Sida 1/2
3. Danger of heat generation due to insufficient ventilation of the
product/power supply!
You will be alerted to an imminently hazardous situation which
may result in serious injury or even death!
You will be alerted to a potentially dangerous situation that
could result in serious injury, even death!
You will be alerted to a potentially dangerous situation that
may result in minor injury!
Your attention is drawn to a possible situation that could result
in property damage and possibly environmental damage and
disrupt operations.
If you have any questions, please do not hesitate to contact our support at
support@graugear.de
or visit our website
www.graugear.de
1. Dangers due to electric current and voltage!
2. Possible dangers during assembly due to sharp-edged components!
• Please read the operating instructions before assembly.
• Avoid contact with sharp or pointed objects.
• Do not use force during assembly.
• Only use suitable tools or supplied accessories and tools.
Safety information
For your own safety and to avoid physical damage as well as damage to property, equipment
and loss of data, please observe the following instructions
Warning signs
• Avoid external heat supply and provide air exchange.
• Keep fan outlets and heat sinks free.
• Avoid direct sunlight on the product/power supply.
• Make sure there is enough environmental space for the product/power supply.
• Do not place any objects on the device/power supply.
• Please be sure to read the instructions for use.
• Keep small parts and accessories safe from children.
• Keep and dispose of plastic bags and packaging from children.
• Never put small parts and packaging into children's hands!
4. Danger of suffocation! Danger due to small parts and packaging!
• Please be sure to read the operating instructions.
• Use the product only if all specifications and requirements are met.
• Always perform a data backup of storage media to be installed.
• Always perform a data backup before commissioning.
• Always perform a data backup before connecting new hardware.
• Only use the accessories supplied with the product.
5. Possible data loss / data loss during commissioning.
6. Cleaning of the product.
• Take the product out of operation before each cleaning.
• Do not use aggressive / harsh cleaners.
• Make sure that there is no residual moisture in the device after cleaning.
• It is best to use an antistatic cloth for cleaning.
7.
Disposal of the product - environmental pollution, recycling not possible!
•
Avoid any contact with electrically conductive parts, there is a danger to life due to electric shock.
•
Please read the operating instructions before use.
•
Make sure the product is not energized before opening or working on it.
•
Please do not remove the contact protection cover under any circumstances.
•
Avoid contact with live parts.
•
Do not touch any plug-in connectors with metallic or pointed objects.
•
Use the product only in designated environments.
•
If necessary, operate the product only with power supplies that correspond to the nameplate.
•
Do not expose the product or power supply to moisture and liquid, steam and dust.
•
Do not make any independent modifications to the product.
•
Do not connect / use the product during a thunderstorm.
•
In case of repair, please contact the specialist dealer or GrauGear.
Cutting and hand injuries possible during assembly.
Danger to life due to choking and swallowing.
Irrecoverable data loss possible!.
Damaging cleaning agent - scratches, color changes, moisture damage or short circuit on the device.
"The adjacent symbol on the product and packaging indicates that this product must not
be disposed of with other household waste. If necessary, remove old batteries,
rechargeable batteries and lamps before returning the product (if possible without
destroying the old device and if it is not to be reused).
According to the Waste Electrical and Electronic Equipment (WEEE) Directive, you may
not dispose of this product and any batteries/rechargeable batteries it may contain in
your normal household waste.
If you wish to dispose of this product/batteries, please take them to a suitable disposal
point (recycling collection point in your city) or return them to your point of purchase."
Ohlstedter Strasse 17, 22949 Ammersbek / Germany
Made in China
© Copyright 2021 by CHAB GmbH. All Rights Reserved
Windows and the Windows logo are registered trademarks of Microsoft Corporation.
Apple, macOS, MAC, iTunes and Macintosh are registered trademarks of Apple Computer.
In this case, overheating and/or failure of the product/power supply unit is possible.
www.graugear.de
G-M2DK-CL-20G
Clone Station
for 2x M.2 NVMe SSD
USB3.2 Gen2x2
Using A Brand New Hard Drive
lf you are using a brand new drive, you might have to initialize it
before you can use it.
Open Computer Management >> Storage Disk Management, then
right-click on the disk you want to initialize, and select Initialize Disk
on the drop-down menu.
Please make sure that the correct disk is selected.
Only initialize a disk if you are absolutely sure it
is a brand new one with out any of you data.
