The guarantee and service offered by this document are not applicable in
the following cases: . The product or accessory has expired its
warranty period; . Breakage or damage caused by inappropriate usage,
maintenance or preservation, such as improper packing, improper usage,
improper plugging in/out external equipment, falling off or squeezing by
external force, contacting or exposing to the improper temperature,
solvent, acid, base, flooding and damp environments, etc; . Breakage
or damage caused by non-authorized institution or staff in the process of
installation, maintenance, alternation, addition and detachment; . The
original identifying information of product or accessory is modified,
alternated, or removed; . No valid warranty card; . Breakage or
damage caused by using illegally authorized, nonstandard or non-public
released software; . Breakage or damage caused by force majeure or
accident; . Breakage or damage that could not be attributed to the
product itself. Once met these situations above, you should seek
solutions from the related responsible parties and Godox assumes no
responsibility. The damage caused by parts, accessories and software
that beyond the warranty period or scope is not included in our
maintenance scope. The normal discoloration, abrasion and
consumption are not the breakage within the maintenance scope.
OFF/ON
100%(LUX)(0.5)()
CRI()
LED6R
1800mAh
5V/2A
6W
3200K6500K
270
95
0%~100%
2H-10H
-10~40
77*66*30 mm
110g
•
•
•
•
•
•
•
•
godox.com
Add: Building 2, Yaochuan Industrial Zone, Tangwei Community,
Fuhai Street, Bao’an District, Shenzhen, China
Tel: +86-755-29609320(8062) Fax: +86-755-25723423
E-mail: godox@godox.com
GODOX Photo Equipment Co., Ltd.
1.1.
ON
OFF
GODOX
-LED6R
705-LED6R0-00
±2mm
105G铜版纸
杨入人
A
单色，黑色印刷
88*88MM
1. 1800mAh
2.
3. 5V 2A
2. : M
As this product do not have waterproof function,
please take measures of waterproof in rainy or
damp environment.
Do not use the flash unit in the presence of
flammable gases, chemicals and other similar
materials. In certain circumstance, these
materials may be sensitive to the strong light
emitting from this flash unit and fire or
electromagnetic interference may result.
As this product has built-in lithium battery, do
not disassemble, impact,squeeze or put it into
fire. If serious bulge occurs, please do not use.
Do not use or store the product if the ambient
temperature reads over the range of -10°C to
40°C. Please charge the product with included
adapter and correctly operate it within the
defined voltage and working temperate
according to the instruction manual.
Warning
Names of Parts
What’s in the Box
Battery
1. This flash unit has built-in 1800mAh Li-ion battery
which is non-detachable.
2. It is reliably safe. The inner circuit is against
overcharge, overdischarge, overcurrent, and short
circuit.
3. Charge the battery by using the 5V 2A charger.
1. No over 24 hours' continuous charging.
2. Store in dry, cool, ventilated places.
3. Do not put aside or into fire.
4. Dead batteries should be disposed according to
local regulations.
5. Please charge the battery to approx. 70% before
being placed for long time.
6. If the battery had ceased using for over 3
months, please make a full recharge.
7. It's normal that the battery will be degraded after
a period's usage for the battery life limitation.
long press the M button to choose this mode.
Technical Data
Model
Built-in Lithium Battery
Power Source of Charging
Power
Color Temperature Range
100% Illuminance(LUX)(0.5m)(≈)
CRI(≈)
Brightness Range
Duration
Working Environment Temperature
Dimension
Net Weight
LED6R
1800mAh
5V/2A
Max. 6W
3200K 6500K～
270
95
0%~100%
2H-10H
-10~40°C
77*66*30 mm
110g
Maintenance
- Shut down the device immediately should abnormal
operation be detected.
- Avoid sudden impacts and the product should be
dedusted regularly.
- It is normal for the light beads to be warm when in use.
Avoid continuous flashes if unnecessary.
- Maintenance of the light must be performed by our
authorized maintenance department which can provide
original accessories.
- This product, except consumables, is supported with a
one-year warranty. Lithium battery is supported with six
months warranty.
- Unauthorized service will void the warranty.
- If the product had failures or was wetted, do not use it
until it is repaired by professionals.
