Arbitrary Function Generator
AFG-2000 Series
USER MANUAL
GW INSTEK PART NO. 82AF-21200EC1
ISO-9001 CERTIFIED MANUFACTURER
This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will Corporation.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve its products and therefore
reserves the right to change the specifications, equipment, and
maintenance procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
TABLE OF CONTENTS
1
Table of Contents
SAFETY INSTRUCTIONS .................................. 3
GETTING STARTED ......................................... 8
Main Features ..................................................................... 8
Panel Overview .................................................................. 10
Setting up the Function Generator .................................... 16
QUICK REFERENCE ....................................... 18
How to use the Digital Inputs ........................................... 19
Selecting a Waveform ........................................................ 21
ARB ................................................................................... 23
Modulation ........................................................................ 24
Sweep (2100 series only) ................................................... 28
Counter (2100 series only) ................................................ 30
Save/Recall ........................................................................ 31
Default Settings ................................................................ 32
OPERATION .................................................. 34
Select a Waveform ............................................................. 36
Setting the Frequency ........................................................ 36
Setting the Amplitude........................................................ 37
Setting the DC Offset ........................................................ 38
Setting the Duty Cycle/Symmetry ...................................... 39
Setting the Output Impedance .......................................... 41
Turning the Output On ...................................................... 42
Amplitude Modulation (AM) (AFG-2100 Series) ............... 43
Frequency Modulation (FM) (AFG-2100 Series) ................. 51
Frequency Shift Keying (FSK) Modulation (AFG-2100 Series)
.......................................................................................... 59
Frequency Sweep (AFG-2100 Series) .................................. 67
Creating an Arbitrary Waveform ......................................... 73
