Grandstream GWN7630LR Bruksanvisning

Grandstream accesspunkt GWN7630LR

Läs gratis den bruksanvisning för Grandstream GWN7630LR (139 sidor) i kategorin accesspunkt. Guiden har ansetts hjälpsam av 3 personer och har ett genomsnittsbetyg på 4.4 stjärnor baserat på 2 recensioner. Har du en fråga om Grandstream GWN7630LR eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/139

Grandstream Networks, Inc.

Wi-Fi Access Points

GWN76xx - User Manual

OVERVIEW

Grandstream’s powerful indoor and outdoor Wi-Fi Access Points (APs) offer high-performance networking and an exceptional

Wi-Fi coverage range. The outdoor series offers weatherproof certified casing and supports up to a 300-meter coverage

range. They are supported by GDMSNetworking and GWN Manager, Grandstream’s cloud and on-premise free management

platforms. Each device also includes an embedded controller within the product’s web user interface for easy administration of

locally deployed Wi-Fi APs. GWN Wi-Fi APs are ideal for any size business or enterprise and can be scaled over time as your

business grows.

PRODUCT OVERVIEW

Technical Specifications

GWN7670WM Technical Specifications

Caution

Changes or modifications to this product not expressly approved by Grandstream, or operation of this product in any way other

than as detailed by this User Manual, could void your manufacturer warranty.

Note

“Out of the box” Grandstream Access Points are not affected by this issue. APs with old firmware are only affected after

changing into client-bridge mode. Please refer to our white paper of “WPA Security Vulnerability”

here.

Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax/be

Antennas

5 single frequency antennas

2.4GHz x 2, gain 3.0dBi

5GHz x 2, gain 4.0dBi

BT gain 3.0dBi

Wi-Fi Data Rates

5G:

IEEE 802.11be: Up to 2882 Mbps

IEEE 802.11ax: 7.3 Mbps to 2402 Mbps

IEEE 802.11ac: 6.5 Mbps to 1732 Mbps

IEEE 802.11n: 6.5 Mbps to 300 Mbps

IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

2.4G:

IEEE 802.11be: Up to 688 Mbps

IEEE 802.11ax: 7.3 Mbps to 574 Mbps

IEEE 802.11n: 6.5Mbps to 300Mbps

IEEE 802.11b: 1, 2, 5.5, 11 Mbps

IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Note: Actual throughput may vary depending on many factors including environmental conditions, distance

between devices, radio interfe- rence in the operating environment and mix of devices in the network.

Frequency Bands

2.4GHz Radio: 2400 – 2483.5 MHz

5GHz Radio: 5180 – 5895 MHz

Note: Not all frequency bands can be used in all regions.

Channel Bandwidth

2.4G: 20 and 40 MHz

5G: 20, 40, 80, 160 MHz

Wi-Fi and System Security WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical

data/control lockdown via digital signatures, unique security certificate and random default password per

Produktspecifikationer

Varumärke:	Grandstream
Kategori:	accesspunkt
Modell:	GWN7630LR
Vikt:	564 g
Bredd:	533.1 mm
Djup:	115 mm
Höjd:	40 mm
Placering:	Tak
Antal användare:	200 användare (er)
MIMO-typ:	Multi User MIMO
Maximal dataöverföringshastighet:	1733 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Maximal dataöverföringshastighet (2,4 GHz):	600 Mbit/s
Maximal dataöverföringshastighet (5 GHz):	1733 Mbit/s
Antal kanaler:	4 kanaler
Produktens färg:	Vit
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	2
Kryptering/säkerhet:	WEP, WPA, WPA2-Enterprise, WPA2-PSK
Antenner mängd:	4
Antenn ökningsnivå (max):	3.5 dBi
Bluetooth:	Nej
Harmonized System (HS)-kod:	85176990
VLAN-funktioner:	SSID-based VLAN assignment
Antenntyp:	Intern
Antal SSID som stöds:	16
MIMO:	Ja