- Changes made to the specifications or designs may
not be reflected in this manual.
Instruction Manual
RGB LEDLED6RRGB
• LED
13
•
• Type-C USB
•
•
•
-10- 40
Forward
This RGB LED Video Light LED6R is a multifunctional
RGB light with multicolor, dual color temperature, FX
lights effects which can be wirelessly adjusted. Suitable
for almost all shooting occasions e.g. live, make up,
portrait and product shooting, video and recording, etc. It
can be used on camera independently or in combination
with easy operation and great portability.
Main Features
• Freely switch LED CCT mode, RGB recycle mode and
FX light effects mode
• Easy to adjust color temperature, brightness and color
saturation
• With built-in lithium battery and the light can be
charged through Type-C USB port
• With magnetic absorbed function which enables the
light can be absorbed onto the iron surface
• Can be used independently or in combination with
cold shoe mounting base and slots
• Fashionable, easy operated and portable
*1
Type-C USB *1
*1
*1
Light Body *1 Type-C USB Cable *1
Diffuser *1 Instruction Manual *1
01.
02.
03. 1/4
04. Type-C USB
05.
06.
1. 24
2.
3.
4.
5. 70%
6. 3
7.
1.2. /
/
1.
1.3.
/
1/41/4
2.1 M
2.3
1%
0100%
RGB LED
RGB LED Video Light
01. LED Beads
02. Diffusion
03. 1/4”Cold Shoe
Mounting Base
04. Type-C USB Charging Port
05. Cold Shoe Slot
06. Cold Shoe Base
Cautions:
07.
08.
09.
10.
11.
M
CCT
HSI
FX
13
2.2
100K
3200K6500K
3. : M
3.1 M
3.2 H
1°
0360°
3.3 S
10-100
3.4 I
1%
0100%
4.
4.1Fx
Fx13
4.213
1
2
3
4
5
6
7
8
9
10
11
12
13
SOS
07. Power Switch
08. Mode Selection Button
09. Adjustment Button
10. Light Effects Button
11. Display
Operation
1.1 Power ON/OFF
Please push the power switch
onto to power on the light ON
and the current parameters will
be displayed. Push the power
switch to to power the light OFF
off.
1. Light Setting
1.2 Mode Selection: CCT Mode/Colorful Mode/
Light Effects Mode
Long press the M button to
switch different modes:
displayed CCT means bi-
color mode and HSI means
colorful mode.
Press FX button to enter
light effects mode. And the
13 categories modes and
icons will be displayed.
1.3 Installation and Multi Usage
The light can be fixed on the equipment with cold shoe
or hot shoe through its cold shoe mounting base.
It can be fixed on the equipment with 1/4”sockets e.g.
pan-tilt, tripod and light stand.
With built-in magnet in its back, this light can be
absorbed on the subjects with iron surface.
And the three cold shoe sockets enable this light to be
installed on the equipment with cold shoe mounting
base.
2. CCT mode:
2.1 Short press the M button to
choose the value to be adjusted.
2.2 Color temperature adjustment: press the upper
adjustment button to increase the color temperature value
while lower button to decrease. Short press the button
once and the color temperature value will changes in 100K.
Long press the button to adjust the value from 3200K to
6500K quickly.
2.3 Brightness adjustment: press the upper adjustment
button to increase the brightness value while lower button
to decrease. Short press the button once and the color
temperature value will changes in 1%. Long press the
button to adjust the value from 0 to 100% quickly.
3. Colorful mode:
long press the M button to choose this mode.
3.1 Short press the M button to
choose the value to be adjusted.
3.2 H hue adjustment: press the upper adjustment button
to increase the hue value while lower button to decrease.
Short press the button once and the hue value will changes
in 1°. Long press the button to adjust the value from 0 to
360° quickly.
3.3 S Saturation adjustment: press the upper adjustment
button to increase the saturation value while lower button
to decrease. Short press the button once and the
saturation value will changes in 1. Long press the button to
adjust the value from 0 to 100 quickly.
4.1 Press the FX button to enter
light effects modes. Then, short
press the FX button to switch the
13 effects in recycle while long
pressing to change them quickly.
4.2 There are 13 categories to be
selected according to your
demands.
