BUILT-IN HOB

Important warning and advice for usage

IMPORTANT! This booklet is a fundamental part of the appliance it should be

preserved whole and at hand throughout the hob’s lifespan. We recommend that this

booklet and all the instructions within it are read carefully before using the appliance.

Keep the spare parts supplied in a safe place. The appliance is to be installed by

qualified personnel respecting the norms in force. This appliance is for domestic use

and has been built to carry out the following functions: cooking and heating food. Any

other use is considered improper.

The manufacturer is not responsible for bad installation, tampering, unskilled use and usage other

than that it is intended for.

i Check that the product has not been damaged during transport.

i Packing elements (plastic bags, expanded polystyrene, nylon etc) are potentially dangerous and must be

kept away from children.

i Packing is made up of recyclable material and is marked by the

symbol. Do not on dispose of it in

the environment.

i This appliance is only to be used by adults. Make sure the children do not touch the commands or play

with the appliance.

i Installation and all gas/electric connections must be carried out by qualified personnel, fully respecting the

safety norms and laws in force, on the basis of the instructions supplied by the manufacturer.

i Electrics are only safe when the product is connected to an efficient earthing system.

i It is risky to modify or try to modify the appliance. In the case of faults, do not attempt reparation but ask for

assistance from a qualified technician.

i Having used the hob, make sure that the knob indicator is on the off position and turn off the main gas

distribution valve or the cylinder valve.

i If you decide not to use this appliance it must rendered unusable according to health and environmental

protection laws before being taken to the recyclable waste disposal; the parts that may be dangerous to

children must be made

i The identification plate with its technical data is in a visible position under the housing and attached to this

booklet. The plate under the housing must never be removed.

i The illustrations for using the appliance are in the final pages of this booklet.

Declaration of conformity

This appliance conforms to the following EC directives

 90/396/CEE “Gas apparatus”

 73/23/CEE “Low voltage”

 89/336/CEE “Electromagnetic compatibility”

 93/68/CEE “General Norms”

 89/109/CEE “Materials or objects that can come into contact with foodstuffs”

GLASS COVER

If the appliance has a glass cover, please take the following precautions:

i Do not place hot pots on the cover when it is closed.

i Remove any liquid that has spilt onto it before opening it.

i It could break if heated. Turn all the burners and the electric plates off and wait for them to cool before

lowering the cover.

These instructions are only valid for destination countries with

the identification symbols shown in the booklet and on the

appliance.

The instructions for hobs shall state that the appliance is not intended to be operated by means of external timer

or separated remote-control system.

HOB CHARACTERISTICS

Warning:

This appliance is the type for being built into furniture.

i The installation class is 3 for the gas parts and Y for the electric parts.

i Furniture must be resistant to temperatures of at least 90°C.

i See the relative paragraph and drawings for correct installation.

i Using a gas cooking appliance causes heat and humidity in the location where it is installed. Make sure that

the kitchen is aired properly: keep natural aeration orifices open or install a mechanical aeration device

(ventilation hood). Intensive and long use of the appliance will need further aeration, opening a window for

example, or more efficient aeration such as increasing the hood speed.

This booklet is suitable for various hobs. You can see your model (Mod. Tc) on the plate. You will see how

your appliance is made up from its model number, the instructions in the following paragraph and the figures at

the back of the booklet (Fig1 to 38).

Example:

Marchio

T y p e : P......

Smoke appearance:

During the first use of a brand new hotplate an obvious smoke appearance will be visible. Poisoning can be

possible.

i Do the burn-in process of the hotplate as described in these operating instructions (see chapter FIRST USE).

i Ensure a sufficient and continuous fresh air flow.

i Use an extractor hood during burn-in process.

Make sure that elderly or ill persons, children, pregnant or nursing women shall stay out of the area during the

burn-in

process.

Produktspecifikationer

Varumärke:	Glem Gas
Kategori:	Ugn
Modell:	GT955HIX
Inbyggd display:	Nej
Timer:	Nej
Bredd:	860 mm
Djup:	500 mm
Höjd:	30 mm
Elektronisk tändning:	Ja
Antal gasbrännare:	5
Produktens färg:	Rostfritt stål
Kontrolltyp:	Rotations-
Wok brännare:	Ja
Apparatens placering:	Inbyggd
Installationsfack, bredd:	830 mm
Installationsfack, djup:	480 mm
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	5
Kokzon 3, form:	Rund
Placering av platta/tillagningsyta 4:	Höger bak
Typ av platta/tillagningsyta 4:	Vanlig
Typ av platta/tillagningsyta 3:	Extra stor
Kokzon 1, form:	Rund
Placering av platta/tillagningsyta 3:	Central
Kokzon 2, form:	Rund
Strömförsörjning till platta/tillagningsyta 3:	gas
Typ av platta/tillagningsyta 1:	Stor
Placering av platta/tillagningsyta 2:	Främre till vänster
Strömförsörjning till platta/tillagningsyta 4:	gas
Strömförsörjning till platta/tillagningsyta 2:	gas
Typ av platta/tillagningsyta 2:	Sjudning
Kokzon 4, form:	Rund
Strömförsörjning till platta/tillagningsyta 1:	gas
Placering av platta/tillagningsyta 1:	Vänster bak
Sjuda brännare / kokzon:	100 W
Regelbunden brännare / kokzon:	1750 W
Stora brännare / kokzon:	3000 W
Manöverplats:	Framsida
Effekt på platta/tillagningsyta 1:	3000 W
Effekt på platta/tillagningsyta 2:	1000 W
Effekt på platta/tillagningsyta 3:	3800 W
Extra stor hög hastighet brännare / kokzon:	3800 W
Effekt på platta/tillagningsyta 4:	1750 W
Typ av ytskikt:	Rostfritt stål
Anslutningseffekt (elektrisk):	11300 W
Anslutningseffekt (gas):	- W
Flamskyddad enhet:	Ja
Material i hällstativ:	Gjutjärn
Wok brännare läge:	Mitten
Effekt på platta/tillagningsyta 5:	1750 W
Wokbrännarens effekt:	3800 W
Typ av platta/tillagningsyta 5:	Vanlig
Kokzon 5, form:	Rund
Placering av platta/tillagningsyta 5:	Höger fram
Strömförsörjning till platta/tillagningsyta 5:	gas
Spisens bredd, storlek:	90 cm
Antal kokzoner som kan användas samtidigt:	5
Grillhäll:	Ja
Integrerad huva:	Nej
