This booklet is your guide to the basic operation and maintenance of your new
Hero MotoCorp SPLENDOR+. Please take time to read it carefully. As with any fine
machine, proper care and maintenance are essential for trouble-free operation and optimum
performance.
We at Hero MotoCorp, are committed to demonstrate excellence in our environment
performance on a continual basis, as an intrinsic element of our corporate philosophy. To
achieve this we commit ourselves to continue product innovations to improve environment
compatibility, comply with and all applicable legislation including environment legislation
strengthen the green supply chain.
Thank you for selecting a Hero MotoCorp SPLENDOR+. We wish you many miles of
continued riding pleasure in the years ahead.
Your vehicle is conforming to latest (Bharat stage-IV norms) regulation for emission, safety &
noise levels. We are also using non asbestos brake shoes/pads and engine gaskets which are
environment friendly in nature.
Let us make this world a safer, healthier and more environment friendly place.
Your Authorised Hero MotoCorp dealer will be glad to provide further information or
assistance and is equipped to handle your future service needs.
This vehicle is fitted with a lighting feature known as “Automatic Headlamp ON”. The feature
is mandated for all 2 Wheelers by Ministry of Road Transport & Highways (Government of
India) vide notification GSR 188 (E) dated 22nd February 2016. This feature helps in
conspicuity for improving rider safety. The headlamp of this vehicle will always be lit ON when
the engine gets ON.
PREFACE
ALL INFORMATION, ILLUSTRATION, PHOTOGRAPH, DIRECTIONS,
SPECIFICATIONS AND OTHER CONTENTS COVERED IN THIS OWNER'S
MANUAL ARE BASED ON THE LATEST PRODUCT INFORMATION AVAILABLE
AT THE TIME OF ITS PRINTING APPROVAL, AND THE ACCURACY OR
CORRECTNESS OF THE SAME IS NOT UNDERTAKEN OR GUARANTEED.
Hero MotoCorp Ltd RESERVES THE RIGHT TO MAKE CHANGES IN ITS
CONTENTS AT ANY TIME WITHOUT NOTICE AND/OR INCURRING ANY
OBLIGATION, WHATSOEVER. NO ONE IS ALLOWED TO REPRODUCE ANY
PART OF THIS PUBLICATION WITHOUT OBTAINING PRIOR WRITTEN
PERMISSION FROM Hero MotoCorp Ltd.
NOTE
ACCESSORIES SHOWN MAY NOT BE THE PART OF STANDARD FITMENT. IT IS
OUR ENDEAVOUR TO CONSTANTLY IMPROVE OUR PRODUCTS. THIS COULD
LEAD TO CHANGE IN PRODUCT SPECIFICATIONS WITHOUT NOTICE. Hero
MotoCorp Ltd ‘SPLENDOR+’ COMPLIES WITH THE LATEST EMISSION NORMS.
Pg. No. Pg. No.
CONTENTS
Ÿ FEATURES 14
Ÿ Steering lock 14
PARKING 22
Ÿ Instruments & Indicators 13
ANTI-THEFT TIPS 7
Ÿ Protective apparel 9
CLEANING AND WASHING OF VEHICLE 23
RIDING 21
TIPS FOR HEALTHY ENVIRONMENT 11
PARTS FUNCTION 12
TOOL KIT/FIRST AID KIT 22
Ÿ Importance of maintenance 23
Ÿ Maintenance safety 24
VEHICLE SAFETY 8
Ÿ Fuel tank 16
PRE-RIDE INSPECTION 19
VEHICLE VIEWS 2
Ÿ Important safety information 8
Ÿ Ignition switch 12
BRAKING 21
UTILITY BOX 22
VEHICLE IDENTIFICATION 1
VEHICLE SPECIFICATION 5
ACCESSORIES & MODIFICATIONS 7
SAFE RIDING TIPS 10
Ÿ HANDLEBAR SWITCHES CONTROL 14
Ÿ i3s (Idle stop start system) 15
Ÿ Fuel valve 17
MAINTENANCE 23
STARTING THE ENGINE 20
Ÿ Spark plug inspection 28
Ÿ Engine oil level inspection/Top up process 29
Ÿ Oil filter screen & Centrifugal filter cleaning 30
Ÿ Carburetor (idle speed adjustment) 33
Ÿ Safety precaution 24
Ÿ Maintenance schedule 25
Ÿ Engine oil 28
Ÿ Engine oil replacement/Oil circulation inspection 29
Ÿ Air cleaner 31
Ÿ Throttle controlled ignition system (TCIS) 33
Ÿ Clutch lever free play adjustment 35
Ÿ Drive chain slider inspection 39
Ÿ Brakes 39
Ÿ Suspension 41
Ÿ Wheel 42
Ÿ Main/Side stand lubrication 43
Ÿ Tyre 44
Ÿ Valve clearance adjustment 34
Ÿ Throttle operation & free play adjustment 36
Ÿ Nuts, bolts & fastners 46
Ÿ Battery 46
Ÿ Stop lamp switch 50
Ÿ Evaporative emission control 51
POLISHING OF VEHICLE 51
BASIC TROUBLESHOOTING 52
Ÿ Catalytic converter 51
Ÿ Headlamp focus adjustment 50
ROAD SIGNS 54
Ÿ Drive chain slackness adjustment 36
Ÿ Fuse replacement 49
ZONAL/REGIONAL/AREA OFFICES
WARRANTY DETAILS
HERO GENUINE PARTS
