assemblyinstructions
Family: Hampton Item No. 3201
1.Find a clear area in which you can work.
1. Attach acrylic lens assembly by threading coupler onto end of lower upright (1)(2)
stems - see .(3)Drawings 1 and 2
1. Fasten mounting strap to outlet box with the original box screws - see (B)(A)(C)
Drawing 3.
2. Thread nipple into mounting strap approximately 3/8”.(D)(B)
2.Unpack fixture and glass from carton.
3...ylbmessa ot roirp snoitcurtsni weiver ylluferaC
*** The construction of this fixture will be accomplished by first assembling the
main body structure, installing the mounting hardware to the junction box,
mounting the fixture to the ceiling and then installing the shade.
starthere
3201
9.31.09
3
Drawing 1 - Fixtu
Drawing 2 - Fixture Assembly
Drawing 3 - Mounting Instructions
re Assembly
A
1
2
1
B
C
4
3
SAFETY WARNING: READ WIRING AND GROUNDING INSTRUCTIONS (I.S. 18)
AND ANY ADDITIONAL DIRECTIONS. TURN POWER SUPPLY OFF DURING
INSTALLATION. IF NEW WIRING IS REQUIRED, CONSULT A QUALIFIED
ELECTRICIAN OR LOCAL AUTHORITIES FOR CODE REQUIREMENTS.
Make electrical connections from supply wire to fixture lead wires. Refer to instruction
sheet and follow all instructions to make all necessary wiring connections. (I.S. 18)
Then refer back to this page to continue installation of this fixture.
4
5
6
1. Slip canopyover nipple and up against ceiling - see . (E) (D)Drawing 3
2. Thread decorative finial onto end of nipple.(F) (D)
1. Fixture can now be lamped accordingly.
2. Slip shade onto acrylic assembly - see .(4)(1)Drawing 2
F
E
D
T24 JA8-2016
H I N K L E Y L I G H T I N G 33000 Pin Oak Parkway Avon Lake, OH 44012 800.446.5539 / 440.653.5500 hinkleylighting.com
