KNX radio wall-transmitter 1gang/2gang at quicklink
Page 1/7
6W-583008-2012
KNX radio wall-transmitter 1gang/2gang at quicklink
Order no.: 8565 p1-x2 xx
KNX radio wall-transmitter 1gang/2gang at solar quicklink
Order no.: 8565 p1-x1 xx
Operating instructions
1. Safety instructions
Electrical equipment may only be installed and assembled by a qualied electrician in
accordance with the relevant installation standards, guidelines, regulations, directives,
safety and accident prevention regulations of the country.
Failure to comply with these instructions may result in damage to the device, re or other
hazards.
Button cells do not belong in children's hands! If button cells are swallowed, seek imme-
diate medical assistance.
Danger of explosion! Do not throw batteries in re.
Danger of explosion! Do not recharge batteries.
The radio transmission is not suitable for safety or alarm applications.
These instructions are an integral component of the product and must be retained by the
end user.
2. Design and layout of the device
(1)
(2)
(3)
(5)
(6)
(8)
(1)
(2)
(4)
(5)
(7)
(8)
Figure 1: Design and layout of the device
(1) Supporting plate
(2) Frame (not within scope of delivery)
(3) Exemplarily Radio wall-transmitter 1gang at solar quicklink
(4) Exemplarily Radio wall-transmitter 2gang at quicklink
(5) Screw for dismantling protection
(6) Button design cover 1gang
(7) Button design cover 2gang
(8) Transmission status LED
