Sida 1/48
instructions booklet
notice D’utilisAtion
2
TABLE OF CONTENTS
03 General warnings
04 Your product
05 Use
Hob
Oven
Programmers and minute minders
Cooking suggestions
08 Cleaning
09 Maintenance
10 Instructions for the installer
Product handling
Installation
Adaptation to the different types of gas
14 Technical assistance
14 Product and packaging disposal
14 Technical data
16 Cooking and grilling tables
We would like to thank you for purchasing one of our products,
we are condent it will full your needs. We would also like to
invite you to read this booklet carefully and keep it safe, as it
contains important information and useful tips for your new
cooker optimal use, in complete safety.
This appliance is in conformity in force:
- 2006/95/CE Low Voltage (Directive)
- 2004/108/CE Electromagnetic Compatibility (Directive)
- 2009/142 Gas Appliance (Directive)
- 1935/2004/CE Materials intended to come into contact with
food (Regulation)
- 2002/95/CE Restriction of the use of certain hazardous
substances in electrical and electronic equipment (Directive)
- 2002/40/CE Energy labelling of household electric ovens
(Directive)
English - EN
3
GENERAL WARNINGS
This appliance is only designed and built for household use. Any other
use, such as heating, for example, is considered improper, and therefore
highly dangerous.
Keep children away with under the age of 8 years, if not under the constant
supervision of an adult.
Children and people with reduced physical, mental or sensory abilities
and/or with lack of adequate knowledge of the use and dangers that the
equipment can entail, are forbidden to use this appliance unless they are
under the constant supervision of a responsible adult.
Children must not play with or near the appliance, whether it is in operation
or not. Please do not allow children to clean the appliance.
If the appliance has a fault and/or is not working properly, please close
the gas line, disconnect the appliance from the power mains, and do
not attempt to service it by yourself. Contact your nearest authorized
assistance centre directly (see the "technical assistance" section herein).
The surface temperatures of every part must strictly comply with the
regulations in force. This does not mean that some metal parts will not
burn during or after its use. Accordingly, please use with due care.
The cooker cannot be installed without feet;
The Company will not be held liable in case of failure to observe the
information provided herein.
The Company reserves the right to change product specications
maintaining safety and functionality.
The alcohol vapours inside the hot cooking compartment may catch re. Do not
cook food containing large quantities of beverages with a high alcohol content.
Only use small quantities of beverages with a high alcohol content. Open the door
of the appliance carefully.
11
ventilation opening for air ow
required for correct combustion
enlarged hole to allow
adequate air ow from the adjacent room
A
g.12
direct exhaust out-take to the
outdoors
exhaust out-take through the ue
installed for the cooker only
g.13
Recessed appliance
(Class 2 sub-class 1)
Recessed appliance
(Class 2 sub-class 1)
Free-standing appliance
installation (Class 1)
g.14
STABILITY DEVICE (only if required by regulation in the country of use and provided as a kit together with the cooker)
WARNING
To prevent accidental tipping of the appliance, it is necessary
1. Children should not play or sit, on the open oven door.
2. Do not lean or sit, on the appliance’s open door. The excessive load may compromise the stability.
3. Do not place hot pans with sharp bottom, on the internal glass.
For models with a width of 50, 60, 70, 80, 90, 100 cm it is necessary to install rear safety devices, as an absolute guarantee against the appliance tipping
forwards, even when bearing heavy loads on the open oven door.
• There is a rear cover panel installed on the rear of the cooker. Measure distance H from the highest point of the panel to the oor (A).
