16.09.2005

Safety precautions

Warning

Read the safety precautions and the user guide before use.

Explain their content and the potential hazar

ds associated with using the device to

your children.

Use only the power adapter indicated on the device.

Use only rechargeable batteries that correspond to the specification (see

pecifications"). Never use a conventional (non-rechargeable) battery or other

battery types as this could result in significant health risks and personal injury.

Rechargeable batteries, which are noticeably damaged, must be replaced.

Using your telephone may affect nearby medical equipment. Be aware of the

echnical conditions in your 

particular environment, e.g. doctor's surgery.

If you use a medical device (e.g. a pacemaker), please contact the device

manufacturer. They will be able to advise you regarding the susceptibility of the

device to external sources of high frequency energy (for the 

specifications of your Gigaset product see "Specifications").

Do not hold the rear of the handset to your ear when it is ringing or when speaker

ode is activated. Otherwise you risk serious and permanent damage to your

hearing.

Your Gigaset is compatible with the majority of digital hearing aids on the market.

However, perfect function with all hearing aids cannot be guaranteed.

The phone may cause interference in analogue hearing aids (humming or

whistling) or cause them to overload. If you require assistance, please contact the

hearing aid supplier.

The devices are not splashproof. For this r

eason do not install them in a damp

environment such as bathrooms or shower rooms.

Do not use the devices in environments with a potential explosion hazard

(e.g. paint shops).

If you give your Gigaset to a third party, make sure you also give them the user

guide.

Remove faulty devices from use or have them repaired by our Service team, as

ese could interfere with other wireless services.

Please note

◆ The device cannot be used in the event of a power failure. It is also not possible to

transmit emergency calls.

◆ Emergency numbers cannot be dialled if the keypad lock is activated!

Produktspecifikationer

Varumärke:	Gigaset
Kategori:	Telefon
Modell:	A230 Duo
Inbyggd display:	Ja
Skärm diagonal:	1.4 "
Upplösning:	5 x 7 pixlar
Pekskärm:	Nej
SMS:	Nej
Antal färger:	monokrom
Skärmupplösning (numerisk):	14 pixlar
Modell:	DECT-telefon
Väckarklocka:	Ja
Klocka med kalender:	Ja
Telefonbokskapacitet:	80 poster
Trådlösa anslutningar:	Ja
Maximal räckvidd inomhus:	50 m
VIP-grupp med egen melodi:	Nej
Batterityp:	AAA
Bakgrundsbelyst skärm:	Ja
Antal batterier:	2
Produktens färg:	Svart
Kalender:	Nej
Batterinivåindikator:	Ja
Nummerpresentation:	Ja
Språkstöd:	Multi
Textrader:	3 linjer
Maximal räckvidd utomhus:	300 m
Monteringssätt:	Skrivbord/vägg
Högtalartelefon:	Ja
Plug & Play-kompatibel:	Ja
Ringsignaltyp:	Mono
Vibrationsalarm:	Nej
Inbyggd telefonsvarare:	Nej
Namn och uppringnings-ID:	Ja
Antal telefoner som ingår:	2
Färg på bakgrundsbelysning:	Bärnsten
Samtalstimer:	Ja
Samtalstid:	18 h
Navigationstangent:	Ja
Stand-by tid:	200 h
Dimension på handset (BxDxH):	151 x 47 x 31 mm
Basdimensioner:	89 x 80 x 61 mm
Bakgrundsljusknappar:	Ja
Funktioner för flera telefonlurar:	4
Direktsamtal:	Ja
Röstuppringning:	Nej
Funktion för VIP-grupp:	Nej