4. FX Light Effects Mode
(13 categories)
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
Display Light Effects
RGB Recycle
Flash
Laser
Lightning
Broken Bulb
TV
Candle
Fire
Firework
Police Car
Fire Truck
Ambulance
SOS
Made in China
705-LED6R0-00
OFF/ON
OFF/ON
OFF/ON
3.4 Brightness adjustment: press the upper adjustment
button to increase the brightness value while lower button
to decrease. Short press the button once and the
brightness value will changes in 1%. Long press the button
to adjust the value from 0 to 100% quickly.
Warranty
Dear customers, as this warranty card is an important certificate to apply
for our maintenance service, please fill in the following form in coordination
with the seller and safekeep it. Thank you!
Customer
Information
Name Contact Number
Address
Product
Information
Model Product Code Number
Seller
Information
Name
Contact Number
Address
Date of Sale
Note:
Note: This form shall be sealed by the seller.
Applicable Products
The document applies to the products listed on the Product Maintenance
lnformation (see below for further information). Other products or accessories
(e.g. promotional items,giveaways and additional accessories attached,etc.) are
notincluded in this warranty scope.
Warranty Period
How to Get the Maintenance Service
Inapplicable Cases
Maintenance and Service Support Information
The warranty period and service types of products are implemented
according to the following Product Maintenance Information:
Product
Type
Parts
Other
Items
Name
Circuit Board
Battery
Electrical parts e.g.
battery charger, power
cord, sync cable, etc.
Flash tube, modeling
lamp, lamp body, lamp
cover, lockingdevice,
package, etc.
The warranty period of products and accessories isimplemented according to the
relevant Product Maintenancelnformation. The warranty period is calculated from
the day(purchase date) when the product is bought for the first time,And the
purchase date is considered as the date registered onthe warranty card when
buying the product.
If maintenance service is needed, you can directly contact the product
distributor or authorized service institutions. You can also contact the
Godox after-sale service call and we will offer you service. When
applying for maintenance service, you should provide valid wananty
card. If you cannot provide valid warranty card, we may offer you
maintenance service once confirmed that the product or accessory is
involved in the maintenance scope, but that shall not be considered as
our obligation.
Godox After-sale Service Call
Maintenance
Period(month)
Warranty Service
Type
Customer sends
the product to
designated site
Without warranty
( )
(
)
()
12
3
12
0755-29609320-8062
12
3
12
No
0755-29609320-8062
Customer sends
the product to
designated site
Customer sends
the product to
designated site
OFF/ON
OFF/ON
OFF/ON
OFF/ON
OFF/ON
OFF/ON
QC PASS
OFF /ON
OFF/ON
OFF/ON
: 2
: 0755-29609320(8062) : 0755-25723423
: godox@godox.com
godox.com
Made in China
705-LED6R0-00
Produktspecifikationer
| Varumärke: | Godox |
| Kategori: | Flash |
| Modell: | LED6R |
| Vikt: | - g |
| Modell: | Camcorder-blixt |
| Färgtemperatur: | 6500 K |
| Produktens färg: | Svart |
| USB-port: | Ja |
| Nätaggregatstyp: | Batteri |
| Drifttid för batteri: | 10 h |
| Ungefärlig återanvändningstid: | - s |
| Spridare inkluderad: | Ja |
Behöver du hjälp?
Om du behöver hjälp med Godox LED6R ställ en fråga nedan och andra användare kommer att svara dig
Flash Godox Manualer
9 Januari 2025
9 Januari 2025
9 Januari 2025
9 Januari 2025
7 Januari 2025
9 December 2024
7 December 2024
6 Oktober 2024
29 September 2024
29 September 2024
Flash Manualer
- Nissin
- Kenko
- Quantum
- Kaiser Fototechnik
- Goodram
- SmallRig
- Cactus
- FoxFury
- Rollei
- SWIT
- Lastolite
- Canon
- Cullmann
- Xit
- Pentax
Nyaste Flash Manualer
1 April 2025
29 Mars 2025
29 Mars 2025
27 Mars 2025
9 Mars 2025
4 Mars 2025
27 Februari 2025
25 Februari 2025
6 Februari 2025
6 Februari 2025