• Use the value of the H measurement to draw reference marks where the holes for the plugs will need to be drilled on the wall where the cooker will be
installed . (B)
• Also mark the centre distance of the cooker on the wall at the same previously measured H height .(C)
• It is now possible to install the two brackets at a distance of 400 mm from each other (200 mm from the centre distance) and position the cooker against
the wall under the two brackets .(D)
A B C D
CENTRE DISTANCE OF COOKER
BRACKET 1 BRACKET 2
200 mm 200 mm
H
H
400 mm
If your cooker has a 90x60, 80x50 cylinder cabinet, or 80x50 cabinet, it is necessary to assemble the brackets at the distance given in the pictures below:
Cooker with 90 x 60 cylinder cabinet Cooker with 80 x 50 cylinder cabinet Cooker with 80 x 50 cabinet
CENTRE DISTANCE OF COOKER CENTRE DISTANCE OF COOKER CENTRE DISTANCE OF COOKER
BRACKET 1 BRACKET 2
BRACKET 1 BRACKET 2
BRACKET 1 BRACKET 2
200 mm 315/320 mm 200 mm 310 mm 280 mm
H
H
H
1 1
to install this stabilizing device as shown in the pictures below.
If a closing panel is applied on the feet of the kitchen, make sure that there is a grid
with a passage section > 100 mm² so as to guarantee proper ventilation of the gas
burners inside the oven cavity.
14
BURNER TYPE
(sizes mm) GAS TYPE PRESSURE
(mbar)
INJECTOR
MARKING
(1/100 mm)
GAS
C SUMPON TION*
POWER (kW)
RECOMMENDED
POT
DIAMETER**
(cm)
MAX. MIN.
MINI AUXILIARY
Ø 39 0,800 0,300
12÷14
6 with reduction
grill
natural gas 20 68 95 dm3/h
AUXILIARY
Ø 55 1,000 0,300
12÷14
6 with reduction
grill
natural gas 20 72 95 dm3/h
SEMIRAPID
Ø 75 1,750 0,440 16÷20
natural gas 20 98 167 dm3/h
RAPID
Ø 100 3,000 0,750 20÷24
natural gas 20 116 286 dm3/h
ULTRARAPID
Ø 120 3,300 1,500 22÷26
natural gas 20 124 314 dm3/h
FISH BURNER
60x235 2,900 1,500 Max
14÷35
natural gas 20 120 276 dm3/h
TRIPLE
Ø 130 3,600 1,800 24÷28
natural gas 20 135 343 dm3/h
TRIPLE
Ø 130 3,800 1,800 24÷28
natural gas 20 137 363 dm3/h
* In reference conditions,
TECHNICAL DATA
PRODUCT AND PACKAGING DISPOSAL
* In reference conditions, gas temperature 15°C, atmospheric pressure 1013.25 mbar
TECHNICAL ASSISTANCE
T
The packaging used on our products can be recycled, therefore we ask you not to dispose of the packaging or parts of it as household
waste, and to dispose of it in the best way possible to reduce the effect on the environment.
If you are purchasing our appliance to replace an old one, it is necessary to contact your locally authorized company for the collection of
decommissioned appliances This will allow the recyclable materials to be re-used and avoid polluting the environment..
The crossed-out bin symbol printed on the appliance indicates that at the end of its service life the appliance must be collected
separately from other waste. Accordingly, at the end of its service life, the user must hand the appliance over to suitable electric and
electronic waste collection centres, or deliver it to the dealer when purchasing a new, similar appliance, on a one for one basis. The
suitable dismantling of the decommissioned appliance and sending of its parts to recycling, ecologically compatible treatment and
disposal, contributes to avoiding possible negative effects on the environment and human health and promote the re-use of the materials
that comprise the appliance The unlawful disposal of the product by the user will result in administrative sanctions..
COOK-TOP
Diameter
(mm)
Power
(Watts)
Diameter
(mm)
Power
(Watts)
Electric plate Normal 145 1000 Circular High-Light 145 1200
Electric plate Normal 145 1500 Circular High-Light 180 1800
Electric plate Rapid 180 2000 Circular High-Light 210 2200
Extensible High-Light 120/210 700/2100
Extensible High-Light 170/265 1400/2200
POWER OF HEATING ELEMENTS
LPG 30 46 58 g/h
LPG 30 52 73 g/h
LPG 30 91 240 g/h
LPG 30 68 130 g/h
LPG 30 88 240 g/h
LPG 30 88 211 g/h
LPG 30 96 262 g/h
LPG 30 98 277 g/h
17
Français - FR
