GD40CS18

1 Description.................................... 5

1.1

Overview.................................................... 5

2 Safety............................................ 5

3 Installation..................................... 5

3.1 Unpack the machine...................................5

3.2 Assemble the guide bar and the chain.......5

3.3 Install the battery pack............................... 5

3.4 Remove the battery pack........................... 6

4 Operation.......................................6

4.1 Examine the chain lubrication.................... 6

4.2 Hold the machine....................................... 6

4.3 Start the machine....................................... 6

4.4 Stop the machine....................................... 6

4.5 Operate the chain brake.............................6

4.6 Fell a tree................................................... 6

4.7

Limb a tree................................................. 7

4.8 Buck a log...................................................7

5 Maintenance..................................7

5.1 Adjust the chain tension............................. 7

5.2 Sharpen the cutters....................................8

5.3 Guide bar maintenance..............................8

5.4 Add the bar and chain lubricant..................8

6 Transportation and storage........... 9

7 Troubleshooting.............................9

8 Technical data.............................10

9 Warranty......................................10

10 EC Declaration of conformity.......10

English

1 DESCRIPTION

1.1 OVERVIEW

Figure 1-22

Guide bar cover

Front handle

guard / chain brake

Front handle

Lock out button

Trigger

Oil tank cap

Oil indicator

Spike bumpers

Saw chain

Guide bar

Wrench

Rear handle

Chain tension

screw

Chain cover

Chain cover nuts

Bolt for saw chain

tension

Sprocket

Battery release

button

Oil outlet

Bar groove

Chain drive links

Cutter

Felling direction

Danger zone

Escape route

Direction of fall

Notch

Felling back cut

Hinge

Limb cut

Keep work off

ground leave

support limbs until

log is cut

Log supported

along the entire

length

Cut from top (over

buck) avoid cutting

earth

Log supported one

end

Under buck

Over buck

Log supported both

ends

Bucking a log

Stand on uphill side

when cutting

because log may

roll

2 SAFETY

WARNING

Make sure that you do/obey all safety instructions.

Refer to Safety Manual.

3 INSTALLATION

WARNING

Do not change or make accessories that are not

recommended by the manufacturer.

WARNING

Do not put in the battery pack until you assemble all

the parts.

3.1 UNPACK THE MACHINE

WARNING

Make sure that you correctly assemble the machine

before use.

WARNING

• If the parts have damage, do not use the machine.

• If you do not have all the parts, do not operate the

machine.

• If the parts are damaged or missing, speak to the

service center.

1. Open the package.

2. Read the documentation in the box.

3. Remove all the unassembled parts from the box.

4. Remove the machine from the box.

5. Discard the box and package in compliance with

local regulations.

3.2 ASSEMBLE THE GUIDE BAR AND

THE CHAIN

Figure 1-7.

1. Remove the chain cover nuts with the wrench.

2. Remove the chain cover.

3. Put the chain drive links into the bar groove.

4. Put the chain cutters in the direction of the chain

operation.

5. Put the chain in position and make sure that the

loop is behind the guide bar.

6. Hold the chain and bar.

7. Put the chain loop around the sprocket.

8. Make sure the chain tension pin hole on the guide

bar fits correctly with the bolt.

9. Install the chain cover.

10. Tighten the chain. Refer to

Adjust the chain tension.

11. Tighten the nuts when the chain is well tensioned.

NOTE

If you start the chain saw with a new chain, have a test

for 2-3 minutes. A new chain gets longer after the first

use, examine the tension and tighten the chain if

necessary.

3.3 INSTALL THE BATTERY PACK

Figure 2

English

Produktspecifikationer

Varumärke:	Greenworks
Kategori:	Sågmaskin
Modell:	GD40CS18
Vikt:	3810 g
Motor:	Borstlös
Ljudeffektnivå:	95 dB
Ljudtrycksnivå:	87 dB
Vibrationsemission:	2.5 m/s ²
Ergonomiskt handtag:	Ja
Bladlängd:	- mm
Kedjehastighet:	20 m/s
Automatisk smörjning:	Ja
Produktens färg:	Black, Green
Batterispänning:	40 V
Strömkälla:	Batteri
Tomgångsvarvtal:	- RPM
Kedja svärdslängd:	350 mm
Kedjedelning:	3/8 "
Kedjebroms:	Ja
Kedjebyte/-justering utan verktyg:	Nej
Kedja mätare:	1.3 mm
