OD-5 Overdrive
EN
Features
Input Impedance: 1MΩ
Output Impedance: 1kΩ
Residual Noise: -85 dB, all knobs at centre position
Controls: GAIN, CLEAN, TONE, LEVEL
Connectors: 1/4" phone sockets for in and output,
power adapter (not included)
Power requirements: Alkaline 9V battery or external power
supply (DC 9 V ), both optionally available
Current Draw: 12 mA
Dimensions: 120 (W) × 56 (H) × 95 (D) mm
Weight: 350 g
Introduction
The Harley Benton ‘Overdrive’ pedal is ideally suited for electric
guitars, which need a boost in order to overdrive a subsequent
amp. The Clean control blends between boosted and clean
signal. Dialing towards clean signal restores the attack and feel
that is lost in a highly compressed overdrive circuit. The clean
boost and blending circuit use a studio grade op-amp for crisp
for super transparent sound without added noise. This unit
utilizes the same concept as layering two amps, one clean and
the other saturated. With the clean control turned down, you
get a classic overdrive tone. All the way up it provides 100%
clean boost.
You can power this device by an external DC9V power adap-
tor or a 9V alkaline battery. If you don‘t use this pedal for a
longer period of time take out the battery to avoid leakage.
Disconnect the input cable from the pedal when you don‘t use
the device. This disconnects the battery from the circuitry and
thus saves its capacity.
This device is intended to be used to boost a guitar signal in order to overdrive
a subsequent amp. Any other use or use under other operating conditions is
considered to be improper and may result in personal injury or property dam-
age. No liability will be assumed for damages resulting from improper use.
Ensure that plastic bags, packaging, etc. are properly disposed of and
are not in the reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the
like) from the product. They could swallow the pieces and choke! Never let chil-
dren use electrical devices unattended.
For the transport and protective packaging, environmentally friendly
materials have been chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of. Do
not just dispose of these materials with your normal household waste, but
make sure that they are collected for recycling. Please follow the notes and
markings on the packaging.
This product is subject to the European Waste Electrical and Electronic
Equipment Directive (WEEE) in its currently valid version. Do not dis-
pose of your old device with your normal household waste. Dispose of
this product through an approved waste disposal rm or through your
local waste facility. Comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Batteries must not be disposed of as domestic waste or thrown into re. Dis-
pose of batteries according to national or local regulations regarding hazard-
ous waste. To protect the environment, dispose of empty batteries at your retail
store or at appropriate collection sites.
