KITCHEN EXTRACTOR HOOD

OKAP WYSPOWY(WENTYLACYJNY)

KUCHYŇSKÁ VENTILAČNÍ DIGESTOŘ

KUCHYNSKÝ VENTILAČNÝ DIGESTOR

KONYHAI PÁRAELSZIVÓ

GZ-646

USER’S MANUAL

INSTRUKCJA OBSŁUGI

NÁVOD K OBSLUZE

NÁVOD NA OBSLUHU

ASZNÁLATI UTASITÁS

Dear customer!

Thank you for choosing the products of the brand " GUZZANTI ". We put our best efforts so you were

satisfied with your choice.

1. GENERAL INFORMATION

1.1 Prior to installing the extractor hood carefully read our recommendations, following which will

provide safe work of the appliance. Save this User’s manual, as it contains answers to the questions which

may arise later.

BEFORE STARTING THE OPERATION (SWITCHING ON) THE APPLIANCE MUST BE HELD

AT THE ROOM TEMPERATURE FOR AT LEAST TWO HOURS.

1.2. This appliance is intended for extraction of polluted air from the space above the cooking appliance,

and intended for domestic use and the household environment only.

USE OF THE APPLIANCE IN GOALS OTHER THAN DOMESTIC IS FORBIDDEN. THE RISK

OF INJURY AND PROPERTY DAMAGE INCREASES IN CASE OF USE OF THE EXTRACTOR

HOOD WITH PURPOSES OTHER THAN INTENDED, WHAT WILL LEAD TO WARRANTY

CANCELLATION.

1.3. Use of the extractor hood decreases the content of harmful products of incomplete combustion of

natural gas, as well as odors produced during cooking in the air, and prevents pollution of walls, ceiling, and

furniture with grease and soot.

1.4. The appliance is an air purifying device of the exhaust type with a diameter fan (turbine), completed

with a grease picking aluminum filter (included) and has the option of upgrading with a carbon fiber. It is

manufactured from sheets of carbon steel with a decorative protective coating of powder paints - 600 / 900

mm in width.

1.5. Depending on the installation scheme over the cooker, the extractor hood can work in two variants:

- in the mode of air extraction into the stationary ventilation shaft (chimney) of the kitchen using

corrugated aluminum or plastic air-ducts Ø120mm (see item 5.3);

- in the recirculation mode (closed circular air circulation in the kitchen), when the extractor hood is not

connected to chimney, and the air is passed through aluminum grease filter (included) and smothering

carbon fiber and is returned to the kitchen (see paragraph 5.3).

1.6. Attention! Do not start extractor hood installation before connecting it to electricity network and

checking its technical serviceability, and checking all of its functions.

1.7. We recommend that all installation works, connection, and repair of your extractor hood should be

carried only by qualified specialists professionally engaged in the execution of such works.

1.8. The manufacturer does not bear responsibility for any damages and failures, caused by incorrect

installation, operation, and repair of the extractor hood.

1.9. The manufacturer reserves the right to modify the product in order to improve its quality and

technical specifications.

1.10. Technical specifications for the extractor hood are indicated in this manual and on the label attached

to the inner surface of the body (access to it opens when the filter is removed).

Attention! The extractor hood should be installed on the wall at the distance of 650-750mm above

the electric cooker and at the distance 750-850 mm above the gas cooker.

2. MAIN TECHNICAL SPECIFICATIONS

Model of kitchen extractor hood

GZ-646

Network voltage, V 220-230

AC frequency, Hz 50

Control type мechanics

Number of operation modes 3

Rated power consumption, W

Of the motor 70

Lighting (LED) 2x2

General

Productivity while connecting to standard ventilation system m

/hour 163

Overall dimensions of the

extractor hood, mm

Width

595

Depth

460

Height

112

Connection size of ventilation duct, mm Ø120

Weight, kg __

Noise level, dB __

Protection class II

Operation mode S1 (long-lasting)

Electro cable type Armoured

3. PARTS SUPPLIED

Item Quantity

Kitchen extractor hood 1 pcs.

Plastic pipe adapter (Ø120mm) 1 pcs.

Dowel ø8х40 2 pcs.

Screws 2 pcs.

Exhaust air cover (for recirculation mode) 1 pcs.

User’s manual 1 pcs.

4. SAFETY REQUIREMENTS

ATTENTION!

IT IS FORBIDDEN TO CONNECT THE EXTRACTOR

HOOD

TO THE NETWORK OF THE ELECTRIC COOKER.

PROTECT ELECTRIC CORD FROM MECHANICAL AND

THERMAL DAMAGE.
