6 Series Video Intercom Villa Door Staon
User Manual
Legal Informaon
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes for using and managing the Product. Pictures, charts, images andinstrucons
all other informaon hereinaer are for and only. The descripon explanaon informaon
contained in the Manual is subject to change, without due to noce, rmware updates or other
reasons. Please the latest version of this Manual at the Hikvision website ( nd hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos are the menoned properes respecve of their owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS,
AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
6 Series Video Intercom Villa Door User ManualStaon
i
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
6 Series Video Intercom Villa Door User ManualStaon
ii
Symbol Convenons
The symbols that may be found in this document are as follows.dened
Symbol Descripon
Danger
Indicates a hazardous which, if not avoided, will or couldsituaon
result in death or serious injury.
Cauon
Indicates a hazardous which, if not avoided, couldpotenally situaon
result in equipment damage, data loss, performance ordegradaon,
unexpected results.
Note Provides to emphasize or supplementaddional informaon
important points of the main text.
6 Series Video Intercom Villa Door User ManualStaon
iii
Safety Instrucon
Warning
●All the electronic operaon should be strictly compliance with the electrical safety regulaons,
re prevenon regulaons and other related in your local region.regulaons
●Please use the power adapter, which is provided by normal company. The power consumpon
cannot be less than the required value.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or hazard.re
●Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●When the product is installed on wall or ceiling, the device shall be rmly xed.
●If smoke, odors or noise rise from the device, turn o the power at once and unplug the power
cable, and then please contact the service center.
●If the product does not work properly, please contact your dealer or the nearest service center.
Never to disassemble the device yourself. (We shall not assume any responsibility foraempt
problems caused by unauthorized repair or maintenance.)
Cauon
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. installaon vibraons Avoid the equipment on surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specicaon of the device for the detailed
operang temperature), cold, dusty or damp and do not expose it to highlocaons,
electromagnec radiaon.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a however), and malfuncon aecng the endurance of sensor at the
same me.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface of the devicecoang
cover.
●Please use a and dry cloth when clean inside and outside surfaces of the device cover, doso
not use alkaline detergents.
●Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportaon without the
original wrapper may result in damage on the device and lead to addional costs.
6 Series Video Intercom Villa Door User ManualStaon
iv
●Improper use or replacement of the may result in hazard of explosion. Replace with thebaery
same or equivalent type only. Dispose of used according to the provided bybaeries instrucons
the manufacturer.baery
●Input voltage should meet both the SELV and the Limited Power Source according to 60950-1
standard.
●The power supply must conform to LPS. The recommended adaptor models and manufacturers
are shown as below. Use the adapter, and do not change the adaptor randomly.aached
Model Manufacturer Standard
ADS-24S-12 1224GPCN SHENZHEN HONOR ELECTRONIC
CO.,LTD
CEE
G0549-240-050 SHENZHEN GOSPELL DIGITAL
TECHNOLOGY CO.,LTD
CEE
TS-A018-120015Ec SHENZHEN TRANSIN TECHNOLOGIES
CO., LTD
CEE
6 Series Video Intercom Villa Door User ManualStaon
v
Regulatory Informaon
FCC Informaon
Please take that changes or not expressly approved by the party responsibleaenon modicaon
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a If this equipment doesparcular installaon.
cause harmful interference to radio or television recepon, which can be determined by turning
the equipment and on, the user is encouraged to try to correct the interference by one or moreo
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC Condions
This device complies with part 15 of the FCC Rules. is subject to the following twoOperaon
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
6 Series Video Intercom Villa Door User ManualStaon
vi
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC 2014/30/EU, the RoHS Direcve Direcve 2011/65/EU
2012/19/EU (WEEE Products marked with this symbol cannot be disposeddirecve):
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a that cannot bebaery
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for The is marked with thisspecic baery informaon. baery
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitaon condions est autorisée aux deux suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2. l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble compromere fonconnement. d'en le
Under Industry Canada this radio regulaons, transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
Conformément à la réglementaon d'Industrie Canada, le présent radio peut émeeur fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour parl'émeeur
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à desl'intenon
autres ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
6 Series Video Intercom Villa Door User ManualStaon
vii
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et à une distance minimale de 20 cm entre le radiateur etulisé
votre corps.
