AR-125

HANGING SKIMMER

SKIMMER DE MOCHILA

SKIMMER HORS-BORD

HÄNGEFILTER

FILTRO A PARETE

HANGEND SKIMMER

SKIMMER DE MOCHILA

INSTALLATION AND MAINTENANCE MANUAL

MANUAL DE INSTALACIÓN Y MANTENIMIENTO

MANUEL D’INSTALLATION ET D’ENTRETIEN

EINBAU-UND BETRIEBSANLEITUNG

MANUALE DI INSTALAZIONE E MANUTENZIONE

INSTALLATIE-EN ONDERHOUDSHANDLEIDINGE

INSTRUÇÕES E MANUTENÇÃO

ENGLISH

IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be implemented

for installation and start-up. Therefore, the installer as well as the user must read the instructions before beginning installation

and start-up.

Keep this manual for future reference.

To achieve optimum performance of the Hanging Skimmer, follow the instructions provided below:

SAFETY INSTRUCTIONS. READ CAREFULLY

• The following standard should be followed in the whole electrical installation:

NF C15-100

that refers to “the construction of electrical installations both in indoor and outdoor swimming pools”, or similar regulations in force

in each area or country.

• “The entire filtering system follows the installation standard C 15-100 that stipulates that all electrical apparatus located at less

than 3.5 m. from the swimming pool and freely accessible should have a very low voltage of 12 V. All 220 V apparatus should be

positioned at least 3.5 m. from the edge of the swimming pool. Apply to the manufacturer for permission to modify one or more

elements of the filtering system”.

• The filter conforms to regulations NF P90-318 y NF P90-319

• Filter medium type: synthetic based cartridge filter

• After using chemical products for treating pool water, it is recommended that a minimum filter time is adhered to for the health

protection of bathers, in accordance to health regulations.

• Electrical installations should only be performed by professional installers qualified in electrical installations.

• The apparatus should not be on while the swimming pool is being used.

• Do not operate the apparatus without water.

• People should NEVER touch the apparatus when it is on if they are wet or with wet hands.

• DISCONNECT the apparatus from the mains before handling.

• Ensure that the ground is dry before touching the electrical equipment.

• Never place the apparatus where it could become wet, as this could cause electrocution.

• Do not allow children or adults to lean against or sit on the apparatus.

• Never use the apparatus for more than 4 consecutive hours.

• If the flexible power supply cable of the apparatus is damaged, it should be replaced. Read instructions how to replace it

carefully. If in doubt, consult your technical service.

DESCRIPTION AR125

Filtering speed 2,99 (m³/h)m²

Flow rate 3,8 m³/h

Filtration threshold 10 µm

Retention capacity g

Filtration area 1,27 m²

Motor 70 W

Motor voltage 12 V ~

Transformer 230 / 12 V ~

Fréquence 50 Hz

Protection CLASE I IPX8

1. VERIFY THE CONTENTS OF THE PACKING:

The apparatus that you have just purchased has been designed for elevated swimming pools, with an innovative and highly functional design.

The following components detailed on page 30 are contained inside the box.

2. GENERAL CHARACTERISTICS:

This Skimmer has been designed for use in fresh water pools. It is a Class I electric apparatus which complies with the IPX8 degree of

protection (resistance to penetration of dust, solid bodies and humidity).

CONNECTION OF APPARATUS

Connect the transformer to a 230V 50 Hz source of alternating current which is equipped with a single-pole switch, so that the apparatus does

not receive any voltage when it is not in use, and a 30 mA differential for discharge protection.

The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric components which have been

inserted or handled at locations other than its own premises.

3. INSTALLATION:

This equipment is easy to install and can be assembled by AN ADULT in around 1 HOUR, taking care to correctly follow the instructions

detailed in this manual at all times.

The following tools are needed to correctly handle and install the components:

Function

Tool

Alternative tool

Tighten screws

Philips screwdriver

7 mm Stecker screwdriver

Cut out liner

Cutter

Blade

Produktspecifikationer

Varumärke:	GRE
Kategori:	pool
Modell:	AR125
Produkttyp:	Patronfilterpump
Vikt:	6450 g
Höjd:	700 mm
Förpackningens bredd:	250 mm
Typ av vattenfilter:	Filterkassett
Certifiering:	EN16713
Vattenfilter:	Ja
skyddsklass:	I
Spänning:	12 V
Filtreringskapacitet:	3800 l/h
Förpackningsvolym:	40250 cm ^
Produktens färg:	Vit
Förpackningstyp:	Låda
Låddjup:	230 mm
Vikt inkl. förpackning:	- g
Produkter per lastpall:	35 styck
Intrastat-kod:	95069990
Internationellt skydd (IP) kod:	IPX8
Strömkälla av typen:	AC
Minsta orderkvantitet:	1 styck
Pumpeffekt:	70 W
