Sida 1/25

hertzaudiovideo.com

OWNER’S MANUAL

Comp

English / English

Congratulations on purchasing our product. Your satisfaction is the first requirement

that our products must meet: the same satisfaction as the one gained by those who

long for experiencing the car audio emotion. This manual has been drawn to provide

the main instructions required to install and use the system properly. However,

the range of possible applications is wide; for further information, please feel free

to contact your trusted dealer or our technical support at the email support@

elettromedia.it Before installing the components, please carefully read all of the

instructions contained in this manual. Failure to respect these instructions may

cause unintentional harm or damage to the product.

1. All components must be firmly secured to the vehicle structure. Do the same

when installing any custom structures you may have built. Confirm your installation

is solid and safe. A component coming loose while driving may cause serious

damage to the passengers, as well as to other vehicles.

2. Always wear protective eyewear when using tools, as splints or product residue

may become airborne.

3. In order to avoid incidental damage, keep the product in the original packaging

until you are ready for the final installation.

4. Do not carry out any installation inside the engine compartment.

5. Before starting with the installation turn the head unit and all other audio

system devices off, avoiding any possible damage.

6. Make sure that the location you choose to install the components does not

interfere with the normal operation of any mechanical or electrical devices of

the vehicle.

7. Do not install loudspeakers where they may be exposed to water, excessive

humidity, dust or dirt.

8. Do not install the tweeter without the protective grille.

9. Do not install the components or make cable run close to electronic or mechanical

devices of the vehicle.

10. Be very cautious when drilling or cutting into the vehicle chassis, making sure

there are no cables or structural elements essential to the vehicle underneath

or in the selected area.

11. When routing cables, make sure that the cable does not come in contact with

sharp edges or near moving mechanical devices. Make sure that it is firmly

attached and protected along its entire length and its insulation is self-extinguishing.

12. Only use cables with the proper section (AWG) indicated herein.

13. When running the cable through a hole in the vehicles chassis, protect the

cable with a rubber ring (grommet). Be sure to provide proper protection for

cables running close to heat-generating devices.

14. Do not run the wires outside of the vehicle.

15. Use top quality cables, connectors and accessories such as found in the

Connection catalogue.

16. Warranty certificate: For more information visit the Hertz website.

SAFE SOUND

USE COMMON SENSE AND PRACTICE SAFE SOUND. PLEASE REMEMBER THAT

LONG EXPOSURE TO EXCESSIVELY HIGH SOUND PRESSURE LEVELS MAY DAMAGE

YOUR HEARING. SAFETY MUST BE AT THE FOREFRONT WHILE DRIVING.

Information on electrical and electronic equipment waste (for those European countries which

organize the separate collection of waste)

Products which are marked with a wheeled bin with an X t hrough it can not be disposed

of together with ordinary domestic waste. These elec trical and electronic products must

be recycled in proper facilities, capable of managing the disposal of these pro ducts and

components. In order to kn ow where and how to deliver these products to the nearest

recycling/disposal site please co ntact your local municipal o ffice. Recycling and disposing

of waste in a pro per way contributes to the protec tion of the environment and to pr event

harmful effects on health.

Продукция  обладает гарантией в течение уставленного текущимиHertz

законамисрока,принормальныхусловияхиспользования,еслионавызвана

дефектами материалов или их производства. Гарантия действительна с

датыпокупки,подтвержденнойчеком.Гарантиянедействительнавследующих

случаях:

• продуктповрежденврезультатеинцидентов,некасающимсяматериаловили

  производственныхдефектов;

• продуктизмененилифальсифицированнеуполномоченнымилицами;

• егосерийныйномеризмененилистерт.

Если на продукт распространяется гарантия, его производитель принимает

решение о ремонте или замене его неисправных деталей. Неисправный

продукт необходимо передать распространителю, где он был куплен,

предъявивполностьюзаполненныйгарантийныйсертификат.Вслучаеесли

гарантиябольшенераспространяетсянапродукт,онбудетотремонтирован

потекущейстоимости.Мынепринимаемнасебяобязательства,связанныес

повреждениямивследствиетранспортировки.Мыненесемответственности

за: расходы или потеря прибылей вследствие невозможности пользования

даннымпродуктом,прочиеслучайныеиливозможныеиздержки,расходыили

повреждения, покрытые клиентом. Гарантия в соответствиис действующим

законодательством.

Гарантия He rtz

Hertz

HertzHertz

The Hertz products are warranted, under normal functioning

conditions, for the period of time as set by the laws in force, against

defects concerning materials or their manufacturing. The warranty is

valid from the date of purchase, certified by receipt.

The warranty is not valid if:

• the product is damaged by incidents, installations and/or improper

use,

or by any other causes not depending on materials or manufacturing

defects;

• the product is modified or tampered with by unauthorised people;

• its serial number has been altered or cancelled.

While the product is under warranty, defective parts will be repaired or

replaced at the manufacturer’s discretion.

The defective product, along with notification about it, must be

returned to the dealer from which it was purchased together with

the warranty certificate duly filled in. If the product is no longer under

warranty, it will be repaired at the current costs.

Elettromedia s.r.l. does not undertake any liability for damages due to

transportation.

Elettromedia s.r.l. does not take any responsibility for: costs or loss of

profit due to the impossibility to use the product, other accidental or

consequential costs, expenses or damages suffered by the customer.

Warranty according to laws in force.

For more information visit the Hertz website.

Hertz Warranty