6 Series Video Intercom Villa Door Staon User Manual
viii
Contents
Chapter 1 Appearance ................................................................................................................ 1
Chapter 2 Terminal and Wiring ................................................................................. 3Descripon
2.1 Terminal .............................................................................................................. 3Descripon
2.2 Wiring ................................................................................................................. 4Descripon
2.2.1 Door Lock Wiring .......................................................................................................... 4
2.2.2 Door Contact Wiring ..................................................................................................... 5
2.2.3 Exit Wiring ......................................................................................................... 6Buon
2.2.4 Alarm Input Device Wiring ............................................................................................ 7
Chapter 3 Installaon ................................................................................................................. 8
3.1 Accessory .......................................................................................................... 8Introducon
3.2 Surface without Mounng Protecve Shield ......................................................................... 9
3.3 Surface Mounng Protecve with Shield ............................................................................. 12
Chapter 4 Acvaon ................................................................................................................. 16
4.1 Acvate Device via Web ....................................................................................................... 16
4.2 Acvate Soware Device via Client ...................................................................................... 16
4.3 Edit Network Parameters ..................................................................................................... 17
Chapter 5 Remote Conguraon via Web ................................................................................. 18
5.1 Live View .............................................................................................................................. 18
5.2 User Management ............................................................................................................... 18
5.3 Device Management ............................................................................................................ 19
5.4 Parameters Sengs ............................................................................................................. 20
5.4.1 Local Parameters ........................................................................................... 20Sengs
5.4.2 System ........................................................................................................... 22Sengs
5.4.3 Network Sengs ......................................................................................................... 24
5.4.4 Video & Audio ............................................................................................... 29Sengs
5.4.5 Image ............................................................................................................. 32Sengs
6 Series Video Intercom Villa Door Staon User Manual
ix
5.4.6 Event .............................................................................................................. 35Sengs
5.4.7 Schedule ........................................................................................................ 39Sengs
5.4.8 Intercom Sengs ........................................................................................................ 40
5.4.9 Access Control ............................................................................................... 43Sengs
Chapter 6 Conguraon via Client Soware ............................................................................. 47
6.1 Device Management ............................................................................................................ 47
6.1.1 Add Online Device ....................................................................................................... 47
6.1.2 Add Device by IP Address ............................................................................................ 49
6.1.3 Add Device by IP Segment .......................................................................................... 49
6.2 Live View via Door Staon ................................................................................................... 49
6.3 Organizaon Management .................................................................................................. 49
6.3.1 Add Organizaon ........................................................................................................ 49
6.3.2 Modify and Delete Organizaon ................................................................................. 50
6.4 Person Management ............................................................................................................ 50
6.4.1 Add Person .................................................................................................................. 50
6.4.2 Modify and Delete Person .......................................................................................... 51
6.4.3 Change Person to Other Organizaon ........................................................................ 51
6.4.4 Import and Export Person Informaon ....................................................................... 52
6.4.5 Get Person Informaon from Device .......................................................................... 52
6.4.6 Issue Card in Batch ...................................................................................................... 53
6.4.7 Permission Sengs ..................................................................................................... 56
6.5 Video Intercom ....................................................................................................... 56Sengs
6.5.1 Receive Call from Door Staon ................................................................................... 57
6.5.2 Release ............................................................................................................ 57Noce
6.5.3 Search Video Intercom Informaon ............................................................................ 58
6.5.4 Upload Armed Informaon ......................................................................................... 59
Appendix A. Matrix and Device Command ...................................................... 60Communicaon
6 Series Video Intercom Villa Door User ManualStaon
x
Chapter 1 Appearance
Front Panel and Rear Panel
Here takes DS-KV6113-WPE1 for example.
Figure 1-1 Front Panel and Rear Panel
Table 1-1 Descripon
No. Descripon
1 Microphone
2 Camera
3 Indicator
Unlock (Green)/ Call (Orange)/ Communicate
(White)
6 Series Video Intercom Villa Door User ManualStaon
1
No. Descripon
4 Buon
5 Card Reading Area
6 Loudspeaker
7 Terminals
8 Debugging Port
9 TAMPER
10 Set Screw
Boom Panel
Figure 1-2 PanelBoom
Table 1-2 Descripon
No. Descripon
11 TF Card Slot (Reserved)
12 Network Interface
6 Series Video Intercom Villa Door User ManualStaon
2
Chapter 2 Terminal and Wiring Descripon
2.1 Terminal Descripon
Figure 2-1 Terminal Descripon
Note
RS-485 terminal is not supported.
6 Series Video Intercom Villa Door User ManualStaon
3
2.2 Wiring Descripon
2.2.1 Door Lock Wiring
Figure 2-2 Door Lock Wiring
Note
Terminal NC/COM is set as default for accessing lock/electric bolt; terminal NO/COM ismagnec
set as default for accessing electric strike.
6 Series Video Intercom Villa Door User ManualStaon
4
2.2.2 Door Contact Wiring
Figure 2-3 Door Contact Wiring
6 Series Video Intercom Villa Door User ManualStaon
5
2.2.3 Exit WiringBuon
Figure 2-4 Exit WiringBoon
6 Series Video Intercom Villa Door User ManualStaon
6
2.2.4 Alarm Input Device Wiring
Figure 2-5 Alarm Input Device Wiring
6 Series Video Intercom Villa Door User ManualStaon
7
Chapter 3 Installaon
Note
●Make sure the device in the package is in good and all the assembly parts are included.condion
●Make sure your power supply matches your door staon.
●Make sure all the related equipment is power-o installaon. during the
●Check the product specicaon for the environment.installaon
3.1 Accessory Introducon
Figure 3-1 Accessory Introducon
6 Series Video Intercom Villa Door User ManualStaon
8
Note
The dimension of the plate is 102.58 mm × 39.24 mm × 6.2 mm.mounng
3.2 Surface without Mounng Protecve Shield
Before You Start
●Tools that you need to prepare for installaon: Drill (ø2.846) and gradienter.
●Purchase the protecve shield before installaon.
Steps
1. Sck mounng the template on the wall. Drill screw holes according to the template.mounng
Remove the template from the wall.
6 Series Video Intercom Villa Door User ManualStaon
9
Figure 3-2 TemplateMounng
2. Secure the plate on the wall with 4 supplied screws according to the screw holes.mounng
3. Install the villa door staon mounng to the plate. Fix the device on the plate with themounng
set screw.
