Sida 1/8

3.17.01.02.079.00 / UO

User's

Manual

Free Standing Gas Cookers

with Gas Ovens

HGS50W HGS60W

To request a service call Tel. 01759 487830

CONTENTS

Introduction

Installation

Operation

Maintenance and cleaning

General warranty conditions

Technical specications

Attention

• Read carefully the user’s manual before use and installation of the

appliance.

• Keep the user’s manual for future use.

• This appliance is not designed for industrial or laboratory use. Use

this appliance only for its intended use.

THESE INSTRUCTIONS MUST BE FOLLOWED:

Remove all internal and external packing materials from the appliance

and check for transportation damage.

In case of damage, do not operate the appliance and contact your

authorised service provider.

Keep children away from all packaging, which may cause danger.

Prior to installation, ensure that the main voltage conditions and the

adjustment of the appliance are compatible.

This appliance must not be used to heat a room.

This appliance must be installed and connected in accordance with

current installation regulations.

Particular attention should be given to the relevant requirements

regarding ventilation.

The use of cooking appliances results in the production of heat and

moisture in the room in which it is installed. Ensure that the kitchen

is well ventilated: keep natural ventilation holes open or install a

mechanical ventilation device (mechanical extractor hood). Prolonged

intensive use of the appliance may call for additional ventilation, for

example opening of a window, or increasing the level of mechanical

ventilation where present.

To request a service call Tel. 01759 487830

TECHNICAL SPECIFICATIONS:

Regulation (EU) 65/2014

Brand HADEN HADEN

Models HGS50W HGS60W

Construction Freestanding Freestanding

Number of cavities Nbr. 1 1

Energy e󰀩ciency index cavity I EEI 82.3 76

Energy e󰀩ciency class cavity I A A

Energy consumption conventional heating, cavity I MJ/cycle 4.68 4.77

Energy consumption fan forced heating, cavity I MJ/cycle - -

Heat source cavity I Gas Gas

Volume cavity I 49 62

Energy e󰀩ciency index cavity II EEI

Energy e󰀩ciency class’) cavity II

Energy consumption conventional heating, cavity II kWh/cycle

Energy consumption fan forced heating, cavity II kWh/cycle

Heat source cavity II

Volume cavity II

A+++ (most E󰀩cient) to D (least e󰀩cient)

Regulation (EU) 66/2014

Brand HADEN HADEN

Model HGS50W HGS60W

Type of hob Freestanding Freestanding

Number of gas burners Nbr. 4 4

0 Heating zone I mm 1.15 1.15

0 Heating zone II mm 0.92 0.92

0 Heating zone III mm 0.92 0.92

0 Heating zone IV mm 0.72 0.72

Energy e󰀩ciency gas burner I % 61.3 61.3

Energy e󰀩ciency gas burner II % 57.1 57.1

Energy e󰀩ciency gas burner III % 57.1 57.1

Energy e󰀩ciency gas burner IV % - -

Energy e󰀩ciency for the gas hob % 58.5 58.5

To request a service call Tel. 01759 487830

WARNING!

This appliance is not intended for use by people (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless it is under supervision or having

been given instructions concerning the use of the appliance by a

person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance.

INTRODUCTION:

1. Gas Burners

2. Oven Lamp (optional)

3. Ignition (optional)

4. Oven Control Knob

5. Door Handle

6. Oven Door

Produktspecifikationer

Varumärke:	Haden
Kategori:	Spis
Modell:	HGS50W
Produkttyp:	Fristående köksspis
Inbyggd display:	Nej
Bredd:	50 mm
Djup:	60 mm
Höjd:	90 mm
Grill:	Ja
Avfrostningsfunktion:	Nej
Ugnens strömkälla:	gas
Antal ugnar:	1
Energiförbrukning (konventionell):	4.68 kWh
Ugnsstorlek:	Medium
Produktens färg:	Vit
Kontrolltyp:	Rotations-
Wok brännare:	Nej
Ugnens nettokapacitet:	52 l
Typ av spishäll:	Gas
Antal brännare / zoner matlagning:	4
Ugnens invändiga ytbehandling:	Emalj
