Sida 1/16
TTL
TTL Wir
For Cano
说 明
Instruction
705-X1C000-00
Made In China
地址/Add: 深圳市宝安区福永镇福洲大道西新和村华发工业园A4栋
Building A4, Xinhe Huafa Industrial Zone, Fuzhou RD West, Fuyong
Town, Baoan District, Shenzhen 518103, China
电话/Tel: +86-755-29609320(8062) Fax: +86-755-25723423传真/
邮箱/E-mail: godox@godox.com
神牛摄影器材有限公司
GODOX Photo Equipment Co., Ltd
可控从属单元组
传输范围(约)
频道
其他
时延设置
无线快门
ZOOM设置
显示屏
输出接口
固件更新
记忆功能
发射器尺寸/净重
接收器尺寸/净重
GR 分组模式下，最多5组(A/B/C/D/E)
Ratio光比分组模式下，3组(A/B/C)
>100米
32个
有(0~10ms，以100us为单位设置)
接收器端可以通过2.5mm同步接口控制相机拍摄
可以通过发射器调节闪灯焦距值
宽屏液晶显示，背光开启或关闭
发射器：PC 端子输入、输出；接收器：2.5mm同步线输出
通过机身上的 Micro USB进行固件升级
设置2秒后的参数会自动记忆，重新开机自动恢复
72x75x52(mm)/100g
70x65x47(mm)/70g
- 23 - - 24 -
Foreword
For Your Safety
Names of Parts
Body
LCD Panel
Accessories
Battery
Installing Batteries
Low Battery Level Indication
Using the Flash Trigger
As a Wireless Studio Flash Trigger
As a Wireless Speedlite Trigger
As a Wired Shutter Release
As a Wireless Studio Flash Trigger
or Speedlite
Trigger with PC Sync Socket
Setting the Transmitter
Power Switch
Power Switch of AF Assist Beam
Channel Settings
Mode Settings
Current Group Settings
25
26
28
31
32
Multi Flash Settings (Times & Frequency)
Multi Flash Settings (Output Value)
Group Settings
Test Flash
Modeling Lamp Control
Setting GR Grouping Mode
Automatically Enter Power Saving Mode
C.Fn: Setting Custom Functions
Wireless Shutter Release Mode
Setting the Camera
Setting the Receiver
Channel Settings
Group Settings
Automatically Enter Power Saving Mode
Selecting the Operation Method
Attentions
Caring for Flash Trigger
Technical Data
42
44
48
49
50
Contents
规格参数
34
兼容相机
Canon EOS 数码单反相机, 包括：
1Dx Mark II, 1Dx, 5Ds/5Dsr, 5D Mark III, 5D Mark II, 5D, 7D Mark II, 6D, 7D,
70D, 60D, 50D, 40D, 30D, 750D/760D, 100D, 700D, 650D, 600D, 550D, 500D,
450D, 400D DIGITAL(EOS Kiss Digital X), 350D DIGITAL, 1200D, 1100D, 1000D
Foreword
Thanks for your purchase of this X1C TTL wireless flash trigger.
This TTL wireless flash trigger can be used with a transmitter and one or more receivers for
studio flash, speedlite, and camera shutter. Featuring multi-channel triggering, stable signal
transmission, and sensitive reaction, it gives photographers unparalleled flexibility and
control over their strobist setups. The flash trigger applies to hotshoe-mounted Canon EOS
series cameras, as well as the cameras which have PC sync sockets.
With X1C wireless flash trigger, high speed synchronization is available for most of camera
flashes in the market which support E-TTL II. The max flash synchronization speed is up to
1/8000s *.
*: 1/8000s is achievable when the camera has a max camera shutter speed of 1/8000s. 1/8000s is not
achievable because some models of Canon EOS cameras have a max camera shutter speed of only 1/4000s.
- 25 -
For Your Safety
- 26 -
To prevent damage to your product or injury to you or to others, read the following safety
precautions in their entirety before using this device. Keep these safety instructions where
all those who use this device will read them.
Failure to observe the precautions listed in this section could result in damage to the
product.
The following icon indicates warnings that should be read before using this device in case
of possible damage or injury.
Do not disassemble or modify
Failure to observe this precaution could result in electric shock or product malfunction.
Should the product break open as the result of a fall or other accident, remove the
batteries and take the product to an authorized maintenance center for inspection.
Keep dry
Do not handle with wet hands or immerse in or expose to water or rain. Failure to
observe this precaution could result in fire or electric shock.
Do not use in the presence of flammable gas
Failure to observe this precaution could result in explosion or fire.
Keep out of reach of children
This device contains small parts which may pose a choking hazard. Consult a
physician immediately if a child swallows any part of this device.
Turn off the transceiver immediately in the event of malfunction
Should smoke or an unusual smell comes from this device, remove the batteries
immediately in case of burning and take the device to an authorized maintenance
center for inspection. Injuries could occur if it is further used.
Do not expose to high temperature
Do not leave the device in a closed vehicle in the sun or in other areas subject to
Produktspecifikationer
| Varumärke: | Godox |
| Kategori: | blixtenhet |
| Modell: | X1 (Canon) |