Note
Apply silicone sealant among the cable wiring area to keep the raindrop from entering.
6 Series Video Intercom Villa Door User ManualStaon
10
Figure 3-3 Apply Silicone Sealant
6 Series Video Intercom Villa Door User ManualStaon
11
Figure 3-4 Surface without Mounng Protecve Shield
3.3 Surface Mounng Protecve with Shield
Before You Start
●Tools that you need to prepare for installaon: Drill (ø2.846) and gradienter.
●Purchase the protecve shield before installaon.
●If installing outdoors, you are advised to install the device with protecve shield.
Steps
1. Sck mounng the template on the wall. Drill screw holes according to the template.mounng
Remove the template from the wall.
6 Series Video Intercom Villa Door User ManualStaon
12
Figure 3-5 TemplateMounng
2. Align the protecve mounng shield with the template.
3. Secure the mounng protecve plate and shield on the wall with 4 supplied screws according to
the screw holes.
4. Install the villa door staon mounng to the plate. Fix the device on the plate with themounng
set screw.
6 Series Video Intercom Villa Door User ManualStaon
13
Figure 3-6 Surface with Mounng Protecve Shield
6 Series Video Intercom Villa Door User ManualStaon
14
Figure 3-7 Finished View
6 Series Video Intercom Villa Door User ManualStaon
15
Chapter 4 Acvaon
4.1 Acvate Device via Web
You are required to acvate rst seng the device by a strong password for it before you can use
the device.
Default parameters of the door are as follows:staon
●Default IP Address: 192.0.0.65.
●Default Port No.: 8000.
●Default User Name: admin
Steps
1. Power on the device, and connect the device to the network.
2. Enter the IP address into the address bar of the web browser, and click to enter theEnter
acvaon page.
Note
The computer and the device should belong to the same subnet.
3. Create and enter a password into the password eld.
4. Conrm the password.
5. Click to OK acvate the device.
4.2 Acvate Device via Client Soware
You can only congure and operate the door staon aer creang a password for the device
acvaon.
Default parameters of door are as follows:staon
●Default IP Address: 192.0.0.65.
●Default Port No.: 8000.
●Default User Name: admin.
Steps
1. Run the client soware, click Maintenance and Management → Device Management → Device
to enter the page.
2. Click .Online Device
3. Select an inacvated device and click Acvate.
4. Create a password, and conrm the password.
6 Series Video Intercom Villa Door User ManualStaon
16
Note
We highly recommend you to create a strong password of your own choosing (using a minimum
of 8 characters, including at least three kinds of following categories: upper case lowerleers,
case leers, numbers, and special characters) in order to increase the security of your product.
And we recommend you change your password regularly, especially in the high security system,
changing the password monthly or weekly can protect your product.beer
5. Click to OK acvate the device.
Note
●When the device is not acvated, operaon the basic and remote of device cannotoperaon
be performed.
●You can hold the or key to select devices in the online devices, and click theCtrl Shi mulple
Acvate to buon acvate devices in batch.
4.3 Edit Network Parameters
To operate and congure the device via LAN (Local Area Network), you need connect the device in
the same subnet with your PC. You can edit network parameters via client iVMS-4200 soware.
Steps
1. Select an online acvated device and click the .Modify Nenfo
2. Edit the device IP address and gateway address to the same subnet with your computer.
3. Enter the password and click to save the network parameters OK modicaon.
Note
●The default port No. is 8000.
●The default IP address of the door staon is 192.0.0.65.
●Aer eding the network parameters of device, you should add the devices to the device list
again.
6 Series Video Intercom Villa Door Staon User Manual
17
Chapter 5 Remote Conguraon via Web
5.1 Live View
In the browser address bar, enter the IP address of the device, and press the Enter key to enter the
login page.
Enter the user name and password and click to enter the Live View page. Or you can clickLogin
Live View to enter the page.
Figure 5-1 Live View
●You can start/stop live view, capture, record, audio on/o, two-way audio, etc.
●The stream type can be set as main stream or sub stream.
●For IE (Internet Explorer) users, the device support two-way audio communicaon.
5.2 User Management
You can add, delete or search the informaon of the user.
Click to enter the page.User sengs
6 Series Video Intercom Villa Door User ManualStaon
18
Figure 5-2 User Management
●Click and enter the , Add Name Floor No. and to add.Room No.
●Click to modify the Edit informaon of the user.
●Check the box of the user and click Delete to delete the selected user.
●Enter the keyword and click search icon. The informaon will display in the list.
Note
User management may vary with funcon dierent models. Please refer to the actual product.
5.3 Device Management
You can manage the linked device on the page.
Click Device Management to enter the page.sengs
Figure 5-3 Device Management
6 Series Video Intercom Villa Door Staon User Manual
19
Add Device
●Click to add the indoor Add staon staon. or sub door Enter the parameters and click toOK
add.
●Click . Enter the Import informaon of the device in the template to import devices in batch.
Export
Click to export the to the PC.Export informaon
Delete
Select the device and click Delete to remove the selected device from the list.
Refresh
Click Refresh to get the device informaon.
Oponal: Set Device Informaon.
●Click to edit device informaon.
●Click to delete device informaon from the list.
●Select Status and Device Type to search devices.
5.4 Parameters Sengs
Click Conguraon to set the parameters of the device.
Remote conguraon in iVMS-4200 and Batch Tool is the same as that in Web. HereConguraon
takes the conguraon in web for example.
