USER GUIDE
MET-A07 ONBOARD PREAMP
☆ ☆MET-A07 Quick Start
☆ ☆MET-A07 Controls
☆ ☆Specification
1. Set the controls
Set off. Set the , , and volume bass middle treble presence
controls to center.
2. Plug in
Connect the MET-A07 to an amplifier or PA with a ¼-inch
instrument cable. The battery light will flash once quickly to
indicate it has switched on.
3. Tune up
Raise the and adjust the and volume bass, middle, treble
presence controls to your liking.
1. Volume volume - For the cleanest signal, set the knob as
high as possible, without causing distortion or feedback.
2. Bass - Boost here to add depth and weight to the sound
of the guitar.
3. Middle middle - Turn the knob all the way left for a smooth
“scooped out” tone at high volume levels. Raise the middle
knob to the right of center to add midrange “bite” to the
sound.
4. Treble - boost to cut through the mix. Cut to mellow and
subdue the sound.
5. Presence - control the frequency between 15K-20K.
6. Notch - anti-feedback control
7. Power - Play a single note by your instrument, the string
number and note name will shown on the display. The light
and indicator change as following:
8. Note: Chromatic mode / guitar mode / bass mode
9. Pitch: 433 – 447 Hz , step 1Hz
10. Battery - When low-battery indicator lamp lights, please
change the battery.
The system requires a 9-volt battery. Draw out the battery
case located next to the input jack and replace the battery
according to the +/- sign.
The guitar cable should be removed from the guitar when
it’s not in use, to keep the battery from draining.
http://www.mings.cn
pointer on the initial
position: tuner standby
pointer keeps in centre:
The note is accutage
pointer points left:
The note is low
pointer points right:
The note is hight
Nominal Input Level: -20dBV
Input Impedance: M Ohm22
Output Impedance: 3.5K Ohm (20Hz＜ ～20KHz)
Nominal Output Level: -12dBV
THD: Less than .05% (-20dBV input)
Noise Floor: -97dB
Dynamic Range: 102dB
Battery Life: (360mAH,9V) 60 hours (EQ Working, Tuner off)
Bass Control Frequency: 60Hz
Middle Control Frequency: 500Hz
Treble Control Frequency: 3KHz
Pres Control Frequency: 10KHz point control(±7dB,Q=1)
AUTO GUITAR
FLAT
AUTO GUITAR
FLAT
AUTO GUITAR
FLAT
AUTO GUITAR
FLAT
AUTO GUITAR
FLAT
