Sida 1/149

24227

40V Cordless Vacuum Blower

USER’S MANUAL

40V kabelloser Gartensauger/Laubbläser BEDIENUNGSANLEITUNG

Soplador aspirador inalámbrico de 40V MANUAL DE UTILIZACIÓN

Aspiratore e Soffiatore senza cavo da 40V MANUALE D’USO

Souffleuse - aspirateur portable sans fil de 40 V

Soprador / aspirador sem fios de 40V MANUAL DE UTILIZAÇÃO

GNIDIELDNAHSREKIURBEGrezalb/regiuz ezolreons V04

AJRIKISÄK NÄJÄTTYÄKnillahupirumi notagnal V 04

KOBSNOITKURTSNIerasålb/gus irflebak V 04

40V batteridrevet vakuumblåser BRUKSANVISNING

40V ledningsfri vakuumblæser BRUGERVEJLEDNING

40V akkumulátoros szívógép/fúvógép HASZNÁL ATI ÚTMUTATÓ

40V Kablosuz Yaprak Toplama/Üfleme Makinesi KULLANICI KILAVUZU

104

1108

112

116

120

124

MANUE L D’UTILISATION

SPECIFICATIONS

Type

24227

Motor 40 Volt DC

Air Velocity 280 km/h (Max)

Weight (Battery

Pack not included)

4 kg

Battery Pack 29717/29727

Charger 29417 / 29447

Measured sound

pressure level

LpA: 90dB(A) KpA:2 dB(A)

Measured sound

power level

LWA: 104dB(A)

Vibration Ah: 3.5m/s , k:1.5m/s

DESCRIPTION

1. Variable switch

2. Low/high button

3. ON/OFF button

4. Auxiliary handle

5. Mulch/vacuum gate

6. Lock button

7. Blower tube

8. Mulcher tube

9. Bag

ASSEMBLY

UNPACKING

from the box.

breakage or damage occurred during shipping.

carefully inspected and satisfactorily operated the

product.

Greenworks Tools service centre for assistance.

The blower vac is supplied with some components not

assembled. To assemble these, proceed as follows:

ASSEMBLE AS A MULCHER

See Figure 2.

locked. (See fig 2)

Hold the gate open. (See fig 2.1)

the rear clip. (See fig 2.2). Push the “hooked” end clip

of the mulcher tube into the front clip. (See fig 2.3).

Press the lock button back to engage the mulcher

tube. (See fig 2.4)

bag adaptor with the lock button. To remove the bag,

simply press lock button and remove bag. (see Fig.4).

NOTE: It may be necessary to remove the blower tube or

mulcher tubes to clear a blocked tube or impeller.

WARNING

To prevent serious personal injury, make sure the

switch is in the OFF position, it is unplugged, and the

impellers have stopped before attaching or removing

tubes.

ASSEMBLE AS A BLOWER See Figure 3.

the blower housing click into the slots on the tube.

INSTALLING BAG WITH SHOULDER HARNESS See

Figure 4.

length to fit the operator's size. Pull the tab lengthen ,

pull the strap to shoten.

For complete charging instructions, refer to the

Operator’s Manuals for your battery pack and

charger models.

NOTE: To avoid serious personal injury, always remove

the battery pack and keep hands clear of the variable

speed trigger when carrying or transporting the tool.

TO INSTALL BATTERY PACK

See Figure 5.

on battery pack with grooves in the blower’s battery

port.

snaps in place and that battery pack is secured in the

blower before beginning operation.

10. 40V lithium-ion battery

11. Notched area

12. Air outlet

13. Slot

14. Tab

15. Strap

English (original instructions)

DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET

2 2

Produktspecifikationer

Varumärke:	Greenworks
Kategori:	lövblåsare
Modell:	GD40BV
Vikt:	2180 g
Modell:	Handhållen lövblås
Luftflöde:	544 m³/h
Ljudtrycksnivå:	90 dB
Vibrationsemission:	3.5 m/s ²
Produktens färg:	Black, Green
Effekt:	- W
Batterispänning:	40 V
Strömkälla:	Batteri
Ljudnivå Lc IEC:	90 dB
Kurshastighet:	185.08 km/t
Strömkabel längd:	0 m
Onogrannhet K:	1.5 m/s ²
Kapacitet påse:	45 l
Arbeta typ:	Blåsning/sugning