Note
Run the browser, click → Internet → SecurityOpons to disable the Protected Mode.
5.4.1 Local Parameters Sengs
You can congure the parameters of the live view, record and captured pictures. The recordles
les and captured pictures are the ones you record and capture by using the web browser. You can
also set and view the saving paths of the captured pictures and recorded videos on the PC that
running the web browser.
6 Series Video Intercom Villa Door User ManualStaon
20
Figure 5-4 Local Parameters
Live View Parameters
Stream Type
Set the stream type as or Main Stream Sub-stream.
Play Performance
Set the live view performance to Shortest Delay Balanced, or .Fluent
Auto Start Live View
Check Yes to enable the funcon.
Image Format
Select the image format for picture capture.
Click Save to enable the sengs.
Record File Parameters
Record File Size
Select the packed size of the manually recorded and downloaded video to , orles 256M 512M
1G. the the maximum record size is the value you selected.Aer selecon, le
Save record toles
Set the saving path for the manually recorded video les.
6 Series Video Intercom Villa Door Staon User Manual
21
Click Save to enable the sengs.
Picture and Clip Sengs
Save snapshots in live view to
Set the saving path of the manually captured pictures in live view mode.
Note
You can click Browse to change the directory for saving the clips and pictures, and click toOpen
open the set folder of clips and picture saving.
Click Save to enable the sengs.
5.4.2 System Sengs
Follow the instrucons congure below to the system include System sengs, Sengs,
Maintenance, Security, and User Management, etc.
Click System to enter the page.sengs
Basic Informaon
Click System → Basic Sengs Informaon to enter the page. On the page, you can editsengs
Device Name Device No. Language System Type and Set the and according to your needs.
Click Save to enable the sengs.
Time Sengs
Click System → Time Time ZoneSengs Sengs to enter the page. Select the sengs of your
locaon from the drop-down list.
●Enable , set the , NTP Server Address NTP Port Interval and .
●Enable , set the Manual Time Sync. me manually or check the Sync. with computer me.
Click Save to enable the sengs.
DST
Click System → DST Enable DSTSengs to check . Set the parameters according to your needs and
click Save to enable the sengs.
About
Click System → About Open Source Sengs and click Soware Licenses to view the details.
Maintenance
Click Maintenance → Upgrade & Maintenance to enter the page.sengs
6 Series Video Intercom Villa Door User ManualStaon
22
Figure 5-5 Maintenance
●Reboot: Click Reboot to reboot the device.
●Restore
Click Restore to reset all the parameters, except the IP parameters and user informaon, to
the default sengs.
Default
Click Default to restore all parameters to default sengs.
●Export parameters:
1. Select Device Parameters Export, and click to pop up the dialog box.
2. Set and conrm encrypon the password.
3. Click to export parameters.OK
●Import Cong. File:
1. Click browse icon to select the conguraon le.
2. Click and enter the password to import.Import encrypon
●Upgrade: Click browse icon to select the upgrade le.
Note
The upgrading process will last 1 to 10 minutes, do not power during the upgrading. Theo
device reboots automacally aer upgrading.
Security Service
Click to enter the page. On the page, you can enable SSHSecurity → Security Service sengs
according to your actual needs.
Click Save to enable the sengs.
User Management
Click to enter the page.User Management sengs
6 Series Video Intercom Villa Door Staon User Manual
23
Administrator can edit the permission for the users.
Note
We highly recommend you to create a strong password of your own choosing (using a minimum of
8 characters, including at least three kinds of following categories: upper case lower caseleers,
leers, numbers, and special characters) in order to increase the security of your product. And we
recommend you change your password regularly, especially in the high security system, changing
the password monthly or weekly can protect your product.beer
Online Users
Click User Management → Online Users to enter the page.
Figure 5-6 Online Users
Click Refresh to get the present informaon.
Arming/Disarming Informaon
Click to view the User Management → Arming/Disarming Informaon informaon. Click Refresh
to get the present informaon.
5.4.3 Network Sengs
TCP/IP Sengs
TCP/IP must be properly sengs congured before you operate the device over network. The
device supports IPv4.
Steps
1. Click Network → Basic Sengs → TCP/IP to enter the page.sengs
6 Series Video Intercom Villa Door User ManualStaon
24
Figure 5-7 TCP/IP Sengs
2. Congure the network parameters.
-Check , the device will get the parameters DHCP automacally.
-Set the , IPv4 Address IPv4 Subnet Mask IPv4 Default Gateway and manually.
3. Congure the corresponding DNS server parameters.
4. Click Save to enable the sengs.
Port Sengs
Steps
1. Click Network → Basic Sengs → Port to enter the page.sengs
6 Series Video Intercom Villa Door Staon User Manual
25
Figure 5-8 Port Sengs
2. Set the ports of the device.
HTTP Port
The default port number is 80, and it can be changed to any port No. which is not occupied.
HTTPS Port
The default port number is 443, and it can be changed to any port No. which is not occupied.
RTSP Port
The default port number is 554.
Server Port
The default server port number is 8000, and it can be changed to any port No. ranges from
2000 to 65535.
