Sida 1/6
H
e
d
l
e
r
B
l
i
t
z
-
u
n
d
D
a
u
e
r
l
i
c
h
t
l
e
u
c
h
t
e
n
:
h
o
h
e
L
e
i
s
t
u
n
g
,
e
r
s
t
k
l
a
s
s
i
g
e
Q
u
a
l
i
t
ä
t
!
Handmade in Germany
HEDLER Pro lux
®
LED
650
operation manual.
Thank you for choosing the Hedler light unit HEDLER Pro lux
®
LED
650
and your con dence in the
Hedler light system. Please, read the following technical informations and the Hedler safety
instructions carefully before using the light unit.
Codes are given in < brackets >.
TECHNICAL DESCRIPTION
Light units of the HEDLER LED range are designed for professional use, they are assembled by applying precision methods and tested individually
for function and quality. The daylight HEDLER Pro lux
®
LED
650
light unit is provided with an integrated U-bracket and a friction brake and a 5/8”
Quick-Lock light stand attachment. After loosening the hex key screws by approx. 2 turns, the U-bracket can be moved back and forth in its
keyway for gravity adjustment and it is turnable for right and left hand use.
The light unit HEDLER Pro lux
®
LED
650
is designed for AC use from 110 - 230 V (with automatic mains voltage recognition) and 50 / 60 Hz and
are equipped with a LED Softstart feature. They use one 75 W highpower single cell LED and generate a icker-free light @ approx. 5600 K and
a CRI > 96. They have an extremely quiet cooling and they are equipped with a special active LED fan cooling and an integrated safety switch-off.
At the front side the aluminium housings safety glass and the QuickFit adapter (compatible with the Hedler Uni-Adapt system) for re ectors.
The HEDLER Pro lux
®
LED
650
can be equipped with all the latest Hedler re ectors and softboxes optionally. Because of the QuickFit adapter
attaching a re ector or softbox is extremely comfortable: Interchangeable re ectors with bayonet ring can be attached in the following way:
place the rim of the ring into the guide grooves of the upper studs and the round opening over the cone-shaped bolt, and lock it by a turn to the
left. To attach the rotatable 4-Leaf barndoors or a MaxiSoft folding re ector, place the rim of the ring into the guide grooves of the upper studs,
and then push the complete re ector towards the QuickFit´s cone-shaped bolt until the ring locks in the bolt´s groove. Detach the re ector by
lifting the QuickFit´s handle, moving the lower side of the re ector away from the light unit´s housing, and then lifting the re ector´s ring out
of the guide grooves of the upper studs.
HEDLER Systemlicht GmbH Heerstrasse 112 D-65594 Runkel / Lahn www.hedler.com
Telefon + 49 - (0) 6482 918 100 Telefax + 49 - (0) 6482 918 111 eMail info@hedler.com
Profilux
®
LED
650
HEDLER
®
Systemlicht
OPERATION MANUAL
HEDLER Pro lux
®
LED
650
operation manual.
