Product Overview

Package

Please make sure to install on an area which is strong enough to support more than 4 times of

the total weight of this product and the camera. Depending on some installation conditions,

this product can be connected to 0.75” PF which is a screw peak processed pipe.

Installation Precautions

SCREW-SPECIALSCREW-MACHINE

This product is an adaptor used to install our Vandal Dome Camera (QNV-6012R/6022R/6032R,

QNV-7010R/7020R/7030R, QNV-8010R/8020R/8030R, LNV-6010R/6020R/6030R, LNV-

6012R/6022R/6032R) in the electric gang box or on the wall or ceiling. (For compatible models,

please visit our website.)

Installation

1

Install the mount bracket on a desired position.

2

Remove the cap-bolt in the selected direction before inserting the pipe.

J

`However, take into consideration the pipe insertion direction.

There are two directions available for inserting the pipe.

ANCHOR

Mount Bracket

SBV-120GW

Pipe

CAP-BOLT

MOUNT-BRACKET