3. Click Save to enable the sengs.
SIP Seng
Steps
1. Click Network → Basic Sengs to enter the page.→ SIP sengs
6 Series Video Intercom Villa Door User ManualStaon
26
Figure 5-9 SIP Sengs
2. Check Enable VOIP Gateway.
3. Congure the SIP parameters.
4. Click Save to enable the sengs.
FTP Sengs
Steps
1. Click Network → Advanced → FTP to enter the sengs page.
6 Series Video Intercom Villa Door User ManualStaon
27
Figure 5-10 FTP Sengs
6 Series Video Intercom Villa Door User ManualStaon
28
2. Check .Enable FTP
3. Select Server Type.
4. Input the and Server IP Address Port.
5. Congure Sengs, the FTP and the user name and password are required for the server login.
6. Set the Directory Structure Parent Directory Child Directory, and .
7. Set the picture naming rules.
8. Click Save to enable the sengs.
Plaorm Access
Plaorm access provides you an to manage the devices via opon plaorm.
Steps
1. Click Network → Advanced Sengs Plaorm → Access to enter the page.sengs
2. Check the checkbox of to enable the Enable funcon.
3. Select the .Plaorm Access Mode
Note
Hik-Connect is an for mobile devices. With the App, you can view live image of theapplicaon
device, receive alarm and so on.nocaon
4. Create a for the device.Stream Encrypon/Encrypon
Note
6 to 12 leers (a to z, A to Z) or numbers (0 to 9), case sensive. You are recommended to use a
combinaon leers of no less than 8 or numbers.
5. Click Save to enable the sengs.
5.4.4 Video & Audio Sengs
Video Parameters
Steps
1. Click Video/Audio → Video to enter the page.sengs
6 Series Video Intercom Villa Door User ManualStaon
29
Figure 5-11 Video Parameters
2. Select the Stream Type.
3. Congure the video parameters.
Stream Type
Select the stream type to main stream or sub stream.
Video Type
Select the stream type to video stream, or video & audio composite stream. The audio signal
will be recorded only when the Video Type Video & Audio is .
Resoluon
Select the of the video output.resoluon
Bitrate Type
Select the bitrate type to constant or variable.
Video Quality
When bitrate type is selected as Variable, 6 levels of video quality are selectable.
Frame Rate
6 Series Video Intercom Villa Door User ManualStaon
30
Set the frame rate. The frame rate is to describe the frequency at which the video stream is
updated and it is measured by frames per second (fps). A higher frame rate is advantageous
when there is movement in the video stream, as it maintains image quality throughout.
Max. Bitrate
Set the max. bitrate from 32 to 16384 Kbps. The higher value corresponds to the higher video
quality, but the bandwidth is required.beer
Video Encoding
The device supports H.264.
I Frame Interval
Set I Frame Interval from 1 to 400.
4. Click Save to save the sengs.
Audio Parameters
Steps
1. Click Video/Audio → Audio to enter the sengs page.
Figure 5-12 Audio Sengs
2. Congure the stream type and the audio encoding type.
Stream Type
Select the stream type to main stream or sub stream.
Audio Encoding
The device support G.711ulaw and G.711 alaw.
3. Adjust the Input Volume Output Volume Speak Volume, and .
6 Series Video Intercom Villa Door User ManualStaon
31
Note
Available range of volume: 0 to 10.
4. Click Save to save the sengs.
5.4.5 Image Sengs
Display Sengs
Congure the image adjustment, backlight and other parameters in display sengs sengs.
Steps
1. Click Image → Display Sengs to enter the display page.sengs
Figure 5-13 Display Sengs
2. Select the Format.
3. Set the display parameters.
WDR
Wide Dynamic Range can be used when there is a high contrast of the bright area and the
dark area of the scene.
Brightness
Brightness describes bright of the image, which ranges from 1 to 100.
Contrast
Contrast describes the contrast of the image, which ranges from 1 to 100.
6 Series Video Intercom Villa Door Staon User Manual
32
Saturaon
Saturaon describes the colorfulness of the image color, which ranges from 1 to 100.
Sharpness
Sharpness describes the edge contrast of the image, which ranges from 1 to 100.
4. Set the Day/Night Mode.
Figure 5-14 Day/Night Mode
-Set Day Mode Night Mode or manually.
-Set the mode as and edit the according to your needs.Auto sensivity
-Set the mode as Scheduled-Switch. Set the start me me. and end
Note
Dayme is from congured start to me congured me. me The rest of the is set as night by
default.
5. Set the backlight parameters.
6 Series Video Intercom Villa Door User ManualStaon
33
Figure 5-15 Backlight
1) Check the checkbox to enable BLC.
2) Select BLC Area.
6. Click Save to enable the sengs.
OSD Sengs
You can customize the camera name, format, display mode, and OSD size displayed onme/date
the live view.
Steps
1. Click Image → OSD Sengs to enter the page.sengs
2. Check the corresponding checkbox to select the display of camera name, date or week if
required.
3. Edit the Camera Name.
4. Select from the drop-down list to set the Time Format Date Format and .
5. Adjust the OSD posion.
6. Click Save to enable the sengs.
Target Cropping
Steps
1. Click Image → Crop to enter the page.
2. Check Enable Target Cropping to enable the funcon.
3. Click to capture photo.
4. Click to start recording.
6 Series Video Intercom Villa Door User ManualStaon
34
5. Select Cropping Resoluon.
6. Click Save.
Note
●You can select Cropping Resoluon as , , or .704*576 1280*720 1920*1080
●You can zoom in or zoom out the image by selecng Cropping Resoluon clicking .aer Save
5.4.6 Event Sengs
Moon Detecon
Moon detecon detects the moving objects in the congured security area, and a series of
acons can be taken when the alarm is triggered.
