This Certificate is for the exclusive use of Intertek's client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and

conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this

Certificate. Only the Client is authorized to permit copying or distribution of this Certificate. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material,

product or service must first be approved in writing by Intertek.

Intertek Page 1 of 3 - - -23a (18-Dec- 9) SFT PV OP 201

Certificate of Conformity

Certificate Number: - -CN PV 200079

Applicant Name & Address:

Shenzhen Growatt New Energy Technology CO.,Ltd

1st East & 3rd Floor of Building A, Building B, Jiayu Industrial Park, #28,

GuangHui Road, LongTeng Community, Shiyan Street, Baoan District,

Shenzhen, P.R.China

Product Description:

Hybrid Inverter

Ratings & Principle

Characteristics:

See Annex to Certificate of Conformity

Models/Type References:

Brand Name:

MIN 2500TL-XH, MIN 3000TL-XH, MIN 3600TL-XH, MIN 4200TL-XH,

MIN 4600TL-XH, MIN 5000TL-XH, MIN 6000TL-XH

Growatt

Specification/Standard:

EN 50549-1: 2019, Requirements for generating plants to be connected

in parallel with distribution networks

Part 1: Connection to a LV distribution network - Generating

plant up to and including Typ s e B

Compliant with COMMISSION REGULATION (EU) 2016/631 (NC RfG)

Type approval for type B

Certificate Issuing Office Name

& Address:

Intertek Testing Services Ltd. Shanghai

2/F (West Side), No. 707, Zhangyang Road, Free Trade Exp imental Area, er

Shanghai, P. R. China

Test Report Number:

1 829065 -001, Revision 1: 14 Jul 2020 90 GZU

Additional information in Appendix.

Signature

Name: Grady Ye

Date: 17 July 2020

On the basis of the tests undertaken, the samples of the below product have been found to comply with the

requirements of the referenced specifications /standards at the time the tests were carried out. It does not imply that

Intertek has performed any surveillance or control of the manufacture. The manufacturer shall ensure that the

manufacturing process assures compliance of the production units with the examined products mentioned in this

certificate.

conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this

product or service must first be approved in writing by Intertek.

Intertek Page 2 of 3 - - -23a (18-Dec- 9) SFT PV OP 201

Ratings & Principle

Charact tics: eris

Model

MIN 2500TL-

MIN 3000TL-

MIN 3600TL-

MIN

4200TL-XH

Max.PV voltage

500 d.c.V

550 d.c.V

PV voltage range

80-500 d.c.V

80-550 d.c.V

PV Isc

16 d.c.A*2

Max.input current

12.5 d.c.A*2

Max. DC voltage

480 d.c.V

DC voltage range

3 -4 V 50 80 d.c.

Max. DC current

10 d.c.A

Max.output power

2500W

3000W

3600W

4200W

Max.apparent

power

2500VA

3000VA

3600VA

4200VA

Nominal output

voltage

230 a.c.V

Max.output

current

11.3 a.c.A

13.6 a.c.A

16 a.c.A

19 a.c.A

Nominal output

Frequen cy

50Hz

Power f r range acto

0.8Leading 0.8 lagging –

Safety level

Class I

Ingress Protection

IP 65

Operation Ambient

Temperature

- - +6025℃ ℃

Software Version

AL 1.0

APPENDIX Certificate of Conformity :

This is an Appendix to Certificate of Conformity Number: - -200079 CN PV .

conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this

product or service must first be approved in writing by Intertek.

Intertek Page 3 of 3 - - -23a (18-Dec- 9) SFT PV OP 201

Ratings & Principle

Characteristics:

Model

MIN 00TL-XH46

MIN 5000TL-XH

MIN 6000TL-XH

Max.PV voltage

550 d.c.V

PV voltage range

80-550 d.c.V

PV Isc

16 d.c.A*2

Max.input current

12.5 d.c.A*2

Max. DC voltage

480 d.c.V

DC voltage range

3 -480 d.c.V 50

Max. DC current

10 d.c.A

Max.output power

4600W

5000W

6000W

Max.apparent

power

4600VA

5000VA

6000VA

Nominal output

voltage

230 a.c.V

Max.output

current

20.9 a.c.A

22.7 a.c.A

27.2 a.c.A

Nominal output

Frequency

50Hz

Power factor range

0.8Leading 0.8 lagging –

Safety level

Class I

Ingress Protection

IP 65

Operation Ambient

Temperature

- - +6025℃ ℃

Software version

AL 1.0

APPENDIX Certificate of Conformity :

This is an Appendix to Certificate of Conformity Number: - -200079 CN PV .
