Updated January 2015
TM
Dummy
PK146 Rev.2 11152015
Updated November 2015
Long Plate Door Hardware
— For doors without a 2-1/8” cross-bore
Insert the long plate screws and
tighten until snug.
Using a 7/64” drill bit, drill the screw
holes at least 3/4” deep.
Mark the holes
2-3/4" Backset
2-3/8" Backset
Desired
Determine backset (distance between edge of door
and center of rosette.) Check other doors in the house
to determine backset.
Height of
Knob/Lever
Edge of
Door
or
(Measure other
doors in the house
to determine this)