Steps
1. Click Event → Moon to enter the page.sengs
6 Series Video Intercom Villa Door User ManualStaon
35
Figure 5-16 Moon Detecon
2. Slide to enable the Enable Moon Detecon funcon.
3. Click Draw Area. Click and drag the mouse on the live video to draw a area.moon detecon
Click Save to save the sengs.
Clear Area Click to clear all of the areas.X
Adjust Sensivity Move the slider to set the of the sensivity detecon.
4. Click to edit the arming schedule.Arming Schedule
6 Series Video Intercom Villa Door User ManualStaon
36
5. Click on the bar and drag the mouse to select the period. Click to save theme me Save
sengs.
Delete Schedule DeleteClick to delete the current arming schedule.
6. Click Linkage Method to enable the linkages.
Nofy Security Center
Send an excepon or alarm signal to the remote management soware when an event
occurs.
7. Click Save to enable the sengs.
Event Linkage
Steps
1. Click Event → Basic Event → Event Linkage to enter the sengs page.
6 Series Video Intercom Villa Door User ManualStaon
37
Figure 5-17 Event Linkage
6 Series Video Intercom Villa Door Staon User Manual
38
2. Select the Major Type Device Event Door Event as or .
3. Select the type of the Normal Linkage for the event.
4. Click Save to enable the sengs.
5.4.7 Schedule Sengs
You can create call schedule, or else the device will call indoor all day by default.staon
Steps
1. Click Schedule → Video Intercom → Call Schedule .
2. Click the next row below Enable Indoor All Day by DefaultStaon .
3. Enter .Schedule Name
4. Select Call Type.
5. Set Weekly Schedule.
1) Click Weekly Schedule.
Figure 5-18 Weekly Schedule
2) Drag mouse to set the schedule according to the actual needs.
3) Oponal: Click the copy icon to copy the schedule to other days according to the actual
needs.
4) Click Save.
6. Set Holiday Schedule.
1) Click .Holiday Schedule
6 Series Video Intercom Villa Door User ManualStaon
39
Figure 5-20 Villa Door No. Staon Sengs
2. Select the device type from the drop-down list, and set the corresponding informaon including
Building No. Floor No. Door No. Community No. Unit No., , Staon , and
Note
When you select as Doorphone Device Type Community No. Building No. Unit No., only , and
can be set.
3. Click Save to enable the device number conguraon.
Note
●For main door staon (D series or V series), the No. is 0.
●For sub door staon staon (D series or V series), the No. cannot be 0. The No.of sub door
ranges from 1 to 99.
●For each villa or building, at least one main door staon (D series or V series) should be
congured, staons and one sub door (D series or V series) can be customized.
●For one main door staon (D series or V series), up to 8 sub door can be staons congured.
Linked Network Sengs
Steps
1. Go to Intercom → Session Sengs to enter the page.sengs
2. Set Register Number and Registraon Password.
3. Set Main Staon IP VideoIntercom Server IP and .
6 Series Video Intercom Villa Door Staon User Manual
41
4. Enable Protocol 1.0.
5. Click Save to enable the sengs.
Time Parameters
Go to Intercom → Time Parameters to enter the page.
Congure Max. Call Max. Message Duraon, Duraon Duraon, Max. Ring , and click Save.
Note
●Max. call duraon between the module indoor and client ranges from 90 s to 120 s. Thestaon
call will end when the actual calling is longer than the automacally duraon congured one.
●Max. message duraon ranges from 30 s to 60 s. The message will end when theautomacally
actual message duraon is longer than the congured one.
●Max. ring duraon refers to the maximum of the module indoor duraon staon when it is
called without being accepted. Max. ring duraon ranges from 65 s to 255 s.
Ring-Back Tone Sengs
Click Intercom → Ringbacktone Sengs to enter the page.sengs
Click to select the ring tone from PC.Add
Note
Available Audio Format: WAV AAC, Size: Less than 600 KB, Sample Rate: 8000Hz, Mono.、
Press to CallBuon
Steps
1. Go to Intercom → Press to Call Buon to enter the page.sengs
Figure 5-21 Press to CallBuon
2. Edit room No. in the and select .buon sengs Link Time Schedule
6 Series Video Intercom Villa Door User ManualStaon
42
Note
●The number of may vary with buons dierent models. Please refer to the actual product.
●The schedule refers to for details.sengs Schedule Sengs
3. Click Save to enable the sengs.
Number Sengs
Link the room No. and SIP numbers.
Click Number Sengs to enter the page.
Figure 5-22 Number Sengs
Click , set the Add Room No. and SIP numbers in the pop-up dialog box.
5.4.9 Access Control Sengs
Door Parameters
Steps
1. Click Access Control → Door Parameters to enter the sengs page.
6 Series Video Intercom Villa Door User ManualStaon
43
Figure 5-23 Door Parameters
2. Select the door and edit the door name.
3. Edit Open Duraon.
4. Set door contact status.
5. Click Save to enable the sengs.
Elevator Control
Before You Start
●Make sure your door is in the mode of main door staon staon. staon Only the main door
support elevator control funcon.
