Gigaset 5040 Quick Guide

Keys

1Name keys

2 Automatic call pick-up key*

3 Star key / Proximity sensor key*

4 Hash key / Telephone lock key*

5 Recall key / Set key*

6 Loudspeaker key (handsfree)

7 Mute key

8Redial key

9 Calls list key / Visual display of incoming calls

10 Loud key / Up key

11 Quiet key / Down key

* Keys can have two functions. Hold down key for at

least 1 second to use the function marked with an aster-

isk. If activated successfully you will hear the positive

confirmation tone. The corresponding symbol is shown

in the display (see “Display symbols”).

Display

To get the optimum viewing angle you can adjust the

display to an angle of 0° - 60°.

Display symbols

œ In setting mode

{ Telephone locked

ƒ Baby Call (direct call) activated

~ Microphone off

} Handsfree on

› Number indicated in calls list called more

than once

‰ Power on

Œ On: Proximity sensor activated

Flashing: Proximity sensor and automatic

call pick-up activated

–

Phone number

00:00

Call duration

Entry mark when setting (e.g. volume)

Recall key pressed

Pause

---

Ready for use

No memory content

zzzz

When trying to connect: telephone locked

With tone dialling:

Star key * pressed

Hash key # pressed

Keypad and display illumination

The whole keypad and the display light up

◆ when a call comes in,

◆ when you press a key,

◆ when you lift handset,

◆ when you approach the telephone and the proximity

sensor is on (see page 6).

Display

Proximity

sensor

4567

gaset 5040

IRL

30350-

211-

101-2-7619

utton_en.

28.02.2011

Proximity sensor

The proximity sensor detects when you approach the

telephone and lights up the keypad and display. A call is

automatically answered by speaking handsfree.

Prerequisite: the caller is stored under a Name key and

“Automatic call pick-up” is activated (see page 6).

Note: An automatically answered call is ended like any

other call in handsfree mode (see page 4).

Important numbers under Name keys

For quick access to important numbers, you can save up

to 6 numbers under Name keys and label them accord-

ingly (see page 5). The complete number must be stored

(including area code).

Easy to recognise incoming and missed calls

The Gigaset 5040 also indicates visually when you

receive a call:

◆ The Name key flashes if the caller is stored (see

page 5).

◆ The Calls list key flashes if the caller is not stored

under a Name key (see page 9).

◆ The calling number is shown in the display if Calling

Line Identification (CLI) is possible (see page 9).

You can also quickly access numbers which called in

your absence:

◆ The Name key is lit up if the caller is stored.

◆ The Calls list key is lit up if the caller is not stored

under a Name key. You can scroll through all missed

calls.

Safety precautions

When installing, connecting and operating the tele-

phone, always observe the following precautions:

◆ Only use the plugs and leads supplied.

◆ Only connect the connecting lead to the socket/jack

provided for that purpose.

◆ Only connect approved accessories.

◆ Arrange the connecting lead where it will not cause

accidents.

◆ Position the telephone on a non-slip surface.

◆ For your safety and protection, the telephone must

not be used in bath or shower rooms (wet locations).

The telephone is not splash proof.

◆ Never expose the telephone to sources of heat, direct

sunlight or other electrical devices.

◆ Protect your telephone from moisture, dust, corro-

sive liquids and vapours.

◆ Never open up the telephone yourself.

◆ Do not touch the plug contact with pointed or metal-

lic objects.

◆ Do not carry the telephone by the leads.

◆ If you give your Gigaset 5040 to someone else, make

sure you also give them the user guide.

All electrical and electronic products should be dis-

posed of separately from the municipal waste stream

via designated collection facilities appointed by the

government or the local authorities.

This crossed-out wheeled bin symbol on the product means

the product is covered by the European Directive 2002/96/EC.

The correct disposal and separate collection of your old appli-

ance will help prevent potential negative consequences for the

environment and human health. It is a precondition for reuse

and recycling of used electrical and electronic equipment.

For more detailed information about disposal of your old appli-

ance, please contact your local council refuse centre or the

original supplier of the product.

Produktspecifikationer

Varumärke:	Gigaset
Kategori:	Telefon
Modell:	Euroset 5040 XL
Inbyggd display:	Ja
Modell:	Analog telefon
Samtalsblockering:	Nej
Antal melodier:	10
Telefonbokskapacitet:	- poster
Trådlösa anslutningar:	Nej
Produktens färg:	Lila
bruksanvisning:	Ja
Monteringsbar på väggen:	Nej
Produktstorlek (BxDxH):	241 x 201 x 80 mm
Textrader:	1 linjer
Monteringssätt:	Bord
Snabbuppringning:	Ja
Mac-kompatibel:	Nej
Inbyggd telefonsvarare:	Nej
Namn och uppringnings-ID:	Ja
Antal telefoner som ingår:	1
Bakgrundsljusknappar:	Ja
Direktsamtal:	Ja