Drive is Connected but Missing in File Explorer
Open Computer Management >> Storage Disk Management,
then right-click on the disk marked as Offline and select Online on
the drop-down menu.
Package Contents
Features
Specification
Startup with SSDs
Back
Top
Remove protective films
of thermal pad and paste
it on the M.2 SSD.
Source SSD
Slot
Target SSD
Slot
G-M2DK-CL-20G Aluminum Heatsink
Type-C
®
cable
User Manual
Thermal Pad
Service Card
Rubber Rim
A B
C
Install thermal silicon, M.2 SSD,
and heatsink.
1
Insert the M.2 SSD card
into the slot.
3
Insert the transparent protective
tube into the clone station.
4
5
Put the aluminum alloy radiator
on two Rubber Rim.
2
A
B
C
Connect the power adaspter.
If no use stand-alone clone
function please connect the USB
data cable with the computer.
B
Power ON/OFF
Power in
Type-C
Fan Cooling
Off/Weak/Strong
Power LED
•Interface : M.2 M-Key
•External interface : USB3.2 Gen2x2 Type-C
®
•Controller : JMS586U
•Supports SSD : M.2 NVMe SSD lenghs: 2230, 2242, 2260, 2280 and 22110
•Transfer speed : PCIe USB3.2 Gen2x2 up to 20Gbit/s (Theoretic)
•Product material: Plastic / Aluminum
•Dimensions: L82 x W77 x H133mm
•Cable length: 35cm / 13.78 inches
•Supports PCIe p1-x4 data transfer rates up to 20Gbps
•Bootable SSD cloning, without PC (stand-alone)
•Compatible with M.2 NVMe SSD size of 2230, 2242, 2260, 2280, 22110
•Supports PCIe NVMe M.2 SSD of M-Key
•60mm fan for active cooling
•Premium aluminum heat sink with excellent cooling effort
•One-Key offline clone
•LED indication of the cloning progress
•LED indicator for power and access
•Power adapter 5V / 2A
•Supports Windows
®
and MacOS
®
Clone Button
Clone Process LED Indicators
Work LED Indicator
SOURCETARGET
TARGET ≥ SOURCE
Do not install any disks while
the device is powered .
Power Supply
Adapter
Please make sure the capacity
of the target SSD is larger than
the source SSD or same larger
than the source SSDD, otherwise
the clone function will not work.
(1) Insert M.2 NVMe SSD to Slot (Source Drive) or (Target Drive) or both
simultaneously.
(2) Connect the device with SuperSpeed USB 3.2 Gen2x2 Cable to any Desktop or
Notebook
(3) Connect the Power cord and turn on the device.
(4) Go to Disk Management to format the M.2 NVMe SSD
(5) Ensure the you properly and Safely Remove the USB Device to allow both
slots to turn off
Note : Formatting is necessary for only NEW SSD, any damage caused
during operation will be personal liability.
Desktop/Notebook Clone Station Mode
Instructions for Stand-Alone-Cloning
(only works if the clone station is not connected to the pc.)
1. Before you start cloning, seperate the usb cable from the device.
2.
Now insert the Source-SSD in the slot [SOURCE] and the Target-SSD in the slot [TARGET] ein.
3. Connect the power adaptor in the power outlet and and turn the Clone Station on.
4. Press and hold the Clone Button for at least 5 seconds, until the four conling progression
LED´s 25%-100% start blinking in a row back and forth.
5. Press the clone button again and the clone progression LEDs blink again.
6. As soons as the 25% LED is glowing constantly, the cloning process starts. The LEDs show
the cloning progress. The cloning time depends on the capacity oft p1-he SSD.
7. As soon as the 100% LED is glowing and not blinking anymore, the cloning process is
finished. Please, turn of the Clone Station before removing any SSD.
1. The clone function creates an identical copy of your hard drive – no need to
connect to any computer.
2.
You can copy a bootable system disk without additional software or professional skills.
3. Since the cloning process copies every single byte of the source SSD the process
may take several hours depending on the SSD capacity.
4. After the cloning process is completed, in some cases the computer may not be able
to identify both SSD since they are assigned to the same drive letter. To separate the
drives, you must assign one drive to a new drive letter under "disk management” (Windows).
5. If only one SSD is plugged into slot (SOURCE), and there will be no action when
you press the start button.
6. The capacity of the target SSD must be the same size or larger than source SSD.
7. You may create a new volume with the remaining space on the target SSD
after cloning.
Clone Notes