●Make sure your door has been connected to the elevator controller via RS-485 wire if youstaon
want to use RS-485 interface.
Steps
1. Click Access Control → Elevator Control to enter the corresponding conguraon page.
6 Series Video Intercom Villa Door User ManualStaon
44
Figure 5-24 Elevator Control
2. Check to enable elevator control funcon.
3. Select an Elevator No., and select an elevator controller type for the elevator.
4. Set the Negave Floor.
5. Select the Interface Type as RS-485 or Network Interface. And enable the elevator control.
-If you select RS-485, make sure you have connected the door staon to the elevator controller
with RS-485 wire.
-If you select Network interface, enter the elevator controller's IP address, port No., user
name, and password.
6. Click Save to enable the sengs.
6 Series Video Intercom Villa Door User ManualStaon
45
Note
●Up to 4 elevator controllers can be connected to one door staon.
●Up to 10 negave oors can be added.
●Make sure the interface types of elevator controllers, which are connected to the same door
staon are consistent.
6 Series Video Intercom Villa Door User ManualStaon
46
Chapter 6 Conguraon via Client Soware
6.1 Device Management
Device management includes device adding device, device, and device,acvaon, eding deleng
and so on.
Aer running the iVMS-4200, video intercom devices should be added to the client soware for
remote conguraon and management.
6.1.1 Add Online Device
Before You Start
Make sure the device to be added is in the same subnet with your computer. Otherwise, please
edit network parameters rst.
Steps
1. Click to select an online device.Online Device acve
2. Click .Add
3. Enter corresponding informaon, and click .Add
6 Series Video Intercom Villa Door User ManualStaon
47
Figure 6-1 Add to the Client
6 Series Video Intercom Villa Door Staon User Manual
48
6.1.2 Add Device by IP Address
Steps
1. Click to pop up the adding devices dialog box.+Add
2. Select IP/Domain Adding Mode as .
3. Enter corresponding informaon.
4. Click .Add
6.1.3 Add Device by IP Segment
You can add many devices at once whose IP addresses are among the IP segment.
Steps
1. Click to pop up the dialog box.+Add
2. Select as .IP Segment Adding Mode
3. Enter corresponding informaon, and click .Add
6.2 Live View via Door Staon
Steps
1. On the main page of the client soware, click to enter the Live View page.Main View
2. In the list of the window, double-click the device IP or click the play icon to live view.le
3. Oponal: On the Live View page, control-click and select to get the picture of the liveCapture
view.
6.3 Organizaon Management
On the main page of the Client Soware, click PersonalManagement to enter the
conguraon page.
6.3.1 Add Organizaon
Steps
1. In the organizaon le, list on the click .+Add
2. Enter the Organizaon Name as desired.
3. Click to save the adding.OK
4. Oponal: You can add levels of mulple organizaons according to the actual needs.
1) You can add levels of mulple organizaons according to the actual needs.
2) Then the added organizaon sub-organizaon will be the of the upper-level organizaon.
6 Series Video Intercom Villa Door User ManualStaon
49
Note
Up to 10 levels of organizaons can be created.
6.3.2 Modify and Delete Organizaon
You can select the added organizaon and click to modify its name.
You can select an organizaon, buon and click X to delete it.
Note
●The lower-level organizaons will be deleted as well if you delete an organizaon.
●Make sure there is no person added under the organizaon, organizaon or the cannot be
deleted.
6.4 Person Management
Aer organizaon, adding the you can add person to the organizaon and manage the added
person such as issuing cards in batch, imporng exporng and person's informaon in batch, etc.
Note
●Up to 2,000 persons can be added.
●Up to 5 cards can be added to each person.
6.4.1 Add Person
Person informaon is necessary for the video intercom system. And when you set linked device for
the person, the intercom between intercom devices can be realized.
Steps
1. Select an organizaon organizaon in the list and click on the Person panel to pop up theAdd
adding person dialog.
Note
The Person No. will be generated automacally and is editable.
2. Set basic person informaon.
1) Enter basic informaon: name, tel, birthday details, eecve period and email address.
Note
The length of person name should be less than 15 characters.
2) Click face to upload the photo.Add
6 Series Video Intercom Villa Door User ManualStaon
50
Note
The picture should be in *.jpg format.
Click Upload Select the person picture from the local PC to upload it to the
client.
Click Take Phone Take the person's photo with the PC camera.
Click Remote Collecon Take the person's photo with the device.collecon
3. Issue the card for the person.
1) Click Credenal .→ Card
2) Click to pop up the Add Card dialog.+
3) Select as Normal Card Card Type.
4) Enter the Card No.
5) Click and the card(s) will be issued to the person.Read
4. Link the device to the person.
1) Set the linked devices.
Linked Device
You can bind the indoor staon to the person.
Note
If you select Analog Indoor Staon in the Linked Device, the will displayDoor Staon eld
and you are required to select the door to communicate with the analog indoorstaon
staon.
Room No.
You can enter the room No. of the person.
2) Click to save the OK sengs.
5. Click to save the Add sengs.
6.4.2 Modify and Delete Person
Select the person and click Edit to open the person dialog.eding
To delete the person, select a person and click to delete it.Delete
Note
If a card is issued to the current person, the linkage will be invalid the person is deleted.aer
6.4.3 Change Person to Other Organizaon
You can move the person to another organizaon if needed.
6 Series Video Intercom Villa Door Staon User Manual
51
Steps
1. Select the person in the list and click Change Organizaon.
2. Select the organizaon to move the person to.
3. Click to save the OK sengs.
6.4.4 Import and Export Person Informaon
The person informaon can be imported and exported in batch.
Steps
1. Exporng Person: You can export the added persons' informaon in Excel format to the local PC.
1) Aer adding the person, you can click Export Person to pop up the following dialog.
2) Click to select the path of saving the exported Excel ... le.
3) Check the checkboxes to select the person informaon to export.
4) Click to start OK exporng.
2. Imporng Person: You can import the Excel with persons le informaon in batch from the local
PC.
1) Click Import Person.
2) You can click Download Template for Imporng Person to download the template rst.
3) Input the person informaon to the downloaded template.
4) Click to select the Excel with person ... le informaon.
5) Click to start OK imporng.
6.4.5 Get Person Informaon from Device
If the added device has been congured informaon with person (including person details,
ngerprint, issued card informaon), you can get the person from the device andinformaon
import to the client for further operaon.
Steps
Note
This is only supported by the device the funcon connecon mothod of which is TCP/IP when
adding the device.
1. In the organizaon list on the click to select an le, organizaon to import the persons.
2. Click Get from Device to pop up the dialog box.
3. The added device will be displayed.
4. Click to select the device and then click to start Get geng the person from theinformaon
device.
6 Series Video Intercom Villa Door User ManualStaon
52
Figure 6-2 Issue Card in Batch
2. Click .Sengs
6 Series Video Intercom Villa Door User ManualStaon
54
6.4.7 Permission Sengs
Add Permissions
Steps
1. On the main page, click AccessControlInfo → Access Group to enter the page.
2. Click to pop up the adding dialog box.+Add
3. Congure the parameters.
1) Enter the of the permission.Name
2) Select the Template of the schedule.
3) Check the person to according to your needs.Selected
4) Check the device to Selected according to your needs.
4. Click Save.
5. Check the permission and click .Apply All to Device
The status of the permission displays as .Applied
6. Oponal: Applying StatusClick to check the details.
Modify/Delete Permissions
On the page of the permission click to edit the parameters of the permission.sengs,
Select one or more permissions, click Delete to remove the permissions.
6.5 Video Intercom Sengs
The Video Intercom Management module provides the of video intercom, checking callfuncon
logs and managing via the iVMS-4200 Client noce Soware.
Note
For the user with access control module permissions, the user can enter the Access Control
module and manage video intercom and search informaon.
You should add the device to the soware congure and the person to link the device in Access
Control module before your conguraon remotely.
On the main page, click AccessControlInfo → Video Intercom → Video Intercom on the le
bar to enter the Video Intercom page.
6 Series Video Intercom Villa Door Staon User Manual
56
6.5.1 Receive Call from Door Staon
Steps
1. Select the client soware in the page to start calling the client and an incoming call dialog will
pop up in the client soware.
2. Click to answer the call. Or click to decline the call.Answer Hang Up
3. Aer you answer the call, you will enter the In Call page.
Adjust the Volume of
Loudspeaker
Click to adjust the volume of loudspeaker.
Hang Up Hang UpClick to hang up.
Adjust the Volume of
Microphone
Click to adjust the volume of microphone.
Unlock Remotely For door staon, you can click to open the door
remotely.
Note
●One video intercom device can only connect with one client soware.
●The maximum ring duraon can be set from 15s to 60s via the Remote Conguraon of the
video intercom device.
●The maximum speaking duraon between indoor staon and iVMS-4200 can be set from 120s
to 600s via the Remote Conguraon staon. of indoor
●The maximum speaking duraon staon between door and iVMS-4200 can be set from 90s to
120s via the Remote Conguraon staon. of door
6.5.2 Release Noce
You can create dierent noces types of and send them to the residents. Four types arenoce
available, including Property, Alarm and Adversing, Noce Informaon.
Before You Start
Make sure the person has been added to the client.
Steps
1. On the video intercom sengs page, click to enter the page.Noce
2. Click to pop up the adding dialog box.+Add
3. Select the person according to your needs.
4. Edit the , Subject Type and Informaon.
5. Click to select the picture.View
6. Click .Send
6 Series Video Intercom Villa Door User ManualStaon
57
Produktspecifikationer
| Varumärke: | Hikvision |
| Kategori: | Intercomsystem |
| Modell: | DS-KV6103-PE1 |
Behöver du hjälp?
Om du behöver hjälp med Hikvision DS-KV6103-PE1 ställ en fråga nedan och andra användare kommer att svara dig
Intercomsystem Hikvision Manualer
27 Mars 2025
27 Mars 2025
2 Mars 2025
7 Januari 2025
8 Oktober 2024
25 September 2024
25 September 2024
25 September 2024
25 September 2024
25 September 2024
Intercomsystem Manualer
- Hollyland
- Estom
- Smartwares
- Abus
- Eartec
- Ritto
- Aiphone
- Avidsen
- RTS
- Steren
- ORNO
- Schwaiger
- EtiamPro
- Nortek
- DIO
Nyaste Intercomsystem Manualer
28 Mars 2025
27 Mars 2025
27 Mars 2025
11 Mars 2025
10 Mars 2025
9 Mars 2025
20 Februari 2025
20 Februari 2025
20 Februari 2025
20 Februari 2025
